AG NEOVO DW3401, 34"

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 904508 Product code: DW3401
Can be ordered 1 units Availability: 14 days after order approval
Warranty: 2 years
694.60 €
Delivery options
  • Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
  • Courier delivery 11.99 €: 10.12.2024
Main product parameters All parameters
  • Curved: Nav
  • Panel Type: IPS
  • Refresh rate: 75 Hz
  • Response time: 5ms
  • Contrast ratio: 1000000:1
  • Brightness: 350cd/m2
  • Size: 34"
  • Resolution: UWWQHD 3440x1440
Description
We offer to buy AG NEOVO 34" a monitor with UWWQHD 3440x1440 resolution.
  • IPS matrix for this monitor provides high colour correspondence parameters, superior picture contrast and good visibility from eventually all viewing angles.
  • The compatibility with the modern graphics cards and video players will be ensured by HDMI input.
  • DisplayPort port ensures the receipt of a higher quality picture from the computer graphics card supporting this technology.
  • The speakers system built in the monitor allows to listen to music and enjoy films with sound without making it necessary to buy additional speakers.
  • 5ms the response time is suitable for games and dynamic films.
Display characteristics
AMD FreeSync : Nav
Curved : Nav
NVIDIA G-SYNC : Nav
Panel Type IPS

Teh monitor panel is the main feature of the visible part of the screen or the technology where the display of the colour dots (pixels) is implemented.

TN is the standard technology with average contract, brightness and colour compliance indices.

IPS is the matrix with high colour compliance and good response speed, therefore it is well suited for graphics tasks and photo editing. IPS matrix provide an excellent viewing angle maintaining the colours and contrast from almost any angle.

VA matrix ensures superior colour compliance, however, the response time of this matrix is lagging behind that of the IPS and TN; the viewing angle is somewhere between both these technologies.

The TN type monitor is fully sufficient for an average user. If you have more money available the VA or IPS can be chosen.

Refresh rate : 75 Hz
Touchscreen : NO
VESA DisplayHDR : DisplayHDR 400
Response time 5ms
The response time of the monitor screen determines how fast the monitor will display moving images (films, games, animations, etc.). The response time is measured in miliseconds. The less the response time the better the ability of the monitor to display moving images.
www.toppc.fi recommends to buy monitors with 5ms response time or lower.
Contrast ratio 1000000:1

Ekrāna kontrasts nosaka attēla asumu. Tā ir atšķirība starp vistumšāko (pilnīgi melnu) un visgaišāko (pilnīgi baltu) pikseli. Jo lielāks kontrasts, jo skaidrāk salasāms teksts uz ekrāna, kontrasts arī nosaka, cik izteiksmīgas līnijas būs redzamas monitora attēlā.

Augsts kontrasts ir nozīmīgs faktors izvēloties monitoru biroja, vai mācību vajadzībām, kad lielākoties tiek strādāts ar tekstuālu informāciju.

Mājas vajadzībām svarīgāks izvēles rādītājs ir gaišums un attēla reakcijas laiks. Kontrastu labāk novērtēt tumšā istabā.
Lielākais LCD monitoru trūkums ir tas, ka samazinot attēla spilgtumu, kontrasts var pazust.

Brightness 350cd/m2

Monitora gaišums ir attēla redzamības rādītājs, kas nosaka, cik labi saskatāms ir attēls pie spēcīga ārējā apgaismojuma (saules gaisma, gaiša telpa, utt.). LCD monitoru gaišums tiek mērīts kandelās uz kvadrātmetru (Cd/m2).
Izvēloties monitoru jāņem vērā - jo lielāks gaišuma rādītājs, jo labāka attēla redzamība.

Ikdienas vajadzībām TopPC.fi iesaka iegādāties monitoru ar gaišumu, ne mazāku par 250 cd/m2.

Basic information
Application : Creative
Aspect ratio : 21:9
Color : Black
Size 34"

The size of the monitor screen is measured in inches across the diagonal. The screen size must be proportionate to the resolution of the screen for achieving the maximum utilisation of the desktop and details of the image.

Mainly two forms of LCD monitors are available: with standard width and height proportion 4:3 or the widescreen proportion 16:9 or 16:10. A widescreen monitor is wider and its resolution is higher than that of the monitors with standard proportion.

The bigger the monitor size the higher resolution usually is supported. Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.

Resolution UWWQHD 3440x1440

The resolution of the monitor screen determines the number of colour dots (pixels) a monitor can display. It refers to the clarity of the text and images displayed on the screen. The higher the resolution the sharper the items look.

The applied resolution depends on the resolution supported by the monitor. LCD monitors, including the screens of laptop computers usually work best if their local resolution has been set. The setting of this resolution for the monitor is not mandatory, but usually it is recommended to set it for ensuring the highest possible sharpness of texts and images. The bigger the monitor size the higher resolution usually is supported.

Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.
• 19 inches screen (standard proportions): 1280x1024 pixels
• 20 inches screen (standard proportions): 1600x1200 pixels
• 22 inches screen (widescreen): 1680x1050 pixels
• 24 inches screen (widescreen): 1900x1200 pixels

Functionality
Flicker-free : Ir
Height adjustment : Ir
Pivot : Nav
Swivel : And
Tilt : YES
VESA wall mount : 100x100 mm
Ports and equipment
D-SUB Nav

D-SUB is the classic (analogous) monitor connection plug. This standard is gradually disappearing from the market giving the place to the higher quality HDMI or DisplayPort (digital) plugs.

If the resolution of the monitor is FullHD or below the average user will experience no problems with this connection. Those who want to achieve higher image quality and resolution should look for the monitor with the DisplayPort or HDMI connection slot.

DisplayPort 1

DisplayPort is the digital connection for transmitting the image via a single wire at a high quality level. Contrary to the HDMI, this connection allows to connect several external monitors to the computer via a single connector.

Prior to buying the monitor with the DisplayPort you should verify whether your computer has the DisplayPort plug available!

DVI Nav

DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.

DVI is compatible with HDMI and transitions of both directions are available.

DVI is not compatible with DisplayPort, however, there are DualMode DisplayPort connectors which contains the HDMI/DVI signal, and in the relevant direction DisplayPort -> DVI can transmit an image.

If the monitor resolution exceeds 1920px in any direction a graphics card with the DVI-D Dual Link support and the relevant quality cable will be required.

Before buying a monitor you should verify whether your graphics card has the corresponding connection slot!

HDMI port 1

HDMI is the digital high quality image transmission standard that allows to connect the monitor to the computer via a thin cable by using an elegant small-size connector. HDMI is compatible with DVI if the relevant transition or cable is used.

Speakers Ir

Some monitors may have built-in speakers that quite often allow to give up external speakers thus freeing a space on the desk and saving money. The sound quality of built-in speakers is quite moderate and therefore we recommend to use this possibility just for infrequent needs.

For enjoying music, movies and games we recommend buying the corresponding quality and capacity speakers.

USB Hub : NO
USB-C Power Delivery : 65W
USB-C video input : 1
More detailed specification
Additional information in manufacturers website AG NEOVO DW3401, 34"
ARTIKEL1 - DW-3401 34IN ULTRAWIDE IPS
ARTIKEL2 - 3440X1440 350 CD/M2 1000000:1 US
Brand - AG Neovo
BrandPartCode - DW3401
Breite - 0
Category - Computer Monitors
Design - Country of origin - Taiwan
Design - Detachable stand - Yes
Design - Feet colour - Black
Design - Frameless design - Yes
Design - Front bezel colour - Black
Design - Market positioning - Photo editing
Design - Product colour - Black
dimensionalWeight - 21120
Display - Adobe RGB coverage - 110%
Display - Anti-glare screen - Yes
Display - Aspect ratio - 21:9
Display - Backlight type - LED
Display - Colour gamut - 100%
Display - Colour gamut standard - DCI-P3
Display - Contrast ratio (typical) - 1000000:1
Display - Digital horizontal frequency - 30 - 112 kHz
Display - Digital vertical frequency - 50 - 76 Hz
Display - Display brightness (typical) - 350 cd/m²
Display - Display diagonal - 86.4 cm (34")
Display - Display diagonal (metric) - 87 cm
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 3440 x 1440 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - UltraWide Quad HD
Display - High Dynamic Range (HDR) supported - Yes
Display - High Dynamic Range (HDR) technology - High Dynamic Range (HDR) 400
Display - Horizontal scan range - 30 - 112 kHz
Display - Maximum refresh rate - 75 Hz
Display - Native aspect ratio - 21:9
Display - NTSC coverage (typical) - 110%
Display - Panel type - IPS
Display - Pixel pitch - 0.233 x 0.233 mm
Display - Response time - 5 ms
Display - RGB colour space - DCI-P3
Display - Screen shape - Flat
Display - sRGB coverage (typical) - 130%
Display - Surface hardness - 3H
Display - Touchscreen - No
Display - Vertical scan range - 50 - 76 Hz
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 4710739597714
Ergonomics - Cable lock slot - No
Ergonomics - Height adjustment - 12 cm
Ergonomics - Height adjustment - Yes
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Picture-in-Picture - Yes
Ergonomics - Pivot - No
Ergonomics - Swivel angle range - 0 - 30°
Ergonomics - Swivelling - Yes
Ergonomics - Tiltable - Y
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 15°
Ergonomics - VESA mounting - Yes
GRUPPE1 - Displays
GRUPPE2 - Lcd Monitor
GTIN - 4710739597714
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0
HSTNUMMER - DW341011E0000
Laenge - 0
LongDesc - DW3401 - 34-Inch 1440p Ultrawide USB-C MonitorThe DW3401 34-Inch USB-C monitor is designed to provide productive workspace for multi-tasking on a single screen at the office and home. With a one-cable solution, it is easy to connect the laptop or tablet while charging the device, allowing you to start working quickly. In addition, the LCD monitor features 3440 x 1440 ultrawide resolution with 21:9 aspect ratio, wide viewing angle and richer color performance, delivering crisp and accurate image performance in detail. Its full-function ergonomic stand allows to build up a productive and comfortable working environment for document editing, web design, artwork creation and video production.USB-C ONE-CABLE CONNECTION TO START PRODUCTIVE WORK QUICKLYStart to work quickly and keep your desktop looking neat with the USB Type-C port connectivity. The video, audio, data and power can be transferred via the convenience of one cable. When charging connected device via USB Type-C Connector, check if the device is equipped with a USB Type-C Connector that supports charging function via USB Power Delivery.USB Power DeliveryPower and charge your laptop, tablet or mobile phone through the USB-C cable (up to 65 W).Super Speed Data TransferEnjoy fast data transfer rates up to 5 Gbps.2K Video QualityDisplay 2K video from your notebook over a single USB-C connector and cable.3440 X 1440 CRISP IMAGE QUALITYThe DW3401 USB-C monitor features UWQHD 3,440 x 1,440 pixels delivers razor-sharp image detail.SEE MORE CONTENT AND MULTI-TASKINGThis 21:9 aspeact ratio offers much wider space to view more columns on one excel files, codings or tool bar for video editors. Its around 30% more space than 16:9 aspect ratio is also ideal for multi-tasking to view different windows for more productive work.COLOR PERFORMANCEThe LCD screen provides wider color space to cover various standards, including 130% sRGB, 110% Adobe RGB and 100% DCI-P3 to offer accurate colors and vivid images for impressive color performance.ACCURATE AND CONSISTENTAchieving Delta E≤2 color accuracy, the DW3401 renders true-to-life color reproduction and ensures your creatives on the screen can be exactly represented as you see.SMOOTHER MOTION PICTURE QUALITYThe DW3401 features 75hz refresh rate to provide smooth scrolling and see more visual elements on fast-moving objects.SEAMLESS GAMEPLAYThe adaptive sync functionality can synchronize with the graphics card to squash screen tearing, stutter, and input latency. You can enjoy seamless gameplay for the sports, racing games for console or casual gaming.IPS WIDE VIEWING ANGLEWith IPS panel technology, this 34-inch 1440p USB-C monitor delivers the same image quality whether you are looking at the screen from above, below, the front, or the side.BEZEL LESS DESIGNA bezel less design allows for multiple monitor setups with a reduced bezel gap, which won’t just let you enjoy a nearly seamless viewing experience, but also enhance productivity at work.HDR400 READYWith the ability to decode HDR400 video* signals, this monitor delivers incredibly detailed video playback. Colors are brighter and more vivid, and contrast is richer and more detailed. With such amazing image reproduction, this monitor displays videos as they were intended to be seen – giving you a fuller, more immersive viewing experience.PIP/PBPThe monitor supports Picture-in-Picture (PiP) and Picture-by-Picture (PbP) to view content from different input sources, perfect for optimal multiple tasks with one monitor.Enhanced Viewing ComfortThe flicker free backlight and blue light filter of this 34-inch bezel less monitor ensure better viewing comfort effectively by reducing eye fatigue after long periods of use.Loaded with ConnectivityIn addition to USB 3.1 Type C port, the DisplayPort, HDMI inputs and dual speakers give you the freedom and flexibility to connect to a variety of multimedia devices.VESA Mounting CompatibleSupporting 100 x 100mm VESA mounting standard, you can flexibly set up your workspace from our accessory options.
LongProductName - 34", WQHD, 1440p, IPS LED, 2560x1440, 300cd/m2, 1000:1, HDMI, DisplayPort, USB-C (65W), Ergonomic stand, Black
LongSummaryDescription - AG Neovo DW3401. Display diagonal: 86.4 cm (34"), Display resolution: 3440 x 1440 pixels, HD type: UltraWide Quad HD, Display technology: LED, Response time: 5 ms, Native aspect ratio: 21:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting, Height adjustment. Product colour: Black
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 4 W
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - CE, Low Voltage Directive (LVD), REACH, RoHS, WEEE
Other features - Country of origin - Taiwan
Other features - Delta E - 2
Other features - Picture-by-Picture (PbP) - Yes
Packaging content - Cables included - AC
Packaging content - Cables included - AC, HDMI, USB Type-C
Packaging content - Cables included - HDMI
Packaging content - Cables included - USB Type-C
Packaging content - Quick start guide - Yes
Packaging content - Screws included - Yes
Packaging content - Stand included - Yes
Packaging data - Package depth - 218 mm
Packaging data - Package height - 505 mm
Packaging data - Package type - Box
Packaging data - Package weight - 14.5 kg
Packaging data - Package width - 960 mm
Packaging data - Warranty card - Yes
Performance - AMD FreeSync - No
Performance - Flicker-free technology - Yes
Performance - Low Blue Light technology - Yes
Performance - NVIDIA G-SYNC - No
Performance - VESA Adaptive Sync support - Yes
Ports & interfaces - AC (power) in - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.2
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - HDMI version - 1.4/2.0
Ports & interfaces - Headphone connectivity - 3.5 mm
Ports & interfaces - Headphone out - Yes
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - Number of upstream ports - 1
Ports & interfaces - Number of USB Type-C upstream ports quantity - 1
Ports & interfaces - USB Power Delivery - Yes
Ports & interfaces - USB Power Delivery up to - 65 W
Ports & interfaces - USB upstream port type - USB Type-C
Power - AC input frequency - 50 - 60 Hz
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (HDR) per 1000 hours - 62 kWh
Power - Energy consumption (SDR) per 1000 hours - 31 kWh
Power - Energy efficiency class (HDR) - G
Power - Energy efficiency class (SDR) - F
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 1271773
Power - Input current - 2 A
Power - Input current - 2.5 A
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 31 W
Power - Power supply type - Internal
producerCode - DW3401
productName - AG Neovo DW3401 LED display 86.4 cm (34") 3440 x 1440 pixels UltraWide Quad HD Black
ProductName - DW3401
productSize - Normal
ShortSummaryDescription - AG Neovo DW3401, 86.4 cm (34"), 3440 x 1440 pixels, UltraWide Quad HD, LED, 5 ms, Black
sizeX - 500
sizeY - 220
sizeZ - 960
Stck_Kart - 1
Stck_Pal - 4
Storno - Y
Sustainability - Sustainability certificates - CE
Sustainability - Sustainability certificates - Low Voltage Directive (LVD)
Sustainability - Sustainability certificates - REACH
Sustainability - Sustainability certificates - RoHS
Sustainability - Sustainability certificates - WEEE
Sustainability - Sustainability compliance - Yes
Title - AG Neovo DW3401 LED display 86.4 cm (34") 3440 x 1440 pixels UltraWide Quad HD Black
URL - https://www.agneovo.com/global/monitors/desktop/dw-series/dw3401
WarrantyInfo -
warrantyLength - 24
warrantyType - G
weight - 10000
Weight & dimensions - Depth (without stand) - 59.8 mm
Weight & dimensions - Depth (with stand) - 218.8 mm
Weight & dimensions - Height (without stand) - 362.5 mm
Weight & dimensions - Height (with stand) - 560.6 mm
Weight & dimensions - Weight (without stand) - 7.6 kg
Weight & dimensions - Weight (with stand) - 11.1 kg
Weight & dimensions - Width (without stand) - 817 mm
Weight & dimensions - Width (with stand) - 817 mm
