8-pin 12V power connectors - 0
Accessories included - Power cord Motherboard power cable (600 mm) 2 x CPU Cable (650 mm) PCI-E 16-pin Gen 5 cable (675 mm) PCI-E cable (16-pin to 8-pin-8-pin)(675 mm) SATA 1 to 2 cable (400+120 mm) SATA 1 to 3 cable (400+120+120 mm) Peripheral cable 1 to 4 (400+150+150+150 mm) RGB addressable cable (800 mm) User manual
Brand - ASUS
BrandPartCode - 90YE00P2-B0NA00
category - PC Components|Power Supplies|PCIe 5.0
Category - Power Supply Units
Category - Root/Electronics/PC parts/PC power supply units
Certificates 80+ - 80 PLUS Gold
code - 90YE00P2-B0NA00
Description - Rog Strix 850W Gold Aura ATX 3.0 power supply It exudes power Rog Strix 850W Gold Aura offers a combination of premium components, excellent cooling and stunning RGB lighting, providing users with the perfect power solution. Featuring huge ROG heatsinks, a high-performance Axial-tech fan, and a striking aluminum finish, this is a powerful power supply that will be the perfect foundation for your next gaming system. Aluminum housing Designed for low temperatures The ROG Strix 850W Gold Aura Edition power unit features a solid, elegant aluminum casing that also functions as a heat sink for the internal power transformer. This further helps reduce temperatures and minimize noise. ROG heatsinks They also stay cool under pressure ROG heatsinks ensure lower temperatures, longer component life, and extended operating time in 0dB mode. Axial-tech fan Better, faster, stronger The Axial-tech fan has a smaller hub with longer blades and a locking ring to increase downward air pressure. For ROG Strix Aura Edition power supplies, we've modified this design to 135mm, ensuring efficient cooling at low RPM while producing less noise. Fan with double ball bearings 2x longer service life The fan blade is mounted on a double ball bearing, which guarantees twice as long service life compared to solutions with flange bearings. 0dB technology Silence intelligently ensured To reduce noise, the PWM-controlled fan turns off completely when the power supply load is 60% or less. 80 Plus Gold certification Golden Heart Top-class Japanese capacitors ensure efficient operation, and their use has helped ROG Strix Aura Edition power units achieve 80 PLUS Gold certification. In addition, increased energy efficiency translates into less heat generation, reduced fan noise and increased reliability. Lambda A++ certification Comfortably quiet operation ROG Strix 850W Gold Aura Edition emits an average of less than 15 dB of noise, which allowed it to achieve the sought-after Cybenetics Lambda A++ certification. Compatible with ATX 3.0 Direction: future The latest power solutions are now available. ATX 3.0 introduces more stringent voltage and current regulation guidelines for the latest generation of hardware, and ROG Strix Aura Edition is ahead of the competition in this respect, ensuring full compliance with this standard. The power unit comes with a 16-pin PCIe cable that allows you to deliver up to 600W of power to graphics cards connected via PCIe Gen 5.0, so your system will be ready for the latest technologies. Aura Sync Put your competitors in the shade Addressable RGB lighting is directly built into the ROG Strix 850W Gold Aura Edition power unit. This lighting can be easily integrated into the Aura Sync lighting ecosystem, enjoying an attractive appearance combined with powerful power. *If no connecting cable is used, the default color effect is rainbow. *To use Aura Sync, an Aura Sync-compatible ASUS or ROG motherboard is required. Likewise, the Intelligent Mode lighting effect, which reflects GPU temperature, requires the use of a compatible ASUS or ROG graphics card. 10 years warranty A decade of power We are so confident in the reliability of the ROG Strix 850W Gold Aura Edition power supply that we provide it with a 10-year warranty. *The main functionality of the product is guaranteed for a period of 10 years. RGB LEDs are covered by a 3-year warranty.
Design - Cooling type - Active
Design - Fan diameter - 13.5 cm
Design - Illumination - Yes
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
dimension depth - 120 mm
dimension height - 310 mm
Dimensions - 180 x 150 x 86 mm
dimension weight - 3875 g
dimension width - 370 mm
ean - 4711081722014
Eans - 4711081722014
Fan - 13.5 cm
Floppy power connectors - 0
GTIN - 4711081722014
guarantee - 120
guarantee_type - normal
LongDesc - Exude PowerThe ROG Strix 850W Gold Aura combines premium components, superior cooling and captivating RGB illumination to create a formidable force. With huge ROG heatsinks, a high-efficiency Axial-tech fan, and a striking aluminum finish, it’s a pumped-and-primed PSU powerhouse for your next gaming rig.COOLINGAluminum CaseBuilt to run coolThe ROG Strix 850W Gold Aura Edition is encased in a strong, sleek aluminum chassis that also acts as a heatsink for the internal power transformer, further helping to reduce temperatures and minimize noise.ROG HeatsinksCool under pressureROG heatsinks facilitate lower temperatures, longer component lifespan, and extended 0dB operation.Axial-tech Fan DesignBetter, faster, strongerAxial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure. For ROG Strix Aura Edition PSUs, we've scaled that design to 135mm so it keeps things cool at low RPMs while producing less noise.Dual Ball Fan Bearings2x longer lifespanThe fan impeller spins on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.0dB TechnologyQuiet intelligenceTo reduce noise output, the PWM-controlled fan shuts off entirely when the PSU load is 60% or below.ENGINEERING80 Plus Gold CertificationHeart of goldTop-end Japanese capacitors ensure efficient operation and have helped the ROG Strix Aura Edition PSUs earn an 80 PLUS Gold certification. The increased efficiency also results in less heat, reducing noise and increasing reliability.Lambda A++ CertificationEffortlessly quietOn average, ROG Strix 850W Gold Aura Edition emits less than 15 dB of noise – earning a coveted Cybenetics Lambda A++ certification.ATX 3.0 CompatibleStep into the futureThe latest power specification updates have landed. ATX 3.0 ushers in tighter voltage and current regulation guidelines for next-gen hardware - and ROG Strix Aura Edition steps ahead of the curve by being fully compliant. A 16-pin PCIe cable ripe for piping up to 600W of power to PCIe Gen 5.0 graphics cards is bundled with the PSU, readying your build for the next-gen.EXPERIENCEAura SyncOutshine the competitionAddressable RGB lighting is built right in to the ROG Strix 850W Gold Aura Edition, so it’s all set to integrate with the Aura Sync illumination ecosystem – adding aesthetic style to raw power.*If the connector cable is not used, the default color effect is rainbow.*To enjoy Aura Sync, you’ll need an Aura Sync-compatible ASUS or ROG motherboard. Similarly, the Smart Mode lighting effect, which reflects GPU temperature, requires use of a compatible ASUS or ROG graphics card.10-year WarrantyA decade of powerWe're so confident about the reliability of the ROG Strix 850W Gold Aura Edition that we back it with a 10-year worldwide warranty.*Core product operation is guaranteed for 10 years. The RGB LEDs are subject to a 3-year warranty.
LongProductName - ROG Strix 850W Gold Aura Edition RGB power supply (850 Watt, Aura Sync RGB lighting, 80+ Gold certification, Axial-Tech fan, ATX 3.0 compatible, PCIe 5.0 Ready)
LongSummaryDescription - ASUS ROG Strix 850W Gold Aura Edition. Total power: 850 W, AC input voltage: 100 - 240 V, Combined power (+3.3V): 120 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 120,400 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
MB power connector - 20 + 4 pin
Modular power supply - Yes
MOLEX power connectors - 4
Name - ASUS ROG-STRIX-850G-AURA-GAMING
name - ASUS ROG Strix 850W Gold Aura Edition, 80 PLUS Gold Netzteil, modular - 850 Watt
name - Power supply Rog Strix 850W Gold Aura ATX 3.0
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 0
Number of power connectors PCI-E 16-pin Gen 5 - 1
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 3
Other features -
Packaging content - Cables included - AC, CPU, PCIe, Peripheral (Molex), SATA
Packaging data - Package type - Box
Packaging data - Package weight - 3.22 kg
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - ATX version - 3.0
Performance - Bearing technology - Ball bearing
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - Silent mode - Yes
PFC - Active
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power cable length - 65 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 5
Ports & interfaces - PCI Express power connectors (8-pin) - 3
Ports & interfaces - PCI Express power connectors (16-pin) - 1
Ports & interfaces - Peripheral (Molex) power cable length - 150,400 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Ports & interfaces - SATA power cable length - 120,400 mm
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 120 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 849.6 W
Power - Combined power (-12V) - 3.6 W
Power - Max output current (+3.3V) - 22 A
Power - Max output current (+5V) - 22 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 70.8 A
Power - Max output current (-12V) - 0.3 A
Power - Power protection features - Over power, Over voltage, Overcharge, Overheating, Short circuit, Under voltage
Power - Total power - 850 W
Power supply - 850 W
producer - Asus
Producer - Asus
ProducerCode - 90YE00P2-B0NA00
ProductName - ROG Strix 850W Gold Aura Edition
SATA power connectors - 5
ShortDescription - 850 | ATX | 135mm | 20 + 4 pin | 80Plus Gold | 180 x 150 x 86 mm |
ShortSummaryDescription - ASUS ROG Strix 850W Gold Aura Edition, 850 W, 100 - 240 V, 120 W, 849.6 W, 3.6 W, 15 W
Technical details - Compliance certificates - RoHS
Technical details - Sustainability compliance - Yes
Title - ASUS ROG Strix 850W Gold Aura Edition power supply unit 20+4 pin ATX ATX Black
URL - https://rog.asus.com/power-supply-units/rog-strix/rog-strix-850g-aura-gaming-model/
vendpn - 90YE00P2-B0NA00
WarrantyInfo -
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.73 kg
Weight & dimensions - Width - 180 mm
