AG NEOVO TX-1502, 15"

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 695776 Product code: TX152011E0100
Can be ordered 18 units Availability: 14 days after order approval
Warranty: 2 years (Warranty for business entities 1 year)
670.29 €
Delivery options
  • Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
  • Courier delivery 11.99 €: 23.12.2024
Main product parameters All parameters
  • Curved: Nav
  • Panel Type: VA
  • Refresh rate: 75 Hz
  • Response time: 5ms
  • Contrast ratio: 800:1
  • Brightness: 350cd/m2
  • Size: 15"
  • Resolution: WXGA 1024x768
Description
We offer to buy AG NEOVO 15" a monitor with WXGA 1024x768 resolution.
  • The compatibility with the modern graphics cards and video players will be ensured by HDMI input.
  • DisplayPort port ensures the receipt of a higher quality picture from the computer graphics card supporting this technology.
  • The port D-SUB supports graphics cards with the preceding generation analogous VGA plug-in and the comparatively newer generation DVI-I standard using a transition DVI-I -> D-Sub.
  • VA panel provides high colour compatibility parameters and improved viewing angle to this monitor.
  • 5ms fast response time makes this monitor perfectly suitable for enjoying computer games and dynamic films.
Display characteristics
AMD FreeSync : Nav
Curved : Nav
NVIDIA G-SYNC : Nav
Panel Type VA

Teh monitor panel is the main feature of the visible part of the screen or the technology where the display of the colour dots (pixels) is implemented.

TN is the standard technology with average contract, brightness and colour compliance indices.

IPS is the matrix with high colour compliance and good response speed, therefore it is well suited for graphics tasks and photo editing. IPS matrix provide an excellent viewing angle maintaining the colours and contrast from almost any angle.

VA matrix ensures superior colour compliance, however, the response time of this matrix is lagging behind that of the IPS and TN; the viewing angle is somewhere between both these technologies.

The TN type monitor is fully sufficient for an average user. If you have more money available the VA or IPS can be chosen.

Refresh rate : 75 Hz
Touchscreen : YES
VESA DisplayHDR : Nav
Response time 5ms
The response time of the monitor screen determines how fast the monitor will display moving images (films, games, animations, etc.). The response time is measured in miliseconds. The less the response time the better the ability of the monitor to display moving images.
www.toppc.fi recommends to buy monitors with 5ms response time or lower.
Contrast ratio 800:1

Ekrāna kontrasts nosaka attēla asumu. Tā ir atšķirība starp vistumšāko (pilnīgi melnu) un visgaišāko (pilnīgi baltu) pikseli. Jo lielāks kontrasts, jo skaidrāk salasāms teksts uz ekrāna, kontrasts arī nosaka, cik izteiksmīgas līnijas būs redzamas monitora attēlā.

Augsts kontrasts ir nozīmīgs faktors izvēloties monitoru biroja, vai mācību vajadzībām, kad lielākoties tiek strādāts ar tekstuālu informāciju.

Mājas vajadzībām svarīgāks izvēles rādītājs ir gaišums un attēla reakcijas laiks. Kontrastu labāk novērtēt tumšā istabā.
Lielākais LCD monitoru trūkums ir tas, ka samazinot attēla spilgtumu, kontrasts var pazust.

Brightness 350cd/m2

Monitora gaišums ir attēla redzamības rādītājs, kas nosaka, cik labi saskatāms ir attēls pie spēcīga ārējā apgaismojuma (saules gaisma, gaiša telpa, utt.). LCD monitoru gaišums tiek mērīts kandelās uz kvadrātmetru (Cd/m2).
Izvēloties monitoru jāņem vērā - jo lielāks gaišuma rādītājs, jo labāka attēla redzamība.

Ikdienas vajadzībām TopPC.fi iesaka iegādāties monitoru ar gaišumu, ne mazāku par 250 cd/m2.

Basic information
Application : Home & Office
Aspect ratio : 4:3
Color : Gray
Size 15"

The size of the monitor screen is measured in inches across the diagonal. The screen size must be proportionate to the resolution of the screen for achieving the maximum utilisation of the desktop and details of the image.

Mainly two forms of LCD monitors are available: with standard width and height proportion 4:3 or the widescreen proportion 16:9 or 16:10. A widescreen monitor is wider and its resolution is higher than that of the monitors with standard proportion.

The bigger the monitor size the higher resolution usually is supported. Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.

Resolution WXGA 1024x768

The resolution of the monitor screen determines the number of colour dots (pixels) a monitor can display. It refers to the clarity of the text and images displayed on the screen. The higher the resolution the sharper the items look.

The applied resolution depends on the resolution supported by the monitor. LCD monitors, including the screens of laptop computers usually work best if their local resolution has been set. The setting of this resolution for the monitor is not mandatory, but usually it is recommended to set it for ensuring the highest possible sharpness of texts and images. The bigger the monitor size the higher resolution usually is supported.

Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.
• 19 inches screen (standard proportions): 1280x1024 pixels
• 20 inches screen (standard proportions): 1600x1200 pixels
• 22 inches screen (widescreen): 1680x1050 pixels
• 24 inches screen (widescreen): 1900x1200 pixels

Functionality
Flicker-free : Nav
Height adjustment : Nav
Pivot : Nav
Swivel : And
Tilt : YES
VESA wall mount : 100x100 mm
Ports and equipment
D-SUB 1

D-SUB is the classic (analogous) monitor connection plug. This standard is gradually disappearing from the market giving the place to the higher quality HDMI or DisplayPort (digital) plugs.

If the resolution of the monitor is FullHD or below the average user will experience no problems with this connection. Those who want to achieve higher image quality and resolution should look for the monitor with the DisplayPort or HDMI connection slot.

DisplayPort 1

DisplayPort is the digital connection for transmitting the image via a single wire at a high quality level. Contrary to the HDMI, this connection allows to connect several external monitors to the computer via a single connector.

Prior to buying the monitor with the DisplayPort you should verify whether your computer has the DisplayPort plug available!

DVI Nav

DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.

DVI is compatible with HDMI and transitions of both directions are available.

DVI is not compatible with DisplayPort, however, there are DualMode DisplayPort connectors which contains the HDMI/DVI signal, and in the relevant direction DisplayPort -> DVI can transmit an image.

If the monitor resolution exceeds 1920px in any direction a graphics card with the DVI-D Dual Link support and the relevant quality cable will be required.

Before buying a monitor you should verify whether your graphics card has the corresponding connection slot!

HDMI port 1

HDMI is the digital high quality image transmission standard that allows to connect the monitor to the computer via a thin cable by using an elegant small-size connector. HDMI is compatible with DVI if the relevant transition or cable is used.

Speakers Nav

Some monitors may have built-in speakers that quite often allow to give up external speakers thus freeing a space on the desk and saving money. The sound quality of built-in speakers is quite moderate and therefore we recommend to use this possibility just for infrequent needs.

For enjoying music, movies and games we recommend buying the corresponding quality and capacity speakers.

USB Hub : NO
USB-C Power Delivery : Nav
USB-C video input : 0
More detailed specification
Additional information in manufacturers website AG NEOVO TX-1502, 15"
ARTIKEL1 - TX-1502 LED-BACKLIT TFT LCD
ARTIKEL2 - 15IN 1024X768 250CD 700:01:00
Brand - AG Neovo
BrandPartCode - TX152011E0100
Category - Computer Monitors
Design - Detachable stand - Yes
Design - Glass thickness - 3.1 mm
Design - Housing material - Metal
Design - Market positioning - Business
Design - Product colour - Grey
Display - Anti-glare screen - Yes
Display - Backlight type - LED
Display - Colour gamut standard - NTSC
Display - Contrast ratio (typical) - 800:1
Display - Display brightness (typical) - 350 cd/m²
Display - Display diagonal - 38.1 cm (15")
Display - Display diagonal (metric) - 38.1 cm
Display - Display number of colours - 16.78 million colours
Display - Display resolution - 1024 x 768 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - XGA
Display - Horizontal scan range - 31 - 61 kHz
Display - Native aspect ratio - 4:3
Display - NTSC coverage (typical) - 60%
Display - Number of simultaneous touchpoints - 10
Display - Panel type - VA
Display - Pixel pitch - 0.297 x 0.297 mm
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Surface hardness - 7H
Display - Touchscreen - Yes
Display - Touchscreen technology - Projected capacitive system
Display - Touchscreen type - Tabletop
Display - Touch technology - Multi-touch
Display - Vertical scan range - 55 - 75 Hz
Display - Viewing angle, horizontal - 160°
Display - Viewing angle, vertical - 150°
EANCode - 4710739597257
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Height adjustment - No
Ergonomics - LED indicators - Yes
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 90°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
GRUPPE1 - Displays
GRUPPE2 - Lcd Touchscreen
GTIN - 4710739597257
HERSTELLER - AG NEOVO TECHNOLOGY
HSTNUMMER - TX152011E0100
Logistics data - Harmonized System (HS) code - 85285210
LongDesc - AG Neovo TX-Series touch screen monitors, available in sizes 15” to 22”, provide a smooth and responsive touch experience with 10-point PCAP touch screens, including responsiveness to latex gloves. With DisplayPort, HDMI and VGA input connectivity, the TX-Series support analogue and digital signals respectively, making them flexible for various applications such as factory automation, information displays, digital signage, and self-service kiosks. These touch screen monitors are complemented by a metal housing with an edge-to-edge tempered glass design which enhances durability for continuous operation in demanding and high-traffic areas.Premium PCAP Multi Touch ScreenBased on projected capacitive (PCAP) touch screen technology, AG Neovo touch screen monitors can register up to 10 simultaneous touch points with fast, accurate, and extremely sensitive touch response. These seamless touch senses are identical to those used in smartphones and tablets.Cross-Platform Touch CapabilityMulti-Touch capability is optimized to work with various operating systems, providing compatibility with Windows, Linux, macOS, and certain Android versions. This enables more choice to the operating system you use.IP65 Dust and Water ProtectionThe TX-Series front IP65 touch screen monitors are designed to protect against dust and liquid spills. This makes these durable touch monitors ideal for the industrial workplace or the demanding, high-use, and high-traffic public locations. Consistent Form Factor DesignReplacing AG Neovo touch screens never requires users to change their whole infrastructure. This is because AG Neovo offers a consistent form factor and long product life cycles. Even as technology advances, no change is made to exterior dimensions or design.Durable and Scratch Resistant Touch ScreenFor 24/7 operations in public settings, AG Neovo uses metal housing and 7H tempered glass displays to offer high durability and scratch resistance levels, all without compromising touch sensitivity.Ergonomic Monitors with Flexible MountingTX-Series touch monitors offer flexible mounting options, from the ergonomic monitor stands that come with the monitors to desk mounts, wall mounts, and all monitor mounts feature VESA mounting patterns. These ergonomic monitors feature adjustable tilt stands. With a tilt capacity ranging from -5 to 90 degrees, users can work in the position most comfortable for them. Tilt stands are beneficial for facilitating public access by non-disabled and disabled users.Versatile ConnectivityThe TX-Series provides new and legacy systems the best of both worlds since it has both analog (VGA) and digital (DisplayPort and HDMI) video inputs, which provide maximum versatility and facilitate users to connect to a variety of devices.
LongProductName - 15" LED-Backlit TFT LCD (TN) Touch Screen, 1024 x 768, 350 cd/m², 800:1, 5 ms, DisplayPort, HDMI, VGA, RJ-11, 24/7, IP65
LongSummaryDescription - AG Neovo TX-1502. Display diagonal: 38.1 cm (15"), Display resolution: 1024 x 768 pixels, HD type: XGA, Display technology: LED, Response time: 5 ms, Native aspect ratio: 4:3, Viewing angle, horizontal: 160°, Viewing angle, vertical: 150°. VESA mounting. Product colour: Grey
Multimedia - Built-in camera - No
Multimedia - Built-in microphone - No
Multimedia - Built-in speaker(s) - No
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Certification - CE, LVD, WEEE, RoHS, REACH,EAC
Other features - Compliance certificates - CE, REACH, RoHS, WEEE
Other features - International Protection (IP) code - IP65
Other features - Mobile operating systems supported - Android
Packaging content - Cables included - AC, HDMI, USB, VGA
Packaging content - Stand included - Yes
Packaging data - Package depth - 290 mm
Packaging data - Package height - 370 mm
Packaging data - Package weight - 7 kg
Packaging data - Package width - 415 mm
Performance - AMD FreeSync - No
Performance - Linux operating systems supported - Yes
Performance - Mac operating systems supported - Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Performance - NVIDIA G-SYNC - No
Performance - Operating hours (hours/days) - 24/7
Performance - Operating system installed - Windows 10
Performance - Windows operating systems supported - Windows 10, Windows 7, Windows 8
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - USB Touch port - Yes
Ports & interfaces - USB Touch ports quantity - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC adapter output voltage - 12 V
Power - European Product Registry for Energy Labelling (EPREL) code - 456259
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.6 W
Power - Power consumption (typical) - 8 W
Power - Power supply type - External
ProductName - TX-1502
ShortSummaryDescription - AG Neovo TX-1502, 38.1 cm (15"), 1024 x 768 pixels, XGA, LED, 5 ms, Grey
Stck_Kart - 1
Stck_Pal - 15
Storno - Y
Sustainability - Sustainability compliance - Yes
Title - AG Neovo TX-1502 computer monitor 38.1 cm (15") 1024 x 768 pixels XGA LED Touchscreen Tabletop Grey
URL - https://displays.agneovo.com/gl/products/tx-series-advanced/17517-tx-1502
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 46.6 mm
Weight & dimensions - Depth (with stand) - 214.2 mm
Weight & dimensions - Height (without stand) - 276.4 mm
Weight & dimensions - Height (with stand) - 312.7 mm
Weight & dimensions - Weight (without stand) - 2.7 kg
Weight & dimensions - Weight (with stand) - 4.6 kg
Weight & dimensions - Width (without stand) - 348.4 mm
Weight & dimensions - Width (with stand) - 348.4 mm
