Zyxel NWA50AX 2 PCS

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 805503 Product code: NWA50AX-EU0102FX2
Can be ordered 23 units Availability: 14 days after order approval
Warranty: 2 years (Warranty for business entities 1 year)
183.81 €
Delivery options
  • Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
  • Courier delivery 11.99 €: 27.11.2024
Main product parameters All parameters
  • Speed index: 1800
  • Type of device: Access Point
  • Wi-Fi standard: Wi-Fi 6 (802.11ax)
Basic information
Speed index : 1800
Type of device Access Point

Access Point - bezvadu piekļuves punkts, kas nodrošina kabeļu tīkla paplašināšanas pārraidi bezvadu tīklā izmantojot vienu LAN pieslēgvietu. Access point nav rūteris, un nespēj sadalīt vienu interneta pieslēguma adresi vairākiem datoriem, tamdēļ šo iekārtu slēdziet tikai aiz esoša kabeļu rūtera.

Router, jeb maršrutētājs - bezvadu piekļuves punkts, kas nodrošina viena interneta pieslēguma sadalīšanu vairākiem datoriem, gan caur tīkla vadiem, gan bezvadu tīklā. Parasti bezvadu maršrutētājam ir viena kabeļu interneta pieslēgvieta, četras datoru pieslēgvietas (kuras var papildināt, izmantojot switch komutatoru) un antenas, kas nodrošina apraidi datoriem un citām WiFi iekārtām.

Range Extender - bezvadu tīkla apraides attāluma pastiprinātājs. Paredzēts esoša signāla pastiprināšanai, lai palielinātu uzveršanas un pārraides attālumu.

Wifi adapter - Bezvadu tīkla karte, paredzēta datora pieslēgšanai pie bezvadu WiFi rūtera vai piekļuves punkta. PCI, PCI-E ir paredzēti galddatoriem, savukārt PCMCIA un USB - portatīvajiem datoriem. Jāpiebilst, ka lielākā daļa portatīvo datoru jau rūpnīcā tiek komplektēti ar bezvadu tīkla kartēm.

USB tīkla karte ir pēdējā izvēle, jo USB2.0 caurlaidības ātrums ir samērā zems ~22MB/s, kas nozīmē to, ka netiks izmantots bezvadu tīkla maksimālais iespējamais ātrums. Ja ir iespēja, labāk izvēlēties kādu citu pieslēguma veidu.

Wi-Fi standard : Wi-Fi 6 (802.11ax)
Functionality
3G/4G support Nav

A possibility to put the SIM card of mobile operators or the USB Dongle adapter in the router providing access to the 3G mobile Internet.

Prior to buying a router with the 3G support you should verify whether the device supports the 3G USB Dongle receiver of the particular mobile communications operator at the manufacturer's website.

Band mode Dual-Band

SingleBand is a standard wireless technology characteristic of all the modern wireless devices.

DualBand is 2.4GHz with an additional 5.0GHz channel providing better receiving of the signal and more stable high-speed operation. For using this function both devices, i.e. the router and the wireless network card, have to support the DualBand mode.

Ethernet 100/1000

LAN or ethernet cables connection slots operational mode.

10/100 MB.s is the standard speed characteristic of almost all the routers.

10/100/1000 MB.s, or GigaBit is tens of times faster standard which, in combination of GigaBit LAN network cards, provides great data transmission speed advantages between computers connected within the internal network. This solution is usually required in offices where large data volumes are copied between computers or fast Internet connection is used (no ~30 MB/s) simultaneously in several computers.



Ports and equipment
LAN ports : 1
Wireless
  • Alternatives
  • Alternatives
More detailed specification
Antenna - Antenna gain level (max) - 4 dBi
Antenna - Antenna type - Internal
Brand - Zyxel
BrandPartCode - NWA50AX-EU0102F
Category - Wireless Access Points
Design - Placement - Ceiling, Wall
Design - Product colour - White
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - Band steering - Yes
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Fast roaming - Yes
Features - Maximum data transfer rate - 1775 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 575 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 1200 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
GTIN - 4718937618743
Logistics data - Country of origin - China
Logistics data - Harmonized System (HS) code - 85176990
Logistics data - Master (outer) case gross weight - 13 kg
Logistics data - Master (outer) case height - 332 mm
Logistics data - Master (outer) case length - 483 mm
Logistics data - Master (outer) case width - 315 mm
Logistics data - Products per master (outer) case - 20 pc(s)
LongSummaryDescription - Zyxel NWA50AX. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1775 Mbit/s. Security algorithms: WPA, WPA2, WPA3. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging content - AC adapter included - Yes
Packaging content - Mounting kit - Yes
Packaging content - Number of products included - 1 pc(s)
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Input current - 0.3 A
Power - Output current - 1.5 A
Power - Output voltage - 12 V
Power - Power over Ethernet (PoE) - Yes
ProductName - NWA50AX
Security - Auto Wireless Distribution System (WDS) - Yes
Security - MAC address filtering - Yes
Security - Security algorithms - WPA, WPA2, WPA3
ShortSummaryDescription - Zyxel NWA50AX, 2.4 GHz, 5 GHz, 1775 Mbit/s, WPA, WPA2, WPA3, 10,100,1000 Mbit/s
Title - Zyxel NWA50AX 1775 Mbit/s White Power over Ethernet (PoE)
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 37.5 mm
Weight & dimensions - Weight - 290 g
Weight & dimensions - Width - 140 mm
