AG NEOVO DR-24G DENTAL MONITOR, 23.8"

Name: AG NEOVO DR-24G DENTAL MONITOR, 23.8"
Brand: AG NEOVO
SKU: 866869
Price: 1207.59 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 866869 Product code: DR24G0A1E0100

Can be ordered 9 units Availability: 14 days after order approval

Warranty: 2 years (Warranty for business entities 1 year)

Compare

Delivery options

Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
Courier delivery 11.99 €: 23.12.2024

Main product parameters All parameters

Curved: Nav
Panel Type: VA
Refresh rate: 75 Hz
Response time: 5ms
Contrast ratio: N/A
Brightness: 250cd/m2
Size: 23.8"
Resolution: FHD 1920x1080

Description

We offer to buy AG NEOVO 23.8" a monitor with FHD 1920x1080 resolution.

The compatibility with the modern graphics cards and video players will be ensured by HDMI input.
DisplayPort port ensures the receipt of a higher quality picture from the computer graphics card supporting this technology.
The port DVI ensures the compatibility with the classic video cards equipped with this port.
The port D-SUB supports graphics cards with the preceding generation analogous VGA plug-in and the comparatively newer generation DVI-I standard using a transition DVI-I -> D-Sub.
VA panel provides high colour compatibility parameters and improved viewing angle to this monitor.
The speakers system built in the monitor allows to listen to music and enjoy films with sound without making it necessary to buy additional speakers.
Thanks to the 5ms fast response time this monitor will be an excellent choice for enjoying dynamic games and films.

Display characteristics

AMD FreeSync : Nav

Curved : Nav

NVIDIA G-SYNC : Nav

Panel Type VA

Teh monitor panel is the main feature of the visible part of the screen or the technology where the display of the colour dots (pixels) is implemented.

TN is the standard technology with average contract, brightness and colour compliance indices.

IPS is the matrix with high colour compliance and good response speed, therefore it is well suited for graphics tasks and photo editing. IPS matrix provide an excellent viewing angle maintaining the colours and contrast from almost any angle.

VA matrix ensures superior colour compliance, however, the response time of this matrix is lagging behind that of the IPS and TN; the viewing angle is somewhere between both these technologies.

The TN type monitor is fully sufficient for an average user. If you have more money available the VA or IPS can be chosen.

Refresh rate : 75 Hz

Touchscreen : NO

VESA DisplayHDR : Nav

Response time 5ms

The response time of the monitor screen determines how fast the monitor will display moving images (films, games, animations, etc.). The response time is measured in miliseconds. The less the response time the better the ability of the monitor to display moving images.
www.toppc.fi recommends to buy monitors with 5ms response time or lower.

Contrast ratio N/A

Ekrāna kontrasts nosaka attēla asumu. Tā ir atšķirība starp vistumšāko (pilnīgi melnu) un visgaišāko (pilnīgi baltu) pikseli. Jo lielāks kontrasts, jo skaidrāk salasāms teksts uz ekrāna, kontrasts arī nosaka, cik izteiksmīgas līnijas būs redzamas monitora attēlā.

Augsts kontrasts ir nozīmīgs faktors izvēloties monitoru biroja, vai mācību vajadzībām, kad lielākoties tiek strādāts ar tekstuālu informāciju.

Mājas vajadzībām svarīgāks izvēles rādītājs ir gaišums un attēla reakcijas laiks. Kontrastu labāk novērtēt tumšā istabā.
Lielākais LCD monitoru trūkums ir tas, ka samazinot attēla spilgtumu, kontrasts var pazust.

Brightness 250cd/m2

Monitora gaišums ir attēla redzamības rādītājs, kas nosaka, cik labi saskatāms ir attēls pie spēcīga ārējā apgaismojuma (saules gaisma, gaiša telpa, utt.). LCD monitoru gaišums tiek mērīts kandelās uz kvadrātmetru (Cd/m2).
Izvēloties monitoru jāņem vērā - jo lielāks gaišuma rādītājs, jo labāka attēla redzamība.

Ikdienas vajadzībām TopPC.fi iesaka iegādāties monitoru ar gaišumu, ne mazāku par 250 cd/m2.

Basic information

Application : Home & Office

Aspect ratio : 16:9

Color : White

Size 23.8"

The size of the monitor screen is measured in inches across the diagonal. The screen size must be proportionate to the resolution of the screen for achieving the maximum utilisation of the desktop and details of the image.

Mainly two forms of LCD monitors are available: with standard width and height proportion 4:3 or the widescreen proportion 16:9 or 16:10. A widescreen monitor is wider and its resolution is higher than that of the monitors with standard proportion.

The bigger the monitor size the higher resolution usually is supported. Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.

Resolution FHD 1920x1080

The resolution of the monitor screen determines the number of colour dots (pixels) a monitor can display. It refers to the clarity of the text and images displayed on the screen. The higher the resolution the sharper the items look.

The applied resolution depends on the resolution supported by the monitor. LCD monitors, including the screens of laptop computers usually work best if their local resolution has been set. The setting of this resolution for the monitor is not mandatory, but usually it is recommended to set it for ensuring the highest possible sharpness of texts and images. The bigger the monitor size the higher resolution usually is supported.

Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.
• 19 inches screen (standard proportions): 1280x1024 pixels
• 20 inches screen (standard proportions): 1600x1200 pixels
• 22 inches screen (widescreen): 1680x1050 pixels
• 24 inches screen (widescreen): 1900x1200 pixels

Functionality

Flicker-free : Ir

Height adjustment : Nav

Pivot : Nav

Swivel : None

Tilt : NO

VESA wall mount : 100x100 mm

Ports and equipment

D-SUB 1

D-SUB is the classic (analogous) monitor connection plug. This standard is gradually disappearing from the market giving the place to the higher quality HDMI or DisplayPort (digital) plugs.

If the resolution of the monitor is FullHD or below the average user will experience no problems with this connection. Those who want to achieve higher image quality and resolution should look for the monitor with the DisplayPort or HDMI connection slot.

DisplayPort 1

DisplayPort is the digital connection for transmitting the image via a single wire at a high quality level. Contrary to the HDMI, this connection allows to connect several external monitors to the computer via a single connector.

Prior to buying the monitor with the DisplayPort you should verify whether your computer has the DisplayPort plug available!

DVI 1

DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.

DVI is compatible with HDMI and transitions of both directions are available.

DVI is not compatible with DisplayPort, however, there are DualMode DisplayPort connectors which contains the HDMI/DVI signal, and in the relevant direction DisplayPort -> DVI can transmit an image.

If the monitor resolution exceeds 1920px in any direction a graphics card with the DVI-D Dual Link support and the relevant quality cable will be required.

Before buying a monitor you should verify whether your graphics card has the corresponding connection slot!

HDMI port 1

HDMI is the digital high quality image transmission standard that allows to connect the monitor to the computer via a thin cable by using an elegant small-size connector. HDMI is compatible with DVI if the relevant transition or cable is used.

Speakers Ir

Some monitors may have built-in speakers that quite often allow to give up external speakers thus freeing a space on the desk and saving money. The sound quality of built-in speakers is quite moderate and therefore we recommend to use this possibility just for infrequent needs.

For enjoying music, movies and games we recommend buying the corresponding quality and capacity speakers.

USB Hub : NO

USB-C Power Delivery : Nav

USB-C video input : 0

More detailed specification

Additional information in manufacturers website AG NEOVO DR-24G DENTAL MONITOR, 23.8"

ARTIKEL1 - DR-24G DENTAL MONITOR
ARTIKEL2 - 23.8IN 1920X1080 LED-BACKLIT
Brand - AG Neovo
BrandPartCode - DR24G0A1E0100
Breite - 0
Category - Computer Monitors
Design - Front bezel colour - White
Design - Glass thickness - 3 mm
Design - Housing material - Metal
Design - Market positioning - Medical
Design - Product colour - White
Display - Anti-glare screen - Yes
Display - Aspect ratio - 16:9
Display - Backlight type - LED
Display - Colour gamut standard - NTSC
Display - Contrast ratio (dynamic) - 20000000:1
Display - Digital horizontal frequency - 24 - 83 kHz
Display - Digital vertical frequency - 50 - 75 Hz
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 60.5 cm (23.8")
Display - Display diagonal (metric) - 60 cm
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LCD
Display - Haze rate - 40%
Display - HD type - Full HD
Display - Maximum refresh rate - 75 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 72%
Display - Panel type - VA
Display - Pixel pitch - 0.274 x 0.274 mm
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Surface hardness - 3H
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 4710739597332
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Height adjustment - No
Ergonomics - Panel mounting interface - 75 x 75,100 x 100 mm
Ergonomics - Picture-in-Picture - Yes
Ergonomics - VESA mounting - Yes
Ergonomics - X-ray film viewing mode - Yes
GRUPPE1 - Displays
GRUPPE2 - Led Small Format
GTIN - 4710739597332
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0
HSTNUMMER - DR24G0A1E0100
Laenge - 0
LongDesc - DR-24GThe AG Neovo DR-24G is a 24-inch dental monitor that features a quick switch to X-ray illuminator mode for dental X-ray film viewing without using another X-ray view box. With advanced gamma correction, black-level alignment adjustability, and high contrast ratio, the dentists can verify the patient’s condition of teeth, jaw placement, and facial bone before dental treatment. The NeoV™ Optical Hard Glass Screen and white metal casing design meet an array of medical level cleaning requirements, allowing dental professionals to clean and sanitise the monitors.EASY CLEAN AND ROBUST PROTECTIONThe special design of NeoV™ Optical Hard Glass and white metal casing prevent dust and waterproof for easy clean and robust protection.QUICK SWITCH TO X-RAY VIEWING MODEThe DR-24G 24-inch dental monitor integrates hotkey operation to switch X-ray viewing mode without using another X-ray view box.DC 24V MEDICAL-GRADE POWER ADAPTER FOR A LONGER DISTANCE CONNECTIONDesigned with DC 24V power supply, it is ideal for long-distance (up to 5 meters) cable management between dental equipment and displays. The medical power supply with IEC / EN60601-1 certified ensures safety, performance, and reliable operation in any professional medical environment.PIP/PBP SUPPORTPiP/PbP functions enable viewing and comparing two images simultaneously from different sources and enhance work efficiency for multitasking.GREAT MOBILITYThis 24-inch dental monitor meets VESA 75mm/100mm wall mount standard and optional handle for flexible installation and operation on the dental chair.
LongProductName - DR-24G, 24", 1920 x 1080p, Full HD, 250 cd/m2, 16.7M, Dental Monitor, NeoV Optical Glass, IEC / EN60601-1, White
LongSummaryDescription - AG Neovo DR-24G. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: White
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 4 W
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - CE, Low Voltage Directive (LVD), REACH, RoHS, WEEE
Other features - Display surface reflectivity (typical) - 1%
Other features - Glass screen - NeoV Optical
Other features - Light sensor - Yes
Other features - Picture-by-Picture (PbP) - Yes
Other features - Protection features - Dust resistant, Waterproof
Other features - Transmission rate - > 97%
Packaging content - Cables included - AC, Audio (3.5mm), VGA
Packaging content - Power adapter included - Yes
Packaging content - Power cable length - 5 m
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 249 mm
Packaging data - Package height - 517 mm
Packaging data - Package type - Box
Packaging data - Package weight - 10.6 kg
Packaging data - Package width - 672 mm
Packaging data - Warranty card - Yes
Performance - AMD FreeSync - No
Performance - Flicker-free technology - Yes
Performance - NVIDIA G-SYNC - No
Ports & interfaces - Audio input - Yes
Ports & interfaces - Audio output - Yes
Ports & interfaces - Audio RCA outputs - 1
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - Composite video in - 2
Ports & interfaces - Composite video out - 2
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DVI-D ports quantity - 1
Ports & interfaces - DVI port - Yes
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - Micro HDMI ports quantity - 1
Ports & interfaces - PC Audio in - Yes
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - S-Video inputs quantity - 1
Ports & interfaces - USB Type-A downstream ports quantity - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC adapter output voltage - 24 V
Power - Energy consumption (SDR) per 1000 hours - 18 kWh
Power - Energy efficiency class (SDR) - E
Power - Energy efficiency scale - A to G
Power - Input current - 2.71 A
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 18 W
Power - Power supply type - External
ProductName - DR-24G
ShortSummaryDescription - AG Neovo DR-24G, 60.5 cm (23.8"), 1920 x 1080 pixels, Full HD, LCD, 5 ms, White
Stck_Kart - 1
Stck_Pal - 5
Storno - Y
Sustainability - Sustainability compliance - Yes
Title - AG Neovo DR-24G LED display 60.5 cm (23.8") 1920 x 1080 pixels Full HD LCD White
URL - https://www.agneovo.com/global/monitors/healthcare/dr-series/dr-24g
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 56.2 mm
Weight & dimensions - Height (without stand) - 352.6 mm
Weight & dimensions - Weight (without stand) - 7.4 kg
Weight & dimensions - Width (without stand) - 562.4 mm
