Iiyama T2454MSC-B1, 23.8"

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 350531 Product code: T2454MSC-B1AG
In stock 10 units
Warranty: 3 years
427.10 €
Delivery options
  • Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
  • Courier delivery 11.99 €: 03.12.2024
Main product parameters All parameters
  • Curved: Nav
  • Panel Type: IPS
  • Refresh rate: 75 Hz
  • Response time: 4ms
  • Contrast ratio: 1000:1
  • Brightness: 250cd/m2
  • Size: 23.8"
  • Resolution: FHD 1920x1080
Description
We offer to buy Iiyama 23.8" a monitor with FHD 1920x1080 resolution.
  • Thanks to FullHD (1920px X 1080px) resolution this monitor will be perfectly suitable for enjoying BlueRay quality films in the full screen mode.
  • IPS matrix for this monitor provides high colour correspondence parameters, superior picture contrast and good visibility from eventually all viewing angles.
  • The compatibility with the modern graphics cards and video players will be ensured by HDMI input.
  • The port D-SUB supports graphics cards with the preceding generation analogous VGA plug-in and the comparatively newer generation DVI-I standard using a transition DVI-I -> D-Sub.
  • The speakers system built in the monitor allows to listen to music and enjoy films with sound without making it necessary to buy additional speakers.
  • Thanks to the 4ms fast response time this monitor will be an excellent choice for enjoying dynamic games and films.
Display characteristics
AMD FreeSync : Nav
Curved : Nav
NVIDIA G-SYNC : Nav
Panel Type IPS

Teh monitor panel is the main feature of the visible part of the screen or the technology where the display of the colour dots (pixels) is implemented.

TN is the standard technology with average contract, brightness and colour compliance indices.

IPS is the matrix with high colour compliance and good response speed, therefore it is well suited for graphics tasks and photo editing. IPS matrix provide an excellent viewing angle maintaining the colours and contrast from almost any angle.

VA matrix ensures superior colour compliance, however, the response time of this matrix is lagging behind that of the IPS and TN; the viewing angle is somewhere between both these technologies.

The TN type monitor is fully sufficient for an average user. If you have more money available the VA or IPS can be chosen.

Refresh rate : 75 Hz
Touchscreen : YES
VESA DisplayHDR : Nav
Response time 4ms
The response time of the monitor screen determines how fast the monitor will display moving images (films, games, animations, etc.). The response time is measured in miliseconds. The less the response time the better the ability of the monitor to display moving images.
www.toppc.fi recommends to buy monitors with 5ms response time or lower.
Contrast ratio 1000:1

Ekrāna kontrasts nosaka attēla asumu. Tā ir atšķirība starp vistumšāko (pilnīgi melnu) un visgaišāko (pilnīgi baltu) pikseli. Jo lielāks kontrasts, jo skaidrāk salasāms teksts uz ekrāna, kontrasts arī nosaka, cik izteiksmīgas līnijas būs redzamas monitora attēlā.

Augsts kontrasts ir nozīmīgs faktors izvēloties monitoru biroja, vai mācību vajadzībām, kad lielākoties tiek strādāts ar tekstuālu informāciju.

Mājas vajadzībām svarīgāks izvēles rādītājs ir gaišums un attēla reakcijas laiks. Kontrastu labāk novērtēt tumšā istabā.
Lielākais LCD monitoru trūkums ir tas, ka samazinot attēla spilgtumu, kontrasts var pazust.

Brightness 250cd/m2

Monitora gaišums ir attēla redzamības rādītājs, kas nosaka, cik labi saskatāms ir attēls pie spēcīga ārējā apgaismojuma (saules gaisma, gaiša telpa, utt.). LCD monitoru gaišums tiek mērīts kandelās uz kvadrātmetru (Cd/m2).
Izvēloties monitoru jāņem vērā - jo lielāks gaišuma rādītājs, jo labāka attēla redzamība.

Ikdienas vajadzībām TopPC.fi iesaka iegādāties monitoru ar gaišumu, ne mazāku par 250 cd/m2.

Basic information
Application : Home & Office
Aspect ratio : 16:9
Color : Black
Size 23.8"

The size of the monitor screen is measured in inches across the diagonal. The screen size must be proportionate to the resolution of the screen for achieving the maximum utilisation of the desktop and details of the image.

Mainly two forms of LCD monitors are available: with standard width and height proportion 4:3 or the widescreen proportion 16:9 or 16:10. A widescreen monitor is wider and its resolution is higher than that of the monitors with standard proportion.

The bigger the monitor size the higher resolution usually is supported. Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.

Resolution FHD 1920x1080

The resolution of the monitor screen determines the number of colour dots (pixels) a monitor can display. It refers to the clarity of the text and images displayed on the screen. The higher the resolution the sharper the items look.

The applied resolution depends on the resolution supported by the monitor. LCD monitors, including the screens of laptop computers usually work best if their local resolution has been set. The setting of this resolution for the monitor is not mandatory, but usually it is recommended to set it for ensuring the highest possible sharpness of texts and images. The bigger the monitor size the higher resolution usually is supported.

Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.
• 19 inches screen (standard proportions): 1280x1024 pixels
• 20 inches screen (standard proportions): 1600x1200 pixels
• 22 inches screen (widescreen): 1680x1050 pixels
• 24 inches screen (widescreen): 1900x1200 pixels

Functionality
Flicker-free : Nav
Height adjustment : Ir
Pivot : Ir
Swivel : None
Tilt : YES
VESA wall mount : 100x100 mm
Ports and equipment
D-SUB 1

D-SUB is the classic (analogous) monitor connection plug. This standard is gradually disappearing from the market giving the place to the higher quality HDMI or DisplayPort (digital) plugs.

If the resolution of the monitor is FullHD or below the average user will experience no problems with this connection. Those who want to achieve higher image quality and resolution should look for the monitor with the DisplayPort or HDMI connection slot.

DisplayPort Nav

DisplayPort is the digital connection for transmitting the image via a single wire at a high quality level. Contrary to the HDMI, this connection allows to connect several external monitors to the computer via a single connector.

Prior to buying the monitor with the DisplayPort you should verify whether your computer has the DisplayPort plug available!

DVI Nav

DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.

DVI is compatible with HDMI and transitions of both directions are available.

DVI is not compatible with DisplayPort, however, there are DualMode DisplayPort connectors which contains the HDMI/DVI signal, and in the relevant direction DisplayPort -> DVI can transmit an image.

If the monitor resolution exceeds 1920px in any direction a graphics card with the DVI-D Dual Link support and the relevant quality cable will be required.

Before buying a monitor you should verify whether your graphics card has the corresponding connection slot!

HDMI port 1

HDMI is the digital high quality image transmission standard that allows to connect the monitor to the computer via a thin cable by using an elegant small-size connector. HDMI is compatible with DVI if the relevant transition or cable is used.

Speakers Ir

Some monitors may have built-in speakers that quite often allow to give up external speakers thus freeing a space on the desk and saving money. The sound quality of built-in speakers is quite moderate and therefore we recommend to use this possibility just for infrequent needs.

For enjoying music, movies and games we recommend buying the corresponding quality and capacity speakers.

USB Hub : YES
USB-C Power Delivery : Nav
USB-C video input : 0
More detailed specification
Additional information in manufacturers website Iiyama T2454MSC-B1, 23.8"
ARTIKEL1 - T2454MSC-B1AG 60.5CM 24IN IPS
ARTIKEL2 - 1920X1080 250CD 10TP PCAP
Brand - iiyama
BrandPartCode - T2454MSC-B1AG
Breite - 0.41
Category - Computer Monitors
Category - Root/Electronics/PC peripherals/Monitors
Category 1 - Displays
Category 2 - Monitore
Category_1 - Monitors and TV
Category_2 - LED Monitors up to 24 inches
Design - Product colour - Black
Display - Aspect ratio - 16:9
Display - Contrast ratio (dynamic) - 5000000:1
Display - Contrast ratio (typical) - 1000:1
Display - Display brightness - 250 cd/m²
Display - Display diagonal - 60.5 cm (23.8")
Display - Display diagonal (metric) - 60.5 cm
Display - Display number of colours - 16.78 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - HD type - Full HD
Display - Horizontal scan range - 30 - 80 kHz
Display - LED backlight - Yes
Display - Native aspect ratio - 16:9
Display - Number of simultaneous touchpoints - 10
Display - Panel type - IPS
Display - Pixel pitch - 0.274 x 0.274 mm
Display - Response time - 4 ms
Display - Screen shape - Flat
Display - Supported graphics resolutions - 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Display - Touchscreen - Yes
Display - Touchscreen technology - Projected capacitive system
Display - Touchscreen type - Multi-user
Display - Touch technology - Multi-touch
Display - Vertical scan range - 56 - 75 Hz
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EAN - 4948570116416
EANCode - 4948570116416
Eans - 4948570116416
EAN_code - 4948570116416
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Height adjustment - 7 cm
Ergonomics - Height adjustment - Yes
Ergonomics - Number of OSD languages - 10
Ergonomics - On Screen Display (OSD) languages - German, Dutch, English, Spanish, French, Italian, Japanese, Polish, Portuguese, Russian
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 90°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
Gewicht - 7.14
GRUPPE1 - Displays
GRUPPE2 - Lcd Touchscreen
GTIN - 4948570116416
HERSTELLER - IIYAMA CONSIGNMENT
Hoehe - 0.18
HSTNUMMER - T2454MSC-B1AG
Laenge - 0.61
Logistics data - Harmonized System (HS) code - 85285210
LongDesc - 24” P-CAP 10pt touch screen featuring IPS panel technology and Anti Glare coatingWith its Full HD (1920x1080) resolution and accurate Projective Capacitive 10 point touch technology, the ProLite T2454MSC-B1AG delivers seamless and accurate touch response. Featuring IPS LCD screen technology, it offers exceptional colour performance and wide viewing angels, making it a perfect choice for a vast array of interactive applications. The Anti Glare coating helps to avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness. Its flexible stand can be positioned at several angles creating a comfortable and ergonomic user experience. The ProLite T2454MSC-B1AG is the ideal solution for interactive signage, instore retail, POS and interactive presentations.TOUCH TECHNOLOGY - CAPACITIVEThis technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.IPSIPS technology offers higher contrast, darker blacks and much better viewing angles than standard TN technology. The screen will look good no matter what angle you look at it.AG COATINGThe Anti Glare coating is used in professional-grade displays to help avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness. It also makes the screen less susceptible to dust, grease and dirt marks.SPEAKERSThis LED monitor is equipped with two high quality stereo speakers.VESAVESA mount compliance means you can easily mount the LFD to any mounting that complies with the VESA standard.
LongProductName - ProLite T2454MSC-B1AG, 23.8", 1920x1080, IPS LED, 16:9, 4 ms, VGA, HDMI, 2x USB 3.0, HDCP, RMS 2x 2W, IPX1, AC 100 - 240V, 50/60Hz, 540.5 x 388 x 128mm
LongSummaryDescription - iiyama ProLite T2454MSC-B1AG. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 4 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting, Height adjustment. Product colour: Black
Manufacturer - Iiyama
Manufacturer - iiyama
Manufacturer_code - T2454MSC-B1AG
MPN - T2454MSC-B1AG
Multimedia - Built-in camera - No
Multimedia - Built-in microphone - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Megapixel (approx.) - 2.1 MP
Multimedia - RMS rated power - 4 W
Name - 24"/60,5cm (1920x1080) iiyama ProLite T2454MSC-B1AG 16:9 5ms Touchscreen VGA USB HDMI VESA Speaker Full HD Black
Name - iiyama ProLite T2454MSC-B1AG - 23,8'' | IPS | Full HD
Name - Iiyama T2454MSC-B1AG - 23.8 -LED - Black, HDMI, Full HD, VGA, speakers
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 5 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Certification - CE, TÜV-Bauart, VCCI-B, EAC, ErP, WEEE, REACH, CB
Other features - Compliance certificates - RoHS
Other features - Dimensions (W x D x H) with stand - 540.5 x 128 x 388 mm
Other features - Display viewable area (HxV) - 527.04 x 296.46 mm
Other features - Full HD - Yes
Other features - International Protection (IP) code - IPX1
Other features - Mean time between failures (MTBF) - 30000 h
Other features - Placement supported - Horizontal/Vertical
Packaging content - Cables included - AC, HDMI, USB, VGA
Packaging content - Quick start guide - Yes
Performance - AMD FreeSync - No
Performance - Linux operating systems supported - Yes
Performance - NVIDIA G-SYNC - No
Performance - OmniTapps Multitouch compatibility - No
Performance - Windows operating systems supported - Yes
Ports & interfaces - Audio input - 3.5mm
Ports & interfaces - HDCP - Yes
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Number of upstream ports - 1
Ports & interfaces - USB Touch port - Yes
Ports & interfaces - USB Type-A downstream ports quantity - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100-240 V
Power - Energy consumption (SDR) per 1000 hours - 20 kWh
Power - Energy efficiency class (SDR) - F
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 366281
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 24 W
Power - Power supply type - AC
Producer - iiyama
ProducerCode - T2454MSC-B1AG
ProductName - T2454MSC-B1AG
ShortDescription - 23,8'' | IPS | Full HD
ShortSummaryDescription - iiyama ProLite T2454MSC-B1AG, 60.5 cm (23.8"), 1920 x 1080 pixels, Full HD, LED, 4 ms, Black
Stck_Kart - 1
Stck_Pal - 30
Storno - Y
Title - iiyama ProLite T2454MSC-B1AG computer monitor 60.5 cm (23.8") 1920 x 1080 pixels Full HD LED Touchscreen Multi-user Black
URL - https://iiyama.com/gl_en/products/prolite-t2454msc-b1ag/
WarrantyInfo - 3 year
Weight - 6.94
Weight - 7,25
Weight & dimensions - Depth (without stand) - 46.5 mm
Weight & dimensions - Depth (with stand) - 128 mm
Weight & dimensions - Height (without stand) - 322.5 mm
Weight & dimensions - Height (with stand) - 388 mm
Weight & dimensions - Weight (with stand) - 5.5 kg
Weight & dimensions - Width (without stand) - 540.5 mm
Weight & dimensions - Width (with stand) - 540.5 mm
