Cougar GEM1050, 1050W, 80PLUS Gold

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1071596 Product code: GEM1050
In stock 3 units
Warranty: 2 years
158.50 €
Delivery options
  • Delivery to Smartpost 6.99 €: on Thursday, 20.03.2025
  • Courier delivery 11.99 €: on Thursday, 20.03.2025
Main product parameters All parameters
  • Producer: Cougar
  • Power output: 1050W
  • 80 PLUS certification: 80 PLUS Gold
  • Fan size: 120 mm
  • Modular cables: Fully-Modular
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 8 x 6+2pin
Description

This Cougar brand power supply unit has an 80 PLUS Gold energy efficiency certificate and a power output of 1050W.

The diameter of this power supply unit's fan is 120 mm, which will ensure quiet operation in mid-range computers. For especially quiet power supply unit operation, we recommend selecting a fan with a 135 mm or 140 mm diameter.

80 PLUS Gold energy efficiency certificate received by this power supply guarantees at least 90% efficiency at 50% load. In other words, for every 100 W of energy the power supply receives from the power grid, at least 90 W goes to your computer components, and the remaining 10 W is lost as heat.

The color of this power supply is Melna. The cable color is Melna and they are flat.

ATX 2.0 standard, which is assigned to this power supply unit, ensures that the unit is equipped only with 6-pin and 8-pin connectors (with respective power of 75W and 150W). For a system with a very powerful graphics card (such as RTX 4070), an ATX 3.* standard unit will be required, and ATX 2.0 will not be sufficient.

Thanks to the fact that this power supply has modular cables, you can add hard drives, video cards, and other components as needed, using the various cables included in the package. This way, there are fewer wires in the computer, which improves ventilation and appearance (especially useful for those who choose a partially transparent case).

Basic information
Cybenetics Efficiency certification : Nav
Cybenetics Noise level certification : Nav
Power supply type : ATX
Power output 1050W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Gold
Total amperage (+12V) : 87.5A
Fan size : 120 mm
Functionality
Cable colour : Melna
Lighting : Nav
Color : Melna
Modular cables : Fully-Modular
Ports and equipment
PCI-E 5.0 : Nav
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 24-pin
PCI-E : 8 x 6+2pin
SATA cconnectors : 12
4pin Molex : 4
Case
More detailed specification
+3.3V - 20 A
+5V - 20 A
+5VSB - 2.5 A (12.5 W)
+12V - 87.5 A (1050 W)
-12V - 0.3 A (3.6 W)
4-pin Peripheral Power Connector - 4
4/8-pin +12V Power Connector - 2
6/8-pin PCI Express Connector - 8
20+4-pin Main Connector - 1
80 Plus Certification - 80 Plus Gold
Box Weight Brutto (kg) - 2.75 kg
Circuit Protection - Over Voltage Undervoltage Over Temperature Over Current Short Circuit Protection Over Power
Depth (mm) - 140 mm
EAN Code - 4710483774102
External Color - Melna
Fan Diameter - 120 mm
Fans Installed Quantity - 1
Height (mm) - 86 mm
Image - https://content.it4profit.com/pimg/s/resize/750x750x750x750/231113150059862267.jpg
Image - https://content.it4profit.com/pimg/s/resize/750x750x750x750/231113150059902898.jpg
Image - https://content.it4profit.com/pimg/s/resize/750x750x750x750/231113150059935337.jpg
Included Accessories - Documentation
Input Frequency - 50/60 Hz
Input Power Connectors Quantity - 1
Input Power Connectors Type - IEC-320 C14
Input Voltage - AC 100-240 V
Maximum Output Power - 1050 W
Modular Power Supply - Yes
Nominal Weight - 2.25 kg
Package Type - Retail
Packs in Box - 1
Pack Weight Brutto (kg) - 2.75 kg
Pack Weight Netto (kg) - 2.25 kg
Pieces in pack - 1
Power Adapter and Power Supply Features - Low noise
Power Device Location - Internal
Power Device Type - Power Supply
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=230104144316147252&THEME=asbis&LANG=lv
ProductCategory - Kabeļi
ProductCode - GEM1050
ProductDescription - Cougar | GEM1050 (Fully Modular) | PSU 80plus Gold
ProductType - Power Supply Unit
S-ATA Connector - 12
Vendor - COUGAR GAMING
Warranty Products Returnable - Yes
Warranty Term (month) - 24 mēneši
Warranty validation Criteria - Serial Number
Width (mm) - 150 mm
