Thermaltake Toughpower PF1 A-RGB, 1200W, 80PLUS Platinum

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 339846 Product code: PS-TPD-1200F3FAPE-1
Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

TopPC.fi website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 2 years (Warranty for business entities 1 year)
Main product parameters All parameters
  • Producer: Thermaltake
  • Power output: 1200W
  • 80 PLUS certification: 80 PLUS Platinum
  • Fan size: 140 mm
  • Modular cables: Fully-Modular
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 8 x 6+2pin
Similar Products
This product Thermaltake Toughpower PF1 A-RGB, 1200W, 80PLUS Platinum
Recommended Thermaltake Toughpower GF, 750W, 80PLUS Gold
Recommended Asus ROG Strix Aura Edition, 1200W, ATX 3.0, 80PLUS Gold
Recommended Seasonic Vertex GX, 1200W, 80PLUS Gold, ATX 3.0, PCIe 5.0
Recommended Corsair HX1500i (2023), 1500W, 80PLUS Platinum
Show similar specs. Hide similar specs.
296.96 €
107.81 €
257.19 €
255.96 €
334.16 €
Basic information
Cybenetics Efficiency certification Cybenetics Platinum Nav Nav Cybenetics Gold Cybenetics Platinum
Cybenetics Noise level certification Cybenetics Standard + Nav Nav Cybenetics A - Cybenetics A -
Power supply type ATX ATX ATX ATX ATX
Power output 1200W 750W 1200W 1200W 1500W
80 PLUS certification 80 PLUS Platinum 80 PLUS Gold 80 PLUS Gold 80 PLUS Gold 80 PLUS Platinum
Total amperage (+12V) 100A 62A 100A 100A 125A
Fan size 140 mm 140 mm 135 mm 135 mm 140 mm
Functionality
Cable colour Melna Melna Melna Melna Melna
Lighting RGB Nav RGB Nav Nav
Color Melna Melna Melna Melna Melna
Modular cables Fully-Modular Fully-Modular Fully-Modular Fully-Modular Fully-Modular
Ports and equipment
PCI-E 5.0 Nav Nav 1 x 600W 12VHPWR 1 x 600W 12VHPWR 1 x 600W 12VHPWR
Processor plug-in 2 x 8-pin(4+4) EPS 1 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS
Motherboard power 24-pin 20+4pin 20+4pin 24-pin 24-pin
PCI-E 8 x 6+2pin 4 X 6+2pin 4 X 6+2pin 3 x 6+2pin 7 x 6+2pin
SATA cconnectors 12 9 5 18 Eight Core
4pin Molex 4 4 4 3 Eight Core
Description

Available for purchase is a power supply produced by Thermaltake with a power output of 1200W. The product has been awarded an 80 PLUS Platinum energy efficiency certificate.

This power supply unit is equipped with a 140 mm fan. It will be significantly quieter than a regular 120 mm fan and will provide adequate cooling at lower speeds, thanks to the massive blade size.

80 PLUS Platinum energy efficiency certificate, received by this power supply unit, guarantees at least 92% efficiency at 50% load. In other words, for every 100 W of energy that the power supply unit receives from the power grid, at least 92 W reaches your computer components, while the remaining 8 W is lost as heat.

The color of the block is Melna. The block has flat cables, whose color is Melna.

ATX 2.0 standard, which is assigned to this power supply unit, ensures that the unit is equipped only with 6-pin and 8-pin connectors (with respective power of 75W and 150W). For a system with a very powerful graphics card (such as RTX 4070), an ATX 3.* standard unit will be required, and ATX 2.0 will not be sufficient.

The power supply has received a Cybenetics Standard + noise level certificate – the noise generated by the unit will be 35-40 decibels.

This power supply has modular cables, which provide the possibility to add video card cables, hard disk cables, etc. as needed from the supplied range. This way, the wire clutter in the computer is reduced, improving ventilation and the aesthetic factor (particularly important for those who purchase a partially transparent case).

The power supply is equipped with RGB lighting.

Basic information
Cybenetics Efficiency certification : Cybenetics Platinum
Cybenetics Noise level certification : Cybenetics Standard +
Power supply type : ATX
Power output 1200W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Platinum
Total amperage (+12V) : 100A
Fan size : 140 mm
Functionality
Cable colour : Melna
Lighting : RGB
Color : Melna
Modular cables : Fully-Modular
Ports and equipment
PCI-E 5.0 : Nav
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 24-pin
PCI-E : 8 x 6+2pin
SATA cconnectors : 12
4pin Molex : 4
More detailed specification
8-pin 12V power connectors - 0
Accessories included -
Category - Root/Electronics/PC parts/PC power supply units
Certificates 80+ - 80 PLUS Platinum
Description -
Designation - CE+WEEE
dimension depth - 160 mm
dimension height - 230 mm
Dimensions -
dimension weight - 4000 g
dimension width - 340 mm
ean - 4713227520607
Eans - 4713227520607
Fan - 14 cm
Floppy power connectors - 1
guarantee - 60
guarantee_type - statutory
MB power connector - 24 pin
Modular power supply - Yes
MOLEX power connectors - 8
name - power supply - Toughpower PF1 ARGB 1200W Platinum TT Premium Edition
Name - Thermaltake Toughpower PF1 1200W
Number of power supply connector 4+4-pin 12V - 0
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 8
Other features -
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
PFC - Active
Power supply - 1200 W
producer - Thermaltake
Producer - Thermaltake
ProducerCode - PS-TPD-1200F3FAPE-1
SATA power connectors - 12
ShortDescription - 1200 | ATX | 140mm | 20+4 | 150mm x 86mm x 180mm | 80 PLUS Platinum | modularny
vendpn - PS-TPD-1200F3FAPE-1
