Accessories included -
Active power - 600 W
Alarm -
Alarm when on battery distinctive low battery alarm overload continuous tone alarm
Apparent power - 750 VA
ARTIKEL1 - SMART-UPS X 750VA RACK/TOWERR
ARTIKEL2 - LCD 230V WITH NETWORKING CARD IN
Backup time (100% load) - 14.2 min
Battery - Automatic battery test - Yes
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 3 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - Yes
Battery life (max), years - 3-5
Battery recharge time, h - 3
BatteryType - Maintenance-free sealed Lead-Acid battery with suspended electrolyteleakproof
Brand - APC
BrandPartCode - SMX750INC
Category - Uninterruptible Power Supplies (UPSs)
Charging time - 3 h
Chassis type - Tower
Color - Black
Connections - RJ-45 10/100 Base-T
Connections - RJ-45 Serial
Connections - Smart-Slot
Connections - USB
ControlPanel - Multi-function LCD status and control console
Depth - 490 mm
Depth, mm - 490
Description - APC SMART-UPS X 750VA RACK/TOWERR LCD 230V WITH NETWORKING CARD
Description - APC Smart-UPS X 750VA Rack / TowerR LCD 230V z kartą sieciową
Design - Certification - CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH
Design - Display type - LED
Design - Form factor - Rackmount/Tower
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack capacity - 2U
dimension depth - 245 mm
dimension height - 590 mm
Dimensions - 89 x 432 x 490 mm
dimension weight - 25400 g
dimension width - 630 mm
ean - 731304327745
EANCode - 0731304327745
Environment requirements -
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Low battery alarm, Overload alarm
Features - Auto-restart - Yes
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 302 V
Features - Input operation voltage (min) - 151 V
Features - Noise level - 40 dB
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 600 W
Features - Output power capacity - 0.75 kVA
Features - Surge energy rating - 645 J
Features - Surge protection - Yes
Features - Temperature voltage compensation - Yes
Features - UPS topology - Line-Interactive
Features - Waveform - Pure sine
Features - Web-based management - Yes
FormFactor - RackTower
Form factor - Rack / Tower
Gewicht - 26
GrossWeight - 26.150 kg
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304327745
GTIN - 0731304327745
guarantee - 36
guarantee_type - external
Height - 89 mm
Height - 248.000000
Height, mm - 89
HERSTELLER - APC
HSTNUMMER - SMX750INC
I/O connectors - 1 x RJ-45 (iLO Remote Management Network)
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB 2.0
Input connection - IEC-320 C14
InputConnections - IEC-320 C14
InputFrequency - 50/60 Hz +/- 3 Hz (auto sensing)
Input frequency, Hz - 50/60 +/- 3
Input power ports - IEC-C14
InputVoltage - 230V
InterfacePorts - RJ-45 10/100 Base-TRJ-45 SerialSmartSlotUSB
Length - 633.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 8 pc(s)
LongDesc - 03-07 (296)
LongDesc - Cold-start capableProvides temporary battery power when the utility power is out.Energy meterProvides actual kilowatt hours of usage for energy conscious users.Green modePatent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.High online efficiencyReduces utlility costs, generates less heat.Intuitive LCD interfaceProvides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.Predictive replace battery dateDynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.Preinstalled network management cardProvides for remote management and control of the UPS over a network out of the box.Pure sine wave output on batterySimulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.Single switched outlet groupSingle outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.SmartSlotCustomize UPS capabilities with management cards.Temperature-compensated battery chargingProlongs battery life by regulating the charge voltage according to battery temperature.
LongProductName - 750 VA, 600W, 302V, 50/60Hz, 40dB, 432x490x89mm, 22kg, Black
LongSummaryDescription - APC SMX750INC. UPS topology: Line-Interactive, Output power capacity: 0.75 kVA, Output power: 600 W. AC outlet types: C13 coupler, IEC Jumpers, Power plug: C14 coupler, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery life (max): 5 year(s), Battery recharge time: 3 h. Form factor: Rackmount/Tower, Product colour: Black, Rack capacity: 2U. Width: 432 mm, Depth: 490 mm, Height: 89 mm
Manufacturer - APC
ManufacturerPartNumber - SMX750INC
MANUFDATASHEET - https://www.apc.com/shop/ae/en/products/APC-Smart-UPS-X-750VA-Rack-TowerR-LCD-230V-with-Networking-Card/P-SMX750INC
Maximum power, W - 600
name - SMX750INC SMART X 750VA USB/AP9631/LCD/RT
No. of batteries - 1
Noise level, dB - 40
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0 - 95
Operating temperature range (T-T), °C - 0 - 40
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Other features -
OutputConnections - (2) IEC Jumpers (Battery Backup)(8) IEC 320 C13 (Battery Backup)
OutputFrequency - 50/60Hz +/- 3 Hz
Output power, W - 600
Output power capacity (VA) - 750
Output power ports - 8 x IEC-C13
OutputVoltage - 230 V
PackageContents - CD with softwareDocumentation CDInstallation guideRack Mounting bracketsSmart UPS signalling RS-232 cableTemperature ProbeUSB cable
Packaging data - Cables included - RS-232, USB cable
Packaging data - Quick installation guide - Yes
Packaging data - Rack mount kit - Yes
Packaging data - Resource CD - Yes
Packaging data - Software CD - Yes
PeriodofWarranty - 3 Y
Ports & interfaces - AC outlets quantity - 10 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler, IEC Jumpers
Ports & interfaces - Cabling technology - 10/100Base-T
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RJ-45
Ports & interfaces - Serial ports quantity - 1
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
PowerVAW - 750 VA
PowerW - 600 W
ProdDesc - APC Smart-UPS X 750VA Rack/TowerR LCD 230V with Networking Card
producer - APC
ProductName - SMX750INC
ProductPicture - http://www.tdbaltic.ee/images/ds4/SMX750INC-01.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
RechargeTime - 3 h
RJ45 - Yes
Runtime - 37.8/14.2
ShortSummaryDescription - APC SMX750INC, Line-Interactive, 0.75 kVA, 600 W, Pure sine, 151 V, 302 V
SmartSlot - Yes
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 1
Storage temperature range (T-T), °C - -15 - 45
Storno - N
Title - APC SMX750INC uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 600 W 10 AC outlet(s)
Topology - Online
UPS Architecture - line-interactive
UPS devices and accessories - Yes
URL - https://www.apc.com/shop/uk/en/products/APC-Smart-UPS-X-750VA-Rack-TowerR-LCD-230V-with-Networking-Card/P-SMX750INC?isCurrentSite=true
USB - Yes
vendpn - SMX750INC
Warranty - -
WarrantyInfo - 3 years
WaveformType - Sine wave
Weight - 22 kg
Weight - 22.000 Kg
Weight - 26.100000
Weight & dimensions - Depth - 490 mm
Weight & dimensions - Height - 89 mm
Weight & dimensions - Package depth - 620 mm
Weight & dimensions - Package height - 246 mm
Weight & dimensions - Package weight - 26.4 kg
Weight & dimensions - Package width - 589 mm
Weight & dimensions - Weight - 22 kg
Weight & dimensions - Width - 432 mm
Weight, kg - 22
Width - 432 mm
Width - 590.000000
Width, mm - 432
