Tenda F3 300Mbps Wireless Router

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 121852 Product code: TENDA F3 300
Can be ordered 82 units Availability: 14 days after order approval
Warranty: 3 years
23.72 €
Main product parameters All parameters
  • Type of device: Router
Description
Basic information
Type of device Router

Access Point - bezvadu piekļuves punkts, kas nodrošina kabeļu tīkla paplašināšanas pārraidi bezvadu tīklā izmantojot vienu LAN pieslēgvietu. Access point nav rūteris, un nespēj sadalīt vienu interneta pieslēguma adresi vairākiem datoriem, tamdēļ šo iekārtu slēdziet tikai aiz esoša kabeļu rūtera.

Router, jeb maršrutētājs - bezvadu piekļuves punkts, kas nodrošina viena interneta pieslēguma sadalīšanu vairākiem datoriem, gan caur tīkla vadiem, gan bezvadu tīklā. Parasti bezvadu maršrutētājam ir viena kabeļu interneta pieslēgvieta, četras datoru pieslēgvietas (kuras var papildināt, izmantojot switch komutatoru) un antenas, kas nodrošina apraidi datoriem un citām WiFi iekārtām.

Range Extender - bezvadu tīkla apraides attāluma pastiprinātājs. Paredzēts esoša signāla pastiprināšanai, lai palielinātu uzveršanas un pārraides attālumu.

Wifi adapter - Bezvadu tīkla karte, paredzēta datora pieslēgšanai pie bezvadu WiFi rūtera vai piekļuves punkta. PCI, PCI-E ir paredzēti galddatoriem, savukārt PCMCIA un USB - portatīvajiem datoriem. Jāpiebilst, ka lielākā daļa portatīvo datoru jau rūpnīcā tiek komplektēti ar bezvadu tīkla kartēm.

USB tīkla karte ir pēdējā izvēle, jo USB2.0 caurlaidības ātrums ir samērā zems ~22MB/s, kas nozīmē to, ka netiks izmantots bezvadu tīkla maksimālais iespējamais ātrums. Ja ir iespēja, labāk izvēlēties kādu citu pieslēguma veidu.

Functionality
3G/4G support Nav

A possibility to put the SIM card of mobile operators or the USB Dongle adapter in the router providing access to the 3G mobile Internet.

Prior to buying a router with the 3G support you should verify whether the device supports the 3G USB Dongle receiver of the particular mobile communications operator at the manufacturer's website.

Band mode Single Band

SingleBand is a standard wireless technology characteristic of all the modern wireless devices.

DualBand is 2.4GHz with an additional 5.0GHz channel providing better receiving of the signal and more stable high-speed operation. For using this function both devices, i.e. the router and the wireless network card, have to support the DualBand mode.

Ethernet 10/100

LAN or ethernet cables connection slots operational mode.

10/100 MB.s is the standard speed characteristic of almost all the routers.

10/100/1000 MB.s, or GigaBit is tens of times faster standard which, in combination of GigaBit LAN network cards, provides great data transmission speed advantages between computers connected within the internal network. This solution is usually required in offices where large data volumes are copied between computers or fast Internet connection is used (no ~30 MB/s) simultaneously in several computers.



Ports and equipment
LAN ports : 3
Wireless card
  • Alternatives
  • Alternatives
More detailed specification
Antenna - Antenna design - External
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 3
Category - Root/Electronics/Networks and communication/Routers
Design - LED indicators - LAN, System, WAN, WPS
Design - Product colour - White
Design - Product type - Tabletop router
dimensionalWeight - 730
Eans - 6932849427141
Features - Certification - CE, RoHS, 3C, EAC, NOM, IC
Logistics data - Harmonized System (HS) code - 85176990
Management features - Reset button - Yes
Management features - Web-based management - Yes
Management features - WPS push button - Yes
Name - Tenda F3
Network - Cabling technology - 10/100Base-T(X)
Network - Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b) - -89 dBmW
Network - Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11g) - -74 dBmW
Network - Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n) - -72 dBmW
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN interface type - Fast Ethernet
Network - Networking standards - IEEE 802.11b
Network - Networking standards - IEEE 802.11g
Network - Networking standards - IEEE 802.11n
Network - Port forwarding - Yes
Network - VPN support - PPTP, L2TP
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging content - Cables included - DC
Packaging content - Manual - Yes
Packaging content - Quick start guide - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - Memory card slot(s) - No
Power - Output current - 0.6 A
Power - Output voltage - 9 V
Power - Power consumption (typical) - 1.9 W
Power - Power source type - DC
Producer - Tenda
producerCode - F3
ProducerCode - F3
productName - Tenda F3 wireless router Fast Ethernet White
productSize - Normal
Protocols - DHCP server - Yes
Security - DMZ support - Yes
Security - Filtering - Yes
Security - MAC address filtering - Yes
Security - Security algorithms - 64-bit WEP
Security - Security algorithms - 128-bit WEP
Security - Security algorithms - WPA-PSK
Security - Security algorithms - WPA2-PSK
Security - Security algorithms - WPS
Security - System event log - Yes
Security - URL filtering - Yes
ShortDescription - Router bezprzewodowy | 802.1b/802.11g/802.1n | WPA/WPA2/WPA-PSK/WPA2-PSK | 300 Mbps | 2,4 GHz | Routing | bezprzewodowy DSL | 3x zewnętrzna antena
sizeX - 290
sizeY - 180
sizeZ - 70
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
warrantyLength - 36
warrantyType - G
weight - 500
Weight & dimensions - Depth - 87 mm
Weight & dimensions - Height - 25 mm
Weight & dimensions - Width - 133 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - WLAN data transfer rate (max) - 300 Mbit/s
