Zyxel WAX610D

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 604635 Product code: WAX610D-EU0101F
Can be ordered 4 units Availability: 14 days after order approval
Warranty: 3 years
393.93 €
Delivery options
  • Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
  • Courier delivery 11.99 €: 10.12.2024
Main product parameters All parameters
  • Speed index: 3000
  • Type of device: Access Point
  • Wi-Fi standard: Wi-Fi 6 (802.11ax)
Basic information
Speed index : 3000
Type of device Access Point

Access Point - bezvadu piekļuves punkts, kas nodrošina kabeļu tīkla paplašināšanas pārraidi bezvadu tīklā izmantojot vienu LAN pieslēgvietu. Access point nav rūteris, un nespēj sadalīt vienu interneta pieslēguma adresi vairākiem datoriem, tamdēļ šo iekārtu slēdziet tikai aiz esoša kabeļu rūtera.

Router, jeb maršrutētājs - bezvadu piekļuves punkts, kas nodrošina viena interneta pieslēguma sadalīšanu vairākiem datoriem, gan caur tīkla vadiem, gan bezvadu tīklā. Parasti bezvadu maršrutētājam ir viena kabeļu interneta pieslēgvieta, četras datoru pieslēgvietas (kuras var papildināt, izmantojot switch komutatoru) un antenas, kas nodrošina apraidi datoriem un citām WiFi iekārtām.

Range Extender - bezvadu tīkla apraides attāluma pastiprinātājs. Paredzēts esoša signāla pastiprināšanai, lai palielinātu uzveršanas un pārraides attālumu.

Wifi adapter - Bezvadu tīkla karte, paredzēta datora pieslēgšanai pie bezvadu WiFi rūtera vai piekļuves punkta. PCI, PCI-E ir paredzēti galddatoriem, savukārt PCMCIA un USB - portatīvajiem datoriem. Jāpiebilst, ka lielākā daļa portatīvo datoru jau rūpnīcā tiek komplektēti ar bezvadu tīkla kartēm.

USB tīkla karte ir pēdējā izvēle, jo USB2.0 caurlaidības ātrums ir samērā zems ~22MB/s, kas nozīmē to, ka netiks izmantots bezvadu tīkla maksimālais iespējamais ātrums. Ja ir iespēja, labāk izvēlēties kādu citu pieslēguma veidu.

Wi-Fi standard : Wi-Fi 6 (802.11ax)
Functionality
3G/4G support Nav

A possibility to put the SIM card of mobile operators or the USB Dongle adapter in the router providing access to the 3G mobile Internet.

Prior to buying a router with the 3G support you should verify whether the device supports the 3G USB Dongle receiver of the particular mobile communications operator at the manufacturer's website.

Band mode Dual-Band

SingleBand is a standard wireless technology characteristic of all the modern wireless devices.

DualBand is 2.4GHz with an additional 5.0GHz channel providing better receiving of the signal and more stable high-speed operation. For using this function both devices, i.e. the router and the wireless network card, have to support the DualBand mode.

Ethernet 100/1000

LAN or ethernet cables connection slots operational mode.

10/100 MB.s is the standard speed characteristic of almost all the routers.

10/100/1000 MB.s, or GigaBit is tens of times faster standard which, in combination of GigaBit LAN network cards, provides great data transmission speed advantages between computers connected within the internal network. This solution is usually required in offices where large data volumes are copied between computers or fast Internet connection is used (no ~30 MB/s) simultaneously in several computers.



Ports and equipment
LAN ports : 4
Wireless
More detailed specification
Accessories included - Płyta montażowa Śruby mocujące
Antenna - Built-in
Antenna - Antenna type - Internal
Antenna gain - 6 dBi
ARTIKEL1 - WIFI 6 NEBULAFLEX AP
ARTIKEL2 - 1Y NEBULAPRO LIZENZ
Brand - Zyxel
BrandPartCode - WAX610D-EU0101F
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Color - White
Description - Prawdziwe doświadczenie WiFi 6 dla każdego WAX610D został zaprojektowany, aby zapewnić prawdziwe wrażenia WiFi 6 wszystkim użytkownikom w różnych typach zastosowań. Dzięki sześciu łączom radiowym (strumieniom przestrzennym) (4x4: 4 przy 5 GHz, 2x2: 2 przy 2,4 GHz), funkcjom OFDMA i MU-MIMO, WAX610D zapewnia fantastyczną wydajność sieci WLAN AP, który pasuje do Twoich potrzeb Oczywiście rozumiemy, że montaż AP na suficie nie zawsze jest możliwy. W trudnych warunkach, takich jak magazyny, zabytkowe budynki lub stylowe hotele, estetyka budynku ostatecznie odgrywa główną rolę. WAX610D jest wyposażony w regulowaną antenę do montażu sufitowego i ściennego (podwójna optymalizacja). Dzięki temu AP można zamontować na ścianie lub suficie bez pogorszenia wydajności i zasięgu. Zarządzanie z dużą elastycznością WAX610D obsługuje NebulaFlex Pro. Daje to użytkownikom pełną elastyczność w łatwym przełączaniu między trybem zarządzanym w chmurze, zarządzanym przez kontroler i trybem autonomicznym. Masz wybór, który tryb najlepiej odpowiada Twoim potrzebom.
Design - Placement - Wall
Design - Product colour - White
dimensionalWeight - 672
dimension depth - 65 mm
dimension height - 215 mm
Dimensions - 180 x 180 x 39 mm / 7.09 x 7.09 x 1.54 cale
dimension weight - 870 g
dimension width - 215 mm
ean - 4718937612970
EAN - 4718937612970
EANCode - 4718937612970
EAN_code - 4718937612970
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 10,100,1000,2500 Mbit/s
Features - Ethernet LAN data rates - 100
Features - Ethernet LAN data rates - 1000 Mbit/s
Features - Ethernet LAN data rates - 2500 Mbit/s
Features - Maximum data transfer rate - 2400 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 575 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 2400 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11ax
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - VLAN support - Yes
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Broadba
GTIN - 4718937612970
guarantee - -1
guarantee_type - external
HERSTELLER - ZYXEL
HSTNUMMER - WAX610D-EU0101F
I/O ports - 1 x 10/100/1000 Mbit/s LAN / DMZ
I/O ports - 1 x 10/100/1000/2500 RJ-45 port (WAN)
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - True WiFi 6 experience for allThe WAX610D is designed to deliver the true WiFi 6 experience to users for various types of applications. Featuring 6 spatial streams (4x4:4 in 5GHz, 2x2:2 in 2.4GHz ), OFDMA and MU-MIMO capabilities, the WAX610D can provide fabulous efficiency for your wireless networking.An access point that fits your needWe understand that mounting an access point to the ceiling isn’t always possible due to the challenging environments like warehouses, historical buildings or stylish hotels where the aesthetics of the building are a priority. The WAX610D is equipped with a dual-optimized antenna that is selectable, allowing the access point to be mounted on the wall or on the ceiling without compromising on performance and coverage.Hassle-free upgradeTo meet the growing demands for WiFi connectivity, the WAX610D enhances the network capacity with 2.90 Gbps WiFi speed and 2.5 Gbps multi-gigabit Ethernet port, which allows multi-gigabit speed run on the existing infrastructure without the need of re-cabling. The WAX610D enables organizations such as schools, hotels, and retail stores to upgrade to the latest WiFi 6 technology easily without breaking the bank.Manage it your way!The WAX610D comes with the support of NebulaFlex Pro, which offers the full flexibility for users to easily switch between cloud-managed, controller-managed, and standalone modes. You can choose the appropriate managed-mode best suited for your needs.
LongProductName - WAX610D, Single Pack 802.11ax 2x2, Dual Optimized Antenna, exclude Power Adaptor-1 year NCC Pro Pack license bundled, Multigig Port, EU and UK, Unified AP, ROHS, WIFI 6
LongSummaryDescription - Zyxel WAX610D-EU0101F. 2.4 GHz, 5 GHz, Maximum data transfer rate: 2400 Mbit/s. Security algorithms: EAP, WEP, WPA, WPA2. Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Power over Ethernet (PoE). Product colour: White
Management, monitoring, configuration - Access management L2-isolation MAC filtering Rogue AP detection
Manufacturer - Zyxel
Manufacturer_code - WAX610D-EU0101F
MPN - WAX610D-EU0101F
name - WAX610D SP 802.11ax 2x2 1Y NCC Pro Pack Bundle
Name - ZyXEL WAX610D
Name - Zyxel WAX610D, access point
Network architecture - GigabitEthernet
Number of antennas - 2
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -30 - 70 °C
Other features - Specyfikacja środowiskowa Temperature -20°C to 50°C / -4°F to 122°F Humidity 10% to 95% (Non-condensing)
Packaging content - Number of products included - 1 pc(s)
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - AC input voltage - 12 V
Power - Power over Ethernet (PoE) - Yes
Power supply - Zarządzanie dostępem Izolacja L2 Filtrowanie adresów MAC Wykrywanie nielegalnych punktów dostępu
producer - Zyxel
producerCode - WAX610D-EU0101F
ProductName - WAX610D-EU0101F
productName - Zyxel WAX610D-EU0101F wireless access point 2400 Mbit/s White Power over Ethernet (PoE)
productSize - Normal
Security - Authentication WPA WPA2 WPA3-Enterprise EAP IEEE 802.1X RADIUS authentication
Security - MAC address filtering - Yes
Security - Remote Authentication Dial-In User Service (RADIUS) - Yes
Security - Security algorithms - EAP
Security - Security algorithms - EAP, WEP, WPA, WPA2
Security - Security algorithms - WEP
Security - Security algorithms - WPA
Security - Security algorithms - WPA2
ShortSummaryDescription - Zyxel WAX610D-EU0101F, 2.4 GHz, 5 GHz, 2400 Mbit/s, EAP, WEP, WPA, WPA2, 10,100,1000,2500 Mbit/s
sizeX - 235
sizeY - 220
sizeZ - 65
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 5
Stck_Pal - 0
Storno - Y
System Requirements -
Technical_details - WAX610D, access point The WAX610D is designed to offer the true WiFi 6 experience to all users in different types of applications. With six radio links (spatial streams) (4x4:4 at 5 GHz, 2x2:2 at 2.4 GHz), OFDMA and MU-MIMO capabilities, the WAX610D supplies the WLAN with dreamlike efficiency. The WAX610D supports NebulaFlex Pro. This gives users full flexibility to easily switch between cloud-managed, controller-managed and standalone mode. Type: Access Point EAN code: 4718937612970 Manufacturer part number: WAX610D-EU0101F Design: wall mounting Connections: Network | RJ-45 | 2x (of which: 1x 10/100/1000, 1x 100/1000/10000) Connectors: Features | Auto-MDI/MDIX, passive PoE (power supply via PoE), RJ-45 ports PoE capable: 1x WLAN: Standards | Wi-Fi 3 (802.11a), Wi-Fi 3 (802.11b), Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 ( 802.11ax) WiFi: Encryption | WPA, WPA2, WPA2-PSK, WPA3, WPA3-ENT WLAN: transfer rate | 575 MBit/s (WLAN 2.4 GHz), 2400 MBit/s (WLAN 5 GHz) Routing & Switching: Layers | Smart Managed, Cloud Managed Power supply: power supply connector Feature: IPv6, VLANs, WMM, U-APSD, DiffServ marking Dimensions: Width: 180mm x Height: 180mm x Depth/Length: 39mm Weight: 545 grams
Title - Zyxel WAX610D-EU0101F wireless access point 2400 Mbit/s White Power over Ethernet (PoE)
URL - https://www.zyxel.com/products_services/802-11ax--WiFi-6--Dual-Radio-Unified-Pro-Access-Point-WAX610D/overview
vendpn - WAX610D-EU0101F
WarrantyInfo -
warrantyLength - 60
warrantyType - F
Weight - 0,87
Weight - 0.86
Weight - 1.2 kg
weight - 865
Weight & dimensions - Depth - 216 mm
Weight & dimensions - Height - 64 mm
Weight & dimensions - Weight - 780 g
Weight & dimensions - Width - 229 mm
