Dahua LM24-P301A, 23.8"

Name: Dahua LM24-P301A, 23.8"
Brand: Dahua
SKU: 1073717
Price: 445.83 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 1073717 Product code: LM24-P301A

In stock 9 units

Warranty: 3 years

Compare

Delivery options

Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
Courier delivery 11.99 €: on Wednesday, 27.11.2024

Main product parameters All parameters

Curved: Nav
Panel Type: IPS
Refresh rate: 75 Hz
Response time: 6ms
Contrast ratio: 1000:1
Brightness: 320cd/m2
Size: 23.8"
Resolution: WQHD 2560x1440

Description

We offer to buy Dahua 23.8" a monitor with WQHD 2560x1440 resolution.

IPS matrix for this monitor provides high colour correspondence parameters, superior picture contrast and good visibility from eventually all viewing angles.
The compatibility with the modern graphics cards and video players will be ensured by HDMI input.
DisplayPort port ensures the receipt of a higher quality picture from the computer graphics card supporting this technology.
The especially high WQHD 2560x1440 resolution due to the increased desktop size makes this monitor a great choice for graphics professionals and video editing experts.

Display characteristics

AMD FreeSync : Nav

Curved : Nav

NVIDIA G-SYNC : Nav

Panel Type IPS

Teh monitor panel is the main feature of the visible part of the screen or the technology where the display of the colour dots (pixels) is implemented.

TN is the standard technology with average contract, brightness and colour compliance indices.

IPS is the matrix with high colour compliance and good response speed, therefore it is well suited for graphics tasks and photo editing. IPS matrix provide an excellent viewing angle maintaining the colours and contrast from almost any angle.

VA matrix ensures superior colour compliance, however, the response time of this matrix is lagging behind that of the IPS and TN; the viewing angle is somewhere between both these technologies.

The TN type monitor is fully sufficient for an average user. If you have more money available the VA or IPS can be chosen.

Refresh rate : 75 Hz

Touchscreen : NO

VESA DisplayHDR : Nav

Response time 6ms

The response time of the monitor screen determines how fast the monitor will display moving images (films, games, animations, etc.). The response time is measured in miliseconds. The less the response time the better the ability of the monitor to display moving images.
www.toppc.fi recommends to buy monitors with 5ms response time or lower.

Contrast ratio 1000:1

Ekrāna kontrasts nosaka attēla asumu. Tā ir atšķirība starp vistumšāko (pilnīgi melnu) un visgaišāko (pilnīgi baltu) pikseli. Jo lielāks kontrasts, jo skaidrāk salasāms teksts uz ekrāna, kontrasts arī nosaka, cik izteiksmīgas līnijas būs redzamas monitora attēlā.

Augsts kontrasts ir nozīmīgs faktors izvēloties monitoru biroja, vai mācību vajadzībām, kad lielākoties tiek strādāts ar tekstuālu informāciju.

Mājas vajadzībām svarīgāks izvēles rādītājs ir gaišums un attēla reakcijas laiks. Kontrastu labāk novērtēt tumšā istabā.
Lielākais LCD monitoru trūkums ir tas, ka samazinot attēla spilgtumu, kontrasts var pazust.

Brightness 320cd/m2

Monitora gaišums ir attēla redzamības rādītājs, kas nosaka, cik labi saskatāms ir attēls pie spēcīga ārējā apgaismojuma (saules gaisma, gaiša telpa, utt.). LCD monitoru gaišums tiek mērīts kandelās uz kvadrātmetru (Cd/m2).
Izvēloties monitoru jāņem vērā - jo lielāks gaišuma rādītājs, jo labāka attēla redzamība.

Ikdienas vajadzībām TopPC.fi iesaka iegādāties monitoru ar gaišumu, ne mazāku par 250 cd/m2.

Basic information

Application : Home & Office

Aspect ratio : 16:9

Color : Black

Size 23.8"

The size of the monitor screen is measured in inches across the diagonal. The screen size must be proportionate to the resolution of the screen for achieving the maximum utilisation of the desktop and details of the image.

Mainly two forms of LCD monitors are available: with standard width and height proportion 4:3 or the widescreen proportion 16:9 or 16:10. A widescreen monitor is wider and its resolution is higher than that of the monitors with standard proportion.

The bigger the monitor size the higher resolution usually is supported. Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.

Resolution WQHD 2560x1440

The resolution of the monitor screen determines the number of colour dots (pixels) a monitor can display. It refers to the clarity of the text and images displayed on the screen. The higher the resolution the sharper the items look.

The applied resolution depends on the resolution supported by the monitor. LCD monitors, including the screens of laptop computers usually work best if their local resolution has been set. The setting of this resolution for the monitor is not mandatory, but usually it is recommended to set it for ensuring the highest possible sharpness of texts and images. The bigger the monitor size the higher resolution usually is supported.

Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.
• 19 inches screen (standard proportions): 1280x1024 pixels
• 20 inches screen (standard proportions): 1600x1200 pixels
• 22 inches screen (widescreen): 1680x1050 pixels
• 24 inches screen (widescreen): 1900x1200 pixels

Functionality

Flicker-free : Nav norādīts

Height adjustment : Ir

Pivot : Ir

Swivel : And

Tilt : YES

VESA wall mount : 75x75mm

Ports and equipment

D-SUB Nav

D-SUB is the classic (analogous) monitor connection plug. This standard is gradually disappearing from the market giving the place to the higher quality HDMI or DisplayPort (digital) plugs.

If the resolution of the monitor is FullHD or below the average user will experience no problems with this connection. Those who want to achieve higher image quality and resolution should look for the monitor with the DisplayPort or HDMI connection slot.

DisplayPort 1

DisplayPort is the digital connection for transmitting the image via a single wire at a high quality level. Contrary to the HDMI, this connection allows to connect several external monitors to the computer via a single connector.

Prior to buying the monitor with the DisplayPort you should verify whether your computer has the DisplayPort plug available!

DVI Nav

DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.

DVI is compatible with HDMI and transitions of both directions are available.

DVI is not compatible with DisplayPort, however, there are DualMode DisplayPort connectors which contains the HDMI/DVI signal, and in the relevant direction DisplayPort -> DVI can transmit an image.

If the monitor resolution exceeds 1920px in any direction a graphics card with the DVI-D Dual Link support and the relevant quality cable will be required.

Before buying a monitor you should verify whether your graphics card has the corresponding connection slot!

HDMI port 1

HDMI is the digital high quality image transmission standard that allows to connect the monitor to the computer via a thin cable by using an elegant small-size connector. HDMI is compatible with DVI if the relevant transition or cable is used.

Speakers Nav

Some monitors may have built-in speakers that quite often allow to give up external speakers thus freeing a space on the desk and saving money. The sound quality of built-in speakers is quite moderate and therefore we recommend to use this possibility just for infrequent needs.

For enjoying music, movies and games we recommend buying the corresponding quality and capacity speakers.

USB Hub : YES

USB-C Power Delivery : 65W

USB-C video input : 1

More detailed specification

Additional information in manufacturers website Dahua LM24-P301A, 23.8"

75 mm x 75 mm VESA mounting interface - Yes
Audio-Out Input/Output connectors - 1
Brand - Dahua Technology
BrandPartCode - DHI-LM24-P301A-A5
Brightness - 320
Category - Computer Monitors
Category - Root/Electronics/PC peripherals/Monitors
Category Code - LC3
CnCode CnCode - 85285210
Colour - Black
Contrast - 1000:1
Data Sheet (Link) - https://eprel.ec.europa.eu/api/product/1363937/fiches?language=EN
Depth Unit Dimensions - 53.25 mm
Description - 24’’ QHD Monitor > The 2560*1440 resolution produces clearer and more vivid pictures; > IPS panel for wide viewing angles with 3-sided frameless design; > 178°H/178°V extra-wide viewing angle for overall viewing performance; > Wide color gamut:99% sRGB, 120% NTSC, 98% DCI-P3, > Rich interfaces, 65W type-C can support reverse charging; > 6ms fast response time with no image blurring or ghosting. > Supporting PIP/PBP to display the screens of two devices on the display simultaneously. > The angle can be adjusted to meet different needs.
Design - Detachable stand - Yes
Design - Feet colour - Black
Design - Market positioning - Business
Design - Product colour - Black
Display - Adobe RGB coverage - 93%
Display - Aspect ratio - 16:9
Display - Backlight type - Edge LED
Display - Colour gamut - 98%
Display - Colour gamut standard - DCI-P3
Display - Contrast ratio (typical) - 1000:1
Display - Display brightness (typical) - 320 cd/m²
Display - Display diagonal - 60.5 cm (23.8")
Display - Display resolution - 2560 x 1440 pixels
Display - Display technology - LED
Display - HD type - Quad HD
Display - Maximum refresh rate - 75 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 102%
Display - Panel type - IPS
Display - Response time - 6 ms
Display - Screen shape - Flat
Display - sRGB coverage (typical) - 99%
Display - Supported graphics resolutions - 2560 x 1440
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
DisplayPort Input/Output connectors - 1
Eans - 6923172579744
Energy consumption, standard - 20 kWh/1000h
Energy efficiency class - F
EPREL Registration Number - 1.36394e+006
EPREL Version Number - 1
Ergonomics - Height adjustment - 12.5 cm
Ergonomics - Height adjustment - Yes
Ergonomics - On Screen Display (OSD) - Yes
Ergonomics - Panel mounting interface - 75 x 75 mm
Ergonomics - Picture-in-Picture - Yes
Ergonomics - Pivot - Yes
Ergonomics - Pivot angle - 0 - 90°
Ergonomics - Swivel angle range - -45 - 45°
Ergonomics - Swivelling - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 20°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
Full Description Line - Model DHI-LM24-P301A|23.8"|Resolution 2560x1440|Form factor 16:9|Refresh rate 75Hz|Brightness 320|Contrast 1000:1|Response time 6 ms|Horizontal 178 degrees|Vertical 178 degrees|1xHDMI|1xDisplayPort|1xAudio-Out|1xUSB-C|Swivel|Tilt|PSU Inbuilt|75 mm x 75 mm|Colour Black
GTIN - 6923172579744
HDMI Input/Output connectors - 1
Height Unit Dimensions - 324.46 mm
LongDesc -
LongProductName - 23.8", 2560 x 1440, IPS, E-LED, 16:9, 320 cd/m², 1000:1, 6 ms, 75 Hz, DP 1.4, HDMI 2.1, USB Type C, 130 W max
LongSummaryDescription - Dahua Technology LM24-P301A. Display diagonal: 60.5 cm (23.8"), Display resolution: 2560 x 1440 pixels, HD type: Quad HD, Display technology: LED, Response time: 6 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in USB hub. VESA mounting, Height adjustment. Product colour: Black
Model name - DHI-LM24-P301A
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Name - Dahua LM24- P301A - 24'' | IPS | QHD | 75Hz
Native resolution - 2560x1440
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Packaging content - Cables included - AC, HDMI
Packaging content - HDMI cable length - 1.5 m
Packaging content - Stand included - Yes
Packaging data - Package depth - 127 mm
Packaging data - Package height - 397 mm
Packaging data - Package type - Box
Packaging data - Package weight - 8.2 kg
Packaging data - Package width - 779 mm
Ports & interfaces - AC (power) in - Yes
Ports & interfaces - Audio output - Yes
Ports & interfaces - Built-in USB hub - Yes
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.4
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Headphone out - No
Ports & interfaces - USB Power Delivery - Yes
Ports & interfaces - USB Power Delivery up to - 65 W
Ports & interfaces - USB Type-C downstream ports quantity - 1
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (SDR) per 1000 hours - 20 kWh
Power - Energy efficiency class (SDR) - F
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 1363937
Power - Input current - 2 A
Power - Power consumption (max) - 130 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 35 W
Power - Power supply type - Internal
Power supply - Inbuilt
Producer - Dahua Technology
ProducerCode - LM24-P301A
ProductName - LM24-P301A
Refresh rate - 75Hz
Response time - 6 ms
Screen form factor - 16:9
Screen size - 23.8"
Shipping Box Depth Shipping/Package Box Dimensions - 78.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 39.5 cm
Shipping Box Weight Shipping/Package Box Dimensions - 7.4 kg
Shipping Box Width Shipping/Package Box Dimensions - 12.5 cm
ShortDescription - 24'' | IPS | QHD | 75Hz
ShortSummaryDescription - Dahua Technology LM24-P301A, 60.5 cm (23.8"), 2560 x 1440 pixels, Quad HD, LED, 6 ms, Black
Standby consumption - 0.5 Watts
Swivel Stand - Yes
Tilt Stand - Yes
Title - Dahua Technology LM24-P301A LED display 60.5 cm (23.8") 2560 x 1440 pixels Quad HD Black
Unit Box Height - 0.395
Unit Box Length - 0.785
Unit Box Width - 0.125
Unit Brutto Volume - 0.03876 cubm
Unit Gross Weight - 7.4 kg
Unit Net Weight - 5.7 kg
URL - https://display.dahuasecurity.com/consumer/en/products/productDetail?product_id=115227
USB-C Input/Output connectors - 1
Vendor Homepage - display.dahuasecurity.com/consumer/en/products/productDetail?product_id=115227
Viewing angle horizontal - 178 degrees
Viewing angle vertical - 178 degrees
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 53.2 mm
Weight & dimensions - Height (without stand) - 324.5 mm
Weight & dimensions - Weight (without stand) - 5.7 kg
Weight & dimensions - Width (without stand) - 539.6 mm
Width Unit Dimensions - 539.6 mm
