Lenovo ThinkVision S24e-20, 23.8"

Name: Lenovo ThinkVision S24e-20, 23.8"
Brand: Lenovo
SKU: 1188566
Price: 146.7 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 1188566 Product code: 62AEKAR2EU

Can be ordered 92 units Availability: 14 days after order approval

Warranty: 3 years

Compare

Delivery options

Courier delivery 11.99 €: 12.03.2025

Main product parameters All parameters

Curved: Nav
Panel Type: VA
Refresh rate: 60 Hz
Response time: 6ms
Contrast ratio: 3000:1
Brightness: 250cd/m2
Size: 23.8"
Resolution: FHD 1920x1080

Description

We offer to buy Lenovo 23.8" a monitor with FHD 1920x1080 resolution.

The compatibility with the modern graphics cards and video players will be ensured by HDMI input.
The port D-SUB supports graphics cards with the preceding generation analogous VGA plug-in and the comparatively newer generation DVI-I standard using a transition DVI-I -> D-Sub.
VA panel provides high colour compatibility parameters and improved viewing angle to this monitor.

Display characteristics

AMD FreeSync : Ir

Curved : Nav

NVIDIA G-SYNC : Nav

Panel Type VA

Teh monitor panel is the main feature of the visible part of the screen or the technology where the display of the colour dots (pixels) is implemented.

TN is the standard technology with average contract, brightness and colour compliance indices.

IPS is the matrix with high colour compliance and good response speed, therefore it is well suited for graphics tasks and photo editing. IPS matrix provide an excellent viewing angle maintaining the colours and contrast from almost any angle.

VA matrix ensures superior colour compliance, however, the response time of this matrix is lagging behind that of the IPS and TN; the viewing angle is somewhere between both these technologies.

The TN type monitor is fully sufficient for an average user. If you have more money available the VA or IPS can be chosen.

Refresh rate : 60 Hz

Touchscreen : NO

VESA DisplayHDR : Nav

Response time 6ms

The response time of the monitor screen determines how fast the monitor will display moving images (films, games, animations, etc.). The response time is measured in miliseconds. The less the response time the better the ability of the monitor to display moving images.
www.toppc.fi recommends to buy monitors with 5ms response time or lower.

Contrast ratio 3000:1

Ekrāna kontrasts nosaka attēla asumu. Tā ir atšķirība starp vistumšāko (pilnīgi melnu) un visgaišāko (pilnīgi baltu) pikseli. Jo lielāks kontrasts, jo skaidrāk salasāms teksts uz ekrāna, kontrasts arī nosaka, cik izteiksmīgas līnijas būs redzamas monitora attēlā.

Augsts kontrasts ir nozīmīgs faktors izvēloties monitoru biroja, vai mācību vajadzībām, kad lielākoties tiek strādāts ar tekstuālu informāciju.

Mājas vajadzībām svarīgāks izvēles rādītājs ir gaišums un attēla reakcijas laiks. Kontrastu labāk novērtēt tumšā istabā.
Lielākais LCD monitoru trūkums ir tas, ka samazinot attēla spilgtumu, kontrasts var pazust.

Brightness 250cd/m2

Monitora gaišums ir attēla redzamības rādītājs, kas nosaka, cik labi saskatāms ir attēls pie spēcīga ārējā apgaismojuma (saules gaisma, gaiša telpa, utt.). LCD monitoru gaišums tiek mērīts kandelās uz kvadrātmetru (Cd/m2).
Izvēloties monitoru jāņem vērā - jo lielāks gaišuma rādītājs, jo labāka attēla redzamība.

Ikdienas vajadzībām TopPC.fi iesaka iegādāties monitoru ar gaišumu, ne mazāku par 250 cd/m2.

Basic information

Application : Home & Office

Aspect ratio : 16:9

Color : Black

Size 23.8"

The size of the monitor screen is measured in inches across the diagonal. The screen size must be proportionate to the resolution of the screen for achieving the maximum utilisation of the desktop and details of the image.

Mainly two forms of LCD monitors are available: with standard width and height proportion 4:3 or the widescreen proportion 16:9 or 16:10. A widescreen monitor is wider and its resolution is higher than that of the monitors with standard proportion.

The bigger the monitor size the higher resolution usually is supported. Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.

Resolution FHD 1920x1080

The resolution of the monitor screen determines the number of colour dots (pixels) a monitor can display. It refers to the clarity of the text and images displayed on the screen. The higher the resolution the sharper the items look.

The applied resolution depends on the resolution supported by the monitor. LCD monitors, including the screens of laptop computers usually work best if their local resolution has been set. The setting of this resolution for the monitor is not mandatory, but usually it is recommended to set it for ensuring the highest possible sharpness of texts and images. The bigger the monitor size the higher resolution usually is supported.

Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.
• 19 inches screen (standard proportions): 1280x1024 pixels
• 20 inches screen (standard proportions): 1600x1200 pixels
• 22 inches screen (widescreen): 1680x1050 pixels
• 24 inches screen (widescreen): 1900x1200 pixels

Functionality

Flicker-free : Ir

Height adjustment : Nav

Pivot : Nav

Swivel : None

Tilt : YES

VESA wall mount : 100x100 mm

Ports and equipment

D-SUB 1

D-SUB is the classic (analogous) monitor connection plug. This standard is gradually disappearing from the market giving the place to the higher quality HDMI or DisplayPort (digital) plugs.

If the resolution of the monitor is FullHD or below the average user will experience no problems with this connection. Those who want to achieve higher image quality and resolution should look for the monitor with the DisplayPort or HDMI connection slot.

DisplayPort Nav

DisplayPort is the digital connection for transmitting the image via a single wire at a high quality level. Contrary to the HDMI, this connection allows to connect several external monitors to the computer via a single connector.

Prior to buying the monitor with the DisplayPort you should verify whether your computer has the DisplayPort plug available!

DVI Nav

DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.

DVI is compatible with HDMI and transitions of both directions are available.

DVI is not compatible with DisplayPort, however, there are DualMode DisplayPort connectors which contains the HDMI/DVI signal, and in the relevant direction DisplayPort -> DVI can transmit an image.

If the monitor resolution exceeds 1920px in any direction a graphics card with the DVI-D Dual Link support and the relevant quality cable will be required.

Before buying a monitor you should verify whether your graphics card has the corresponding connection slot!

HDMI port 1

HDMI is the digital high quality image transmission standard that allows to connect the monitor to the computer via a thin cable by using an elegant small-size connector. HDMI is compatible with DVI if the relevant transition or cable is used.

Speakers Nav

Some monitors may have built-in speakers that quite often allow to give up external speakers thus freeing a space on the desk and saving money. The sound quality of built-in speakers is quite moderate and therefore we recommend to use this possibility just for infrequent needs.

For enjoying music, movies and games we recommend buying the corresponding quality and capacity speakers.

USB Hub : NO

USB-C Power Delivery : Nav

USB-C video input : 0

More detailed specification

Additional information in manufacturers website Lenovo ThinkVision S24e-20, 23.8"

Brand - Lenovo
BrandPartCode - 62AEKAR2EU
Category - Computer Monitors
Design - Colour name - Raven Black
Design - Market positioning - Home
Design - Product colour - Black
dimensionalWeight - 6432
Display - Anti-glare screen - Yes
Display - Colour depth - 8 bit
Display - Colour gamut standard - NTSC
Display - Contrast ratio (dynamic) - 3000000:1
Display - Contrast ratio (typical) - 3000:1
Display - Digital horizontal frequency - 54 - 90 kHz
Display - Digital vertical frequency - 49 - 76 Hz
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 60.5 cm (23.8")
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - HD type - Full HD
Display - Maximum refresh rate - 60 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 72%
Display - Panel type - VA
Display - Pixel density - 93 ppi
Display - Pixel pitch - 0.2745 x 0.2745 mm
Display - Response time - 6 ms
Display - Response time (extreme) - 4 ms
Display - Screen shape - Flat
Display - Touchscreen - No
Display - Viewable size, horizontal - 52.7 cm
Display - Viewable size, vertical - 29.6 cm
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Cable management - Yes
Ergonomics - On Screen Display (OSD) - Yes
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 22°
Ergonomics - VESA mounting - Yes
GTIN - 0195348151559
GTIN - 195348151559
LongDesc - ThinkVision S24e-20 is an excellent performer that delivers core functionality with a sleek new form factor. Its 1920 x 1080 FHD resolution VA panel up to angles as extreme as 178°.The compact screen head is twice as slim as its previous generation and sits within a compact 3-side NearEdgeless frame.The stand’s built-in cable management system keeps wires out of sight and out mind. Which is a good thing because, with HDMI, VGA and Audio Out ports, S24e-20 can connect to a whole range of mission-critical devices. And because your staff are your most precious asset, S24e-20 has TÜV Rheinland Eye Comfort Certified technology to protect them from eye fatigue.
LongProductName - 60.5cm (23.8") Full HD 1920 x 1080 VA, 16:9, 250cd/m², 16.7M, 6ms, 178°/178°, 3000:1
LongSummaryDescription - Lenovo ThinkVision S24e-20. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 6 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Operational conditions - Operating relative humidity (H-H) - 10 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Certification - TÜV Rheinland Eye Comfort Certification
Other features - Compliance certificates - RoHS
Packaging content - Cables included - AC
Packaging content - Cables included - AC, HDMI
Packaging content - Cables included - HDMI
Packaging content - HDMI cable length - 1.8 m
Packaging content - Power cable length - 1.8 m
Packaging content - Quick start guide - Yes
Packaging content - Stand included - Yes
Packaging data - Package depth - 415 mm
Packaging data - Package height - 124 mm
Packaging data - Package weight - 5.42 kg
Packaging data - Package width - 624 mm
Performance - AMD FreeSync - Yes
Performance - AMD FreeSync type - FreeSync
Performance - NVIDIA G-SYNC - No
Performance - Windows operating systems supported - Windows 7
Performance - Windows operating systems supported - Windows 10
Performance - Windows operating systems supported - Windows 10, Windows 7
Ports & interfaces - Audio input - No
Ports & interfaces - Audio output - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - Headphone out - No
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy efficiency class (SDR) - D
Power - Power consumption (max) - 23.5 W
Power - Power consumption (off) - 0.5 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 17.5 W
Power - Power supply type - Internal
producerCode - 62AEKAR2EU
productName - Lenovo ThinkVision S24e-20 LED display 60.5 cm (23.8") 1920 x 1080 pixels Full HD Black
ProductName - S24e-20
productSize - Normal
Safety warning - Warnings - Place the monitor on a flat and stable surface to avoid tipping and damage.
ShortSummaryDescription - Lenovo ThinkVision S24e-20, 60.5 cm (23.8"), 1920 x 1080 pixels, Full HD, LED, 6 ms, Black
sizeX - 415
sizeY - 620
sizeZ - 125
Sustainability - European Product Registry for Energy Labelling (EPREL) code - 391341
Sustainability - Sustainability certificates - ENERGY STAR
Sustainability - Sustainability certificates - ENERGY STAR, EPEAT Gold, TCO
Sustainability - Sustainability certificates - EPEAT Gold
Sustainability - Sustainability certificates - TCO
Title - Lenovo ThinkVision S24e-20 LED display 60.5 cm (23.8") 1920 x 1080 pixels Full HD Black
URL - https://www.lenovo.com/
WarrantyInfo -
warrantyLength - 36
warrantyType - F
weight - 4930
Weight & dimensions - Bezel width (bottom) - 2.24 cm
Weight & dimensions - Bezel width (side) - 2.5 mm
Weight & dimensions - Bezel width (top) - 2.5 mm
Weight & dimensions - Depth (without stand) - 45.5 mm
Weight & dimensions - Depth (with stand) - 173.1 mm
Weight & dimensions - Height (without stand) - 327.2 mm
Weight & dimensions - Height (with stand) - 434.5 mm
Weight & dimensions - Weight (without stand) - 3.02 kg
Weight & dimensions - Weight (with stand) - 3.82 kg
Weight & dimensions - Width (without stand) - 540.4 mm
Weight & dimensions - Width (with stand) - 540.4 mm
