Silverstone ST1200-PTS, 1200W, 80PLUS Platinum

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 848159 Product code: 30340
Can be ordered 3 units Availability: 14 days after order approval
Warranty: 2 years (Warranty for business entities 1 year)
272.95 €
Main product parameters All parameters
  • Producer: Silverstone
  • Power output: 1200W
  • 80 PLUS certification: 80 PLUS Platinum
  • Fan size: 120 mm
  • Modular cables: Fully-Modular
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 8 x 6+2pin
Description

We offer to purchase a Silverstone power supply unit with a power capacity of 1200W, which has received the 80 PLUS Platinum energy efficiency certification.

120 mm fans, with which this power supply unit is equipped, will ensure industry standard quiet operation. For especially quiet power supply unit operation, we recommend purchasing a 135 mm or 145 mm diameter fan.

The power supply has been awarded the 80 PLUS Platinum energy efficiency certificate, which ensures at least 92% efficiency at 50% load. This indicates that at least 92 W out of 100 W of power that the power supply receives from the power grid is delivered to the computer components, while the remaining 8 W is lost as heat.

The color of the block is Melna. The block has flat cables, whose color is Melna.

ATX 2.0 standard, which is assigned to this power supply unit, ensures that the unit is equipped only with 6-pin and 8-pin connectors (with respective power of 75W and 150W). For a system with a very powerful graphics card (such as RTX 4070), an ATX 3.* standard unit will be required, and ATX 2.0 will not be sufficient.

The power supply has a Cybenetics Standard ++ noise level certificate, which means its noise level is 30-35 dB.

This power supply unit has fully-modular cables (Fully-modular) – you can connect and disconnect all the included cables as needed, reducing clutter and improving ventilation. This will be useful for those with a partially transparent computer case and for whom the aesthetic factor is particularly important.

Basic information
Cybenetics Efficiency certification : Cybenetics Platinum
Cybenetics Noise level certification : Cybenetics Standard ++
Power supply type : ATX
Power output 1200W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Platinum
Total amperage (+12V) : 100A
Fan size : 120 mm
Functionality
Cable colour : Melna
Lighting : Nav
Color : Melna
Modular cables : Fully-Modular
Ports and equipment
PCI-E 5.0 : Nav
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 24-pin
PCI-E : 8 x 6+2pin
SATA cconnectors : Eight Core
4pin Molex : 6
Case
More detailed specification
category - PC Components|Power Supplies|Modular Power Supplies
Category_1 - Power
Category_2 - Computer Power Supplies
code - SST-ST1200-PTS
ean - 4710007226582
EAN_code - 4710007226582
Manufacturer - Silverstone Technology
Manufacturer_code - 30340
Name - Silverstone SST-ST1200-PTS 1200W PC Power Supply (black 8x PCIe, cable management)
name - SilverStone SST-ST1200-PTS Strider Platinum Series 80 PLUS Platinum, modular - 1200 Watt
Technical_details - Fan(s): 120mm, semi-passive Volume: > 18.00dB(A) (Manufacturer), 32.95dB(A) (Cybenetics, 115V), 31.19dB(A) (Cybenetics, 230V) Cable Management: fully modular Connectors: 1x 20/?24-Pin, 2x 4/?8-Pin ATX12V, 8x 6/?8-Pin PCIe, 8x SATA, 6x IDE, 2x Floppy average efficiency: 91% (80 PLUS, 115V), 91.0% (Cybenetics, 115V), 92.8% (Cybenetics, 230V) Certificates: 80 PLUS Platinum (115V), ETA-A+ (115V), LAMBDA-S++ (115V), ETA-A (230V), LAMBDA-S++ (230V) Dimensions (WxHxD): 150x86x140mm Warranty: five years Quantity of 12V-Rails: 1 +3.3V: 25A +5V: 22A +12V: 100A -12V: 0.3A +5Vsb: 3A PFC: active Form factor: ATX PS/?2 Special features: ErP Lot 6, supports "Haswell" C6/?C7 Low-Power States
Weight - 3,80
