ID: 890134
Product code: 90YE00L3-B0NA00
Can be ordered 6 units Availability: 14 days after order approval
Warranty: 3 years
Asus ROG Thor Platinum II, 1000W, 80PLUS Platinum
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
Delivery options
- Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
- Courier delivery 11.99 €: 11.12.2024
Main product parameters All parameters
- Producer: Asus
- Power output: 1000W
- 80 PLUS certification: 80 PLUS Platinum
- Fan size: 135 mm
- Modular cables: Fully-Modular
- Processor plug-in: 2 x 8-pin(4+4) EPS
- PCI-E: 8 x 6+2pin
Description
We offer to purchase a Asus power supply unit with a power capacity of 1000W, which has received the 80 PLUS Platinum energy efficiency certification.
Even the best gaming computer will be able to operate safely with this 1000W power supply unit. The power will be sufficient for both a substantial water cooling system and multiple high-end graphics cards, an overclocked high-end processor, and several hard drives.
This power supply is equipped with an exceptionally large 135 mm fan. Thanks to the larger blade size, it provides better airflow at lower speeds and quieter operation compared to standard 120 mm fans.
The power supply has been awarded the 80 PLUS Platinum energy efficiency certificate, which ensures at least 92% efficiency at 50% load. This indicates that at least 92 W out of 100 W of power that the power supply receives from the power grid is delivered to the computer components, while the remaining 8 W is lost as heat.
This power supply unit is equipped with a 1 x 600W 12VHPWR plug intended for use with modern graphics cards – Nvidia GeForce RTX 4070 and up. The RTX 4060 uses a standard 8-pin connector.
The color of this power supply is Melna,Sudraba. The cable color is Melna and they are flat.
This is a power supply unit compliant with ATX 3.0 requirements. It indicates that it has a 16-pin (12VHPWR) port, which can power the latest generation (RTX 30 and 40 series) PCIe 5.0 graphics cards with up to 600 W of power. Furthermore, ATX 3.0 allows the current to be increased by 200% for a millisecond, ensuring smoother power delivery to the components.
The power supply unit has a Cybenetics A ++ noise level certificate, which means its noise level is below 15 dB.
This power supply has modular cables, which provide the possibility to add video card cables, hard disk cables, etc. as needed from the supplied range. This way, the wire clutter in the computer is reduced, improving ventilation and the aesthetic factor (particularly important for those who purchase a partially transparent case).
The power supply unit has RGB lighting.
This power supply is manufactured by Asus. You can view all Asus power supplies here.
Basic information
Cybenetics Efficiency certification
: Nav
Cybenetics Noise level certification
: Cybenetics A ++
Power supply type
: ATX
Power output
1000W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification
: 80 PLUS Platinum
Total amperage (+12V)
: 83A
Fan size
: 135 mm
Functionality
Cable colour
: Melna
Lighting
: RGB
Color
: Melna, Silver
Modular cables
: Fully-Modular
Ports and equipment
PCI-E 5.0
: 1 x 600W 12VHPWR
Processor plug-in
: 2 x 8-pin(4+4) EPS
Motherboard power
: 20+4pin
PCI-E
: 8 x 6+2pin
SATA cconnectors
: 12
4pin Molex
: 6
More detailed specification
Brand - ASUS
BrandPartCode - 90YE00L4-B0NA00
category - PC Components|Power Supplies|PCIe 5.0
Category - Power Supply Units
Category - Root/Electronics/PC parts/PC power supply units
Category_1 - Power
Category_2 - Computer Power Supplies
code - 90YE00L4-B0NA00
Design - Cooling type - Active
Design - Illumination - Yes
Design - LED indicators - Yes
Design - Product colour - Black, Silver
ean - 4711081746294
Eans - 4711081746294
EAN_code - 4711081746294
GTIN - 4711081746294
LongDesc - The Quietest 1000W Power SupplyBack with a vengeance, the second iteration of the ROG Thor 1000W Platinum wields cooling and component upgrades that make it the quietest PSU in its class*. And to compliment the latest high-end ROG motherboards and bring additional flair to beastly rigs, we've added a mirrored side panel that neatly frames the OLED displayROG HeatsinksROG heatsinks have 2x more volume than traditional designs, facilitating lower temperatures, longer component lifespan, and extended 0dB operation.Axial-tech Fan DesignA 135mm Axial-tech fan with PWM control delivers lower noise and keeps thermals in check.Dual Ball Fan BearingsThe fan impeller spins on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.0dB TechnologyTo reduce noise output, the PWM-controlled fan shuts off entirely when the PSU load is 50% or below.Lambda A++ CertificationThor II cooling upgrades result in a coveted Lambda A++ noise rating, confirming the latest iteration wields menacing power in absolute stealth.80 Plus Platinum CertificationThe ROG Thor 1000W Platinum II utilizes low-ESR Japanese capacitors to ensure efficient operation. These upgrades enable an 80 PLUS Platinum certification, which guarantees 89% efficiency at 100% load and 92% efficiency at 50% load. The increased efficiency results in less heat, reduces fan noise, and increases reliability.OLED Power DisplayThe built-in OLED panel makes it easy to tune your system for best performance and efficiency.Aura SyncCustomize the Aura ROG logo and/or add RGB lighting strips to accent your showcase build.Sleeved CablesA range of sleeved cables are bundled with Thor II, and we also provide a 20% CableMod discount.PCIe Gen 5.0 ReadyEach ROG Thor 1000W Platinum II PSU is bundled with a 16-pin PCIe cable that can pipe up to 600W of power to PCIe Gen 5.0 graphics cards. Get ready for the future of power delivery.
LongProductName - ROG Thor 1000W Platinum II , 80Plus Platinum, OPP/OVP/UVP/SCP/OCP/OTP, 100-240Vac, ROG Thermal Solution, +3.3V +5V +12V -12V +5Vsb, 25A 25A 83A 0.3A 3A, 125W 125W 996W 3.6W 15W, 2.37KG, ARGB, 0dB Fan
LongSummaryDescription - ASUS ROG THOR 1000P2-GAMING. Total power: 1000 W, AC input voltage: 100 - 240 V, Maximum input current (@220V): 83 A. Motherboard power connector: 20+4 pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Silver, Cooling type: Active. Cables included: CPU, DC, PCIe, Peripheral (Molex), SATA
Manufacturer - Asus
Manufacturer_code - 90YE00L4-B0NA00
Name - ASUS ROG-THOR-1000P2-GAMING
Name - ASUS ROG-THOR-1000P2-GAMING 1000W, PC power supply (black, with Aura Sync and an OLED display, 1000 Watt)
name - ASUS ROG Thor 1000P2 Platinum II, 80 PLUS Platinum Netzteil, modular, PCIe 5.0 - 1000 Watt
Packaging content - Cables included - CPU, DC, PCIe, Peripheral (Molex), SATA
Packaging content - Cable tie(s) included - Yes
Performance - 80 PLUS certification - 80 PLUS Platinum
Performance - Certification - ROHS
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - Silent mode - Yes
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU P4 connector (4-pin) - 2
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 12
Ports & interfaces - PCI Express connector - Yes
Ports & interfaces - PCI Express power connectors (6+2 pin) - 8
Ports & interfaces - PCI Express power connectors (8-pin) - 1
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 6
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 125 W
Power - Combined power (+5V) - 125 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 996 W
Power - Combined power (-12V) - 3.6 W
Power - Maximum input current (@220V) - 83 A
Power - Max output current (+3.3V) - 25 A
Power - Max output current (+5V) - 125 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 83 A
Power - Max output current (-12V) - 0.3 A
Power - Power protection features - Over current, Over power, Over voltage, Overdischarge, Short circuit, Under voltage
Power - Total power - 1000 W
Producer - Asus
ProducerCode - 90YE00L4-B0NA00
ProductName - THOR 1000P2-GAMING
ShortDescription - 1000 | ATX | 135mm | 20 + 4 pin | 80 Plus Platinum| 190 x 150 x 86 mm |
ShortSummaryDescription - ASUS ROG THOR 1000P2-GAMING, 1000 W, 100 - 240 V, 83 A, 125 W, 996 W, 125 W
Technical details - Compliance certificates - RoHS
Technical details - Sustainability certificates - RoHS
Title - ASUS ROG THOR 1000P2-GAMING power supply unit 1000 W 20+4 pin ATX ATX Black, Silver
URL - https://rog.asus.com/power-supply-units/rog-thor/rog-thor-1000p2-gaming-model/
Warranty - 36 months
WarrantyInfo - 10-year
Weight - 5,13
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.37 kg
Weight & dimensions - Width - 190 mm
