NZXT C850, 850W, 80PLUS Gold

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 909911 Product code: PA-8G1BB-EU
Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

TopPC.fi website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 2 years (Warranty for business entities 1 year)
Main product parameters All parameters
  • Producer: NZXT
  • Power output: 850W
  • 80 PLUS certification: 80 PLUS Gold
  • Fan size: 135 mm
  • Modular cables: Fully-Modular
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 6 x 6+2pin
Similar Products
This product NZXT C850, 850W, 80PLUS Gold
Recommended Gigabyte UD850GM, 850W, 80PLUS Gold
Recommended Gigabyte UD850GM PG5 White, 850W, 80PLUS Gold, PCIe 5.0
Recommended Deepcool PN850M, 850W, Sleeved Cables, 80PLUS Gold. PCI-E 5.0
Recommended NZXT C1200 Black (2023), 1200W, 80PLUS Gold, PCIe 5.0
Show similar specs. Hide similar specs.
139.28 €
90.95 €
107.28 €
114.81 €
178.45 €
Basic information
Cybenetics Efficiency certification Nav Cybenetics Platinum Cybenetics Platinum Cybenetics Gold Cybenetics Gold
Cybenetics Noise level certification Nav Cybenetics Standard ++ Cybenetics Standard ++ Cybenetics Standard ++ Cybenetics Standard +
Power supply type ATX ATX ATX ATX ATX
Power output 850W 850W 850W 850W 1200W
80 PLUS certification 80 PLUS Gold 80 PLUS Gold 80 PLUS Gold 80 PLUS Gold 80 PLUS Gold
Total amperage (+12V) 70.8A 70.8A 70.8A 70.5A 100A
Fan size 135 mm 120 mm 120 mm 120 mm 135 mm
Functionality
Cable colour Melna Melna White Melna Melna
Lighting Nav Nav Nav Nav Nav
Color Melna Melna White Melna Melna
Modular cables Fully-Modular Fully-Modular Fully-Modular Fully-Modular Fully-Modular
Ports and equipment
PCI-E 5.0 Nav Nav 1 x 600W 12VHPWR 1 x 600W 12VHPWR 1 x 600W 12VHPWR
Processor plug-in 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 1 x 8-pin(4+4) EPS
Motherboard power 24-pin 20+4pin 20+4pin 20+4pin 24-pin
PCI-E 6 x 6+2pin 4 X 6+2pin 4 X 6+2pin 3 x 6+2pin 2 X 6+2pin
SATA cconnectors 6 Eight Core Eight Core Eight Core Eight Core
4pin Molex 6 3 3 2 4
Description

We offer to purchase a NZXT power supply unit with a power capacity of 850W, which has received the 80 PLUS Gold energy efficiency certification.

This 850W power supply unit is intended for a workstation or high-performance gaming computer. It will be able to power multiple hard drives (SSD/HDD), water cooling, a high-end graphics card (for example, RTX 4070 Ti SUPER), and a top-tier processor (possibly overclocked).

Thanks to the large 135 mm cooling fan diameter, this power supply is much quieter than average. The fan has a larger blade area, which provides the necessary airflow at lower fan speeds, thereby reducing the overall noise and vibration levels to a minimum.

80 PLUS Gold energy efficiency certificate received by this power supply guarantees at least 90% efficiency at 50% load. In other words, for every 100 W of energy the power supply receives from the power grid, at least 90 W goes to your computer components, and the remaining 10 W is lost as heat.

The color of the block is Melna. The block has flat cables, whose color is Melna.

ATX 2.0 standard, which is assigned to this power supply unit, ensures that the unit is equipped only with 6-pin and 8-pin connectors (with respective power of 75W and 150W). For a system with a very powerful graphics card (such as RTX 4070), an ATX 3.* standard unit will be required, and ATX 2.0 will not be sufficient.

Thanks to the fact that this power supply has modular cables, you can add hard drives, video cards, and other components as needed, using the various cables included in the package. This way, there are fewer wires in the computer, which improves ventilation and appearance (especially useful for those who choose a partially transparent case).

Basic information
Cybenetics Efficiency certification : Nav
Cybenetics Noise level certification : Nav
Power supply type : ATX
Power output 850W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Gold
Total amperage (+12V) : 70.8A
Fan size : 135 mm
Functionality
Cable colour : Melna
Lighting : Nav
Color : Melna
Modular cables : Fully-Modular
Ports and equipment
PCI-E 5.0 : Nav
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 24-pin
PCI-E : 6 x 6+2pin
SATA cconnectors : 6
4pin Molex : 6
More detailed specification
8-pin 12V power connectors - 0
Accessories included -
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates 80+ - 80 PLUS Gold
Description - C SERIES GOLDC Series Gold ATX power supply from NZXT features safe, reliable power while ensuring optimal efficiency and quieter performance. Manufactured with high-quality components and backed by a 10-year warranty, the C Series Gold ATX power supplies deliver both peace of mind and up to 1000 watts of clean, reliable power to your PC gaming system.
MORE EFFICIENT
At 50% load and high-line input voltage, power conversion efficiency reaches 1.5% higher than 80plus Gold Standard.
FULLY MODULAR
C SERIES GOLDUse only the cables you need to keep your system clean and organized. Black sleeved cable and a matte black finish seamlessly fit any PC style.
COMPATIBLE AND HIGHLY-TESTED
C SERIES GOLDC series is built and tested with strict standards for trouble-free installation and stable operation. It fits any case supporting ATX PSU and supports the latest NVIDIA and AMD GPUs up to 30 series and AMD 6000 Series
MORE PRECISE AND ERROR-FREE
Micro controller (MCU) enabled protection mechanism monitors current and voltage and output wattage.
OPTIMIZED AND SILENT
Gold PSU includes low thermal dissipation optimization with upgraded components and optimized circuit design. The cooling fan is also upgraded from 120 to 135mm PWM fan with a FDB bearing fan to ensure it can operate silently at high load. Adhesive dispensing on part of the electrical components reduces noise.
dimension depth - 118 mm
dimension height - 227 mm
Dimensions - 150 x 150 x 86mm
dimension weight - 3243 g
dimension width - 335 mm
ean - 5060301697656
EAN_code - 5060301697656
Fan - 13.5 cm
Fan speed (max) - 2300 rpm
Floppy power connectors - 0
guarantee - 24
guarantee_type - normal
Manufacturer - NZXT
Manufacturer_code - PA-8G1BB-EU
MB power connector - 24 pin
Modular power supply - Yes
MOLEX power connectors - 6
Name - NZXT C850 80+ Gold 850W, PC power supply (black, 6x PCIe, cable management, 850 watts)
name - Power Supply C850 V2 850W modular 80+ Gold
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 6
Other features -
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
PFC - Active
Power supply - 850 W
producer - NZXT
SATA power connectors - 6
Technical_details - Type: PC power supply Color: Black EAN: 5060301697656 Manufacturer No.: PA-8G1BB-EU Series: C Power: 850W : 850W : 120W : Minimum: 85%, Maximum: 90.5% : 100-240 volts : 5 A at 230 volts / 50 Hz, 10 A at 110 volts / 60 Hz Standard: ATX12V 2.52, EPS12V 2.9x Design: ATX Certification: 80 PLUS Gold Amperages: 22 A : 22A : 3 A : 0.3A : 70.8A : 70.8A Power Factor Correction: Active PFC Switch: 1x power switch Connectors: 1x 24-pin ATX12V-2.x, 2x 4+4-pin 12V, 6x 4-pin 5.25", 6x 6+2-pin graphics, 6x 15-pin SATA Cable: Yes Cooling: 1x 120mm fan : Temperature controlled Volume: 48.8 dB(A) at 100% load Dimensions: Width: 150mm x Height: 86mm x Depth/Length: 150mm
vendpn - PA-8G1BB-EU
Weight - 3,29
