Corsair CX650, 650W, 80PLUS Bronze

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1028884 Product code: CP-9020278-EU
In stock >50 units
Warranty: 3 years
64.52 €
Main product parameters All parameters
  • Producer: Corsair
  • Power output: 650W
  • 80 PLUS certification: 80 PLUS Bronze
  • Fan size: 120 mm
  • Modular cables: Nav
  • Processor plug-in: 1 x 8-pin(4+4) EPS
  • PCI-E: 2 X 6+2pin
Description

We offer to purchase a Corsair power supply unit with a power capacity of 650W, which has received the 80 PLUS Bronze energy efficiency certification.

650W power is sufficient for web browsing, Microsoft Office, and playing simple computer games. The power supply can run a computer with one or two hard drives, a mid-range graphics card (such as the GTX 1650), and a mid-range processor. If you are a serious computer games enthusiast, buy a more powerful power supply.

This power supply unit is equipped with a 120 mm fan, which is the industry standard for ensuring quiet operation in average computers. If you want an especially quiet unit, look for one with a fan diameter of 135 mm or 140 mm.

The power supply has been awarded the 80 PLUS Bronze energy efficiency certificate, which ensures at least 85% efficiency at 50% load. This indicates that at least 85 W out of 100 W of power received by the power supply from the electrical grid is delivered to the computer components, with the remaining 15 W being lost as heat.

The color of the power supply is Melna. It is equipped with flat cables, whose color is Melna.

This power supply unit has been assigned the ATX 2.0 standard. This means that the unit is equipped only with 6-pin and 8-pin connectors, providing 75W and 150W power respectively. It's important to note that this unit will be compatible with RTX 4070 and more powerful cards, but you will need to use the 2x8-pin to 16-pin 12VHPWR adapter included with the graphics card. ATX 2.0 power connectors are not designed to handle the high power fluctuations of modern graphics cards; therefore, if you are building a system with a powerful GPU, such as the RTX 4070, we recommend choosing a power supply unit with the ATX 3.* standard and 12VHPWR (PCIe 5.0) connector.

This power supply has no removable cables and all cables are attached to the power supply. It has a simple design, but it works just as well as a power supply with modular cables.

Basic information
Cybenetics Efficiency certification : Nav
Cybenetics Noise level certification : Nav
Power supply type : ATX
Power output 650W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Bronze
Total amperage (+12V) : 52A
Fan size : 120 mm
Functionality
Cable colour : Melna
Lighting : Nav
Color : Melna
Modular cables : Nav
Ports and equipment
PCI-E 5.0 : Nav
Processor plug-in : 1 x 8-pin(4+4) EPS
Motherboard power : 24-pin
PCI-E : 2 X 6+2pin
SATA cconnectors : 3
4pin Molex : 2
Case
More detailed specification
Additional information in manufacturers website Corsair CX650, 650W, 80PLUS Bronze
8-pin 12V power connectors - 0
Accessories included - CX650 power supply Power cord Mounting screws Headbands
Category - Root/Electronics/PC parts/PC power supply units
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates 80+ - 80 PLUS Bronze
Code - CP-9020278-EU
Description - CORSAIR CX Series power supplies are 80 PLUS Bronze certified, offering operational efficiency of up to 88% with reduced heat emissions and lower energy costs. Their full, continuous power delivery ensures consistent performance, and a thermally controlled, silent 120mm cooling fan ensures quiet operation. With a compact 125mm length that fits easily into most modern PC cases, the CX Series comes with black sheathed cables and a black powder-coated chassis to match the style of your PC. Enjoy confidence in your purchase with a three-year warranty and the support of CORSAIR's global technical team to ensure reliable power for your system.
dimension depth - 100 mm
dimension height - 180 mm
Dimensions - 125 x 150 x 86 mm
dimension weight - 2200 g
dimension width - 240 mm
EAN - 840006670896
ean - 840006670896
Eans - 840006670896
EAN_code - 0840006670896
Fan - 12 cm
Floppy power connectors - 0
guarantee - 36
guarantee_type - normal
Manufacturer - Corsair
Manufacturer_code - CP-9020278-EU
MB power connector - 24 pin
Modular power supply - No
MOLEX power connectors - 0
name - CORSAIR CX650 550W 80+ BRONZE N.MODULAR ATX EU
Name - Corsair CX650 650W, PC power supply (black, 2x PCIe, 650 watts)
Name - Corsair CX650 CP-9020278-EU
Name - Corsair | 80 PLUS Bronze ATX Power Supply (EU) | CX Series CX650 | 650 W
Number of power connectors 12VHPWR - 0
Number of power connectors PCI-E 16-pin Gen 5 - 0
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 0
Other features -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 170.00 mm
Package features > Gross height (mm) - 96.00 mm
Package features > Gross width (mm) - 160.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 331 pc(s)
Package features > Paper/Pasteboard - 500.00 g
Package features > Plastic (No PET) - 100.00 g
Package features > Tare weight (kg) - 0.60 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEEE tax - No
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 2
PFC - None
Power > Nominal power - 650 W
Power supply - 650 W
producer - Corsair
Producer - Corsair
ProducerCode - CP-9020278-EU
Producer product family - 80 PLUS Bronze ATX Power Supply (EU)
Producer product name - CX Series CX650
SATA power connectors - 3
ShortDescription - 650 | ATX | 120 mm | 20 + 4 pin | 150mm x 86mm x 125mm | 80 PLUS Bronze|
Technical details > Gross weight - 2.92 kg
Technical details > Net weight - 2.32 kg
Technical details > Producer - Corsair
vendpn - CP-9020278-EU
Warranty - 120
Warranty - 120 month(s)
Weight - 2,20
