Antenna - Antenna direction type - Omni-directional
Antenna - Antenna features - Integrated antenna
Antenna - Antenna gain level (max) - 4 dBi
Antenna - Antenna type - Internal
ARTIKEL1 - AC1750 WLAN GB ACCESS POINT 5PC
ARTIKEL2 - 5 PACK
Brand - TP-Link
BrandPartCode - EAP245(5-PACK)
Category - Wireless Access Points
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - LED indicators - Yes
Design - Placement - Ceiling, Wall
Design - Product colour - White
Design - Reset button - Yes
EAN - 4897098687017
EANCode - 4897098687017
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Airtime Fairness (ATF) - Yes
Features - Automatic channel scanning - Yes
Features - Automatic channel selection - Yes
Features - Band steering - Yes
Features - BeamForming - Yes
Features - Cabling technology - 10/100/1000Base-T(X)
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Frequency band - 2.4, 5 GHz
Features - Maximum data transfer rate - 1750 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 450 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 1300 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - Transmitting power - 27 dBmW
Features - Transmitting power (CE) - 20 - 23 dBm
Features - Transmitting power (FCC) - 24 dBm
Features - Virtual LAN features - SSID-based VLAN assignment
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Features - Wireless isolation - Yes
Gewicht - 3.07
Gross Weight Kg - 3,8
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 0840030707018
GTIN - 840030707018
GTIN - 4897098687017
GTIN - 4897098687024
HERSTELLER - TP-LINK
HSTNUMMER - EAP245(5-PACK)
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Superior Wi-Fi Speeds and PerformanceQCA enterprise class chipsets, dedicated high-power amplifier and professional antenna along with the latest generation 802.11ac Wave 2 MU-MIMO technology, ensure superior 1750 Mbps Wi-Fi speeds and long-range coverage over 2.4GHz and 5GHz wireless bands.Seamless Roaming802.11k/802.11v seamless roaming switches clients automatically to the access point with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.Secure Guest Network with Facebook W-Fi and SMS LoginGuest Network provides secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.Multiple PoE Options for Easy InstallationEAP245 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter. The addition of elegant appearance and simple mounting design for easy attachment to a wall or ceiling further makes deployment effortless and flexible.Free Cloud Centralized Management- Anytime, AnywhereOmada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.Easy Management with the Omada AppFollow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smartphone or tablet.
LongProductName - Kit 5x EAP245, 12.3W, IEEE 802.11ac/n/g/b/a, 2x RJ-45, 2.4/5 GHz
LongSummaryDescription - TP-Link Omada EAP245(5-PACK). Maximum data transfer rate: 1750 Mbit/s, Maximum data transfer rate (2.4 GHz): 450 Mbit/s, Maximum data transfer rate (5 GHz): 1300 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, Service Set Identifier (SSID) features: Multiple SSIDs. Management protocols: HTTP/HTTPS. Power over Ethernet (PoE) type supported: Passive PoE, AC input voltage: 48 V, Input current: 1.5 A. Placement: Ceiling, Wall, Product colour: White, Cable lock slot type: Kensington
Management features - Syslog - Yes
Management features - Web-based management - Yes
Manufacturer Code - EAP245(5-PACK)
Manufacturer Name - TP-LINK
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging content - Cables included - AC
Packaging content - Mounting kit - Yes
Packaging content - Number of products included - 5 pc(s)
Packaging content - PoE adapter included - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 285.5 mm
Packaging data - Package height - 283.5 mm
Packaging data - Package weight - 3.54 kg
Packaging data - Package width - 257.5 mm
Performance - Compatible operating systems - Microsoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Power - AC input voltage - 48 V
Power - Input current - 1.5 A
Power - Power consumption (typical) - 12.3 W
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Passive PoE
ProductName - EAP245(5-PACK)
Protocols - Management protocols - HTTP/HTTPS
Security - Access Control List (ACL) - Yes
Security - MAC address filtering - Yes
Security - Number of SSID supported - 16
Security - Security algorithms - 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Security - Service Set Identifier (SSID) features - Multiple SSIDs
Short description - TP-LINK WLAN AC1750 Access Point Dualband EAP245(5-Pack)
ShortSummaryDescription - TP-Link Omada EAP245(5-PACK), 1750 Mbit/s, 450 Mbit/s, 1300 Mbit/s, 10,100,1000 Mbit/s, 2.4, 5 GHz, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Stck_Kart - 2
Stck_Pal - 2
Storno - Y
Sustainability - Sustainability certificates - Federal Communications Commission (FCC), CE, RoHS
Sustainability - Sustainability compliance - Yes
Title - TP-Link Omada EAP245(5-PACK) wireless access point 1750 Mbit/s White Power over Ethernet (PoE)
URL - https://www.tp-link.com/us
WarrantyInfo -
Weight & dimensions - Depth - 180 mm
Weight & dimensions - Height - 47.5 mm
Weight & dimensions - Width - 180 mm
