Endorfy Elementum E5, 550W, 80PLUS

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1088523 Product code: EY7A001
Can be ordered 24 units Availability: 14 days after order approval
Warranty: 3 years
53.05 €
Delivery options
  • Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
  • Courier delivery 11.99 €: 10.12.2024
Main product parameters All parameters
  • Producer: Endorfy
  • Power output: 550W
  • 80 PLUS certification: 80 PLUS (White)
  • Fan size: 120 mm
  • Modular cables: Nav
  • Processor plug-in: 1 x 8-pin(4+4) EPS
  • PCI-E: 1 X 6pin + 1 X 8pin
Description

This Endorfy brand power supply unit has an 80 PLUS (White) energy efficiency certificate and a power output of 550W.

The power of 550W is sufficient for basic computer gaming, web browsing, and Office applications use. The unit is designed for a computer with a budget processor, integrated graphics card, small SSD or hard drive. If you decide to upgrade your computer in the future, you should definitely consider purchasing a more powerful power supply.

120 mm fans, with which this power supply unit is equipped, will ensure industry standard quiet operation. For especially quiet power supply unit operation, we recommend purchasing a 135 mm or 145 mm diameter fan.

The power supply unit has received the 80 PLUS (White) energy efficiency certificate, which guarantees at least 80% efficiency. This means that for every 100W of power that the power supply unit receives from the electrical grid, at least 80W is delivered to your computer components, while the remaining 20W is lost as heat.

The color of the power supply is Melna. It is equipped with flat cables, whose color is Melna.

This power supply unit has been assigned the ATX 2.0 standard. This means that the unit is equipped only with 6-pin and 8-pin connectors, providing 75W and 150W power respectively. It's important to note that this unit will be compatible with RTX 4070 and more powerful cards, but you will need to use the 2x8-pin to 16-pin 12VHPWR adapter included with the graphics card. ATX 2.0 power connectors are not designed to handle the high power fluctuations of modern graphics cards; therefore, if you are building a system with a powerful GPU, such as the RTX 4070, we recommend choosing a power supply unit with the ATX 3.* standard and 12VHPWR (PCIe 5.0) connector.

This power supply has no removable cables and all cables are attached to the power supply. It has a simple design, but it works just as well as a power supply with modular cables.

Basic information
Cybenetics Efficiency certification : Nav
Cybenetics Noise level certification : Nav
Power supply type : ATX
Power output 550W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS (White)
Total amperage (+12V) : 41A
Fan size : 120 mm
Functionality
Cable colour : Melna
Lighting : Nav
Color : Melna
Modular cables : Nav
Ports and equipment
PCI-E 5.0 : Nav
Processor plug-in : 1 x 8-pin(4+4) EPS
Motherboard power : 24-pin
PCI-E : 1 X 6pin + 1 X 8pin
SATA cconnectors : 4
4pin Molex : 2
Case
More detailed specification
8-pin 12V power connectors - 0
Accessories included - Zasilacz ENDORFY Elementum E5 550 W 1× Kabel zasilający 1× Zestaw montażowy 1× Instrukcja obsługi
Category - Root/Electronics/PC parts/PC power supply units
Certificates 80+ - 80 PLUS
Description - Elementum E5 550 W to stabilny zasilacz z certyfikatem 80 PLUS, który sprawdzi się zarówno jako model wykorzystywany przez integratorów PC, jak i w przypadku składania komputera w domowych warunkach. Wyposażony w niezbędne okablowanie umożliwi zasilenie karty graficznej z wykorzystaniem 2 złączy PCI-E (8 oraz 6-pinowego) a dzięki głębokiej czarnej kolorystyce będzie estetycznie prezentował się nawet w mniej okazałych PC. Bezpieczna praca zabezpieczenia OVP, UVP, SCP, OPP i SIP chronią Twój komputer między innymi przed zwarciami i przeciążeniem. Dzięki nim w razie awarii albo przepięcia ze strony instalacji elektrycznej zasilacz się po prostu wyłączy. Cichy wentylator 12-centymetrowy wentylator zaprojektowany w taki sposób, by zapewniać wysoką wydajność chłodzenia bez głośnego szumu. 3 lata gwarancji każdy zasilacz Elementum E5 550 W nabyty w sprzedaży detalicznej objęty jest 3-letnią gwarancją producenta. Bezpieczna praca
Szereg zabezpieczeń (OVP, UVP, SCP, OPP i SIP) chroni Twój komputer między innymi przed zwarciami i przeciążeniem. W praktyce oznacza to, że każda awaria albo przepięcie ze strony instalacji elektrycznej spowoduje natychmiastowe wyłączenie zasilacza Elementum E5 550 W. 12-centymetrowy wentylator
Za chłodzenie w Elementum E5 550 W odpowiada 12-centymetrowy wentylator. Dzięki niemu cały zasilacz utrzymuje niską temperaturę nawet podczas wymagających zadań, a Ty możesz korzystać z PC bez monotonnego szumu w tle.
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
dimensionalWeight - 912
dimension depth - 100 mm
dimension height - 190 mm
Dimensions - 87 x 140 x 150 mm
dimension weight - 1563 g
dimension width - 240 mm
ean - 5903018666105
Eans - 5903018666105
Fan - 12 cm
Floppy power connectors - 0
guarantee - 36
guarantee_type - normal
MB power connector - 24 pin
Modular power supply - No
MOLEX power connectors - 2
name - Elementum E5 550 W
Name - ENDORFY Elementum E5 550 W
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 0
Number of power connectors PCI-E 16-pin Gen 5 - 0
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 1
Other features - Zabezpieczenia: OVP UVP SCP OPP SIP
Packaging data - DFU / User manual - Y
PCI-E 6-pin power connectors - 1
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS
Performance - Power supply unit (PSU) form factor - ATX
PFC - Active
Ports & interfaces - EPS power connector (4+4 pin) - Yes
Ports & interfaces - Length of EPS power connectors (4+4 pin) - 70 cm
Ports & interfaces - Motherboard power cable length - 45 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 4
Ports & interfaces - PCI Express power cable length - 46 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 1
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 2
Ports & interfaces - SATA power cable length - 410
Ports & interfaces - SATA power cable length - 700
Power - AC input frequency - 50 - 60 Hz
Power - Max output current (+3.3V) - 18 A
Power - Max output current (+5V) - 18 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 41 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - OPP (overload protection)
Power - Power protection features - OVP (overvoltage protection)
Power - Power protection features - SCP (short circuit protection)
Power - Power protection features - SIP (surge and shock protection)
Power - Power protection features - UVP (undervoltage protection)
Power - Total power - 550 W
Power supply - 550 W
producer - Endorfy
Producer - Endorfy
producerCode - EY7A001
ProducerCode - EY7A001
productName - Power supply Endorfy Elementum E5 (EY7A001) 550 W
productSize - Normal
SATA power connectors - 4
ShortDescription - 550 | ATX | 120 mm |87mm 140mm 150 | 80 PLUS |
sizeX - 240
sizeY - 190
sizeZ - 100
vendpn - EY7A001
warrantyLength - 36
warrantyType - F
weight - 1560
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 87 mm
Weight & dimensions - Width - 150 mm
