MikroTik RB941-2nD-TC Access Point

Name: MikroTik RB941-2nD-TC Access Point
Brand: MikroTik
SKU: 118225
Price: 24.69 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 118225 Product code: MT RB941-2nD-TC

In stock 44 units

Warranty: 2 years (Warranty for business entities 1 year)

Compare

Delivery options

Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
Courier delivery 11.99 €: 29.11.2024

Main product parameters All parameters

Speed index: N/A
Type of device: Access Point
Wi-Fi standard: Wi-Fi 4 (802.11n)

Basic information

Speed index : N/A

Type of device Access Point

Access Point - bezvadu piekļuves punkts, kas nodrošina kabeļu tīkla paplašināšanas pārraidi bezvadu tīklā izmantojot vienu LAN pieslēgvietu. Access point nav rūteris, un nespēj sadalīt vienu interneta pieslēguma adresi vairākiem datoriem, tamdēļ šo iekārtu slēdziet tikai aiz esoša kabeļu rūtera.

Router, jeb maršrutētājs - bezvadu piekļuves punkts, kas nodrošina viena interneta pieslēguma sadalīšanu vairākiem datoriem, gan caur tīkla vadiem, gan bezvadu tīklā. Parasti bezvadu maršrutētājam ir viena kabeļu interneta pieslēgvieta, četras datoru pieslēgvietas (kuras var papildināt, izmantojot switch komutatoru) un antenas, kas nodrošina apraidi datoriem un citām WiFi iekārtām.

Range Extender - bezvadu tīkla apraides attāluma pastiprinātājs. Paredzēts esoša signāla pastiprināšanai, lai palielinātu uzveršanas un pārraides attālumu.

Wifi adapter - Bezvadu tīkla karte, paredzēta datora pieslēgšanai pie bezvadu WiFi rūtera vai piekļuves punkta. PCI, PCI-E ir paredzēti galddatoriem, savukārt PCMCIA un USB - portatīvajiem datoriem. Jāpiebilst, ka lielākā daļa portatīvo datoru jau rūpnīcā tiek komplektēti ar bezvadu tīkla kartēm.

USB tīkla karte ir pēdējā izvēle, jo USB2.0 caurlaidības ātrums ir samērā zems ~22MB/s, kas nozīmē to, ka netiks izmantots bezvadu tīkla maksimālais iespējamais ātrums. Ja ir iespēja, labāk izvēlēties kādu citu pieslēguma veidu.

Wi-Fi standard : Wi-Fi 4 (802.11n)

Functionality

3G/4G support Nav

A possibility to put the SIM card of mobile operators or the USB Dongle adapter in the router providing access to the 3G mobile Internet.

Prior to buying a router with the 3G support you should verify whether the device supports the 3G USB Dongle receiver of the particular mobile communications operator at the manufacturer's website.

Band mode Single Band

SingleBand is a standard wireless technology characteristic of all the modern wireless devices.

DualBand is 2.4GHz with an additional 5.0GHz channel providing better receiving of the signal and more stable high-speed operation. For using this function both devices, i.e. the router and the wireless network card, have to support the DualBand mode.

Ethernet 10/100

LAN or ethernet cables connection slots operational mode.

10/100 MB.s is the standard speed characteristic of almost all the routers.

10/100/1000 MB.s, or GigaBit is tens of times faster standard which, in combination of GigaBit LAN network cards, provides great data transmission speed advantages between computers connected within the internal network. This solution is usually required in offices where large data volumes are copied between computers or fast Internet connection is used (no ~30 MB/s) simultaneously in several computers.

Ports and equipment

LAN ports : 10

Wireless

Without
WiFi Adapter USB (+8.67 €)
Gembird Adapter Mini USB WiFi 300 Mbps
Alternatives
WiFi Adapter PCI-E 1x (+13.16 €)
TP-LINK TL-WN781ND, PCI-E x1 WiFi Adapter
Alternatives

More detailed specification

Additional information in manufacturers website MikroTik RB941-2nD-TC Access Point

10/100M LAN Ports - 4
Accessories included -
Antenna - Antenna gain level (max) - 1.5 dBi
Antenna - Antennas quantity - 2
Antenna gain - 1.5 dBi
brand - MikroTik
category - MikroTik > Wi-Fi mājai un ofisam > hAP
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Code - RB941-2nD-TC
Color - Blue
Color - White
Description - Home Access Point lite (hAP lite) jest idealnym małym urządzeniem dla Twojego mieszkania, domu lub biura. Obsługuje WPS wyzwalany przyciskiem, dla wygody nie wpisywania skomplikowanego hasła, gdy ktoś chce mieć bezprzewodowy dostęp do Internetu, a także można mu nakazać przejście w tryb cAP i dołączenie do centralnie zarządzanej sieci CAPsMAN poprzez naciśnięcie przycisku. Oczywiście urządzenie pracuje pod kontrolą systemu RouterOS ze wszystkimi funkcjami, kształtowaniem pasma, firewallem, kontrolą dostępu użytkowników i wieloma innymi. hAP lite wyposażony jest w wydajny procesor 650MHz, 32MB RAM, cztery porty Fast Ethernet oraz licencję RouterOS L4. W zestawie znajduje się zasilacz USB.
Description - The home Access Point lite (hAP lite) is an ideal little device for your apartment, house or office. It supports button triggered WPS, for the convenience of not typing a complicated password when somebody wants to have wireless internet access, and can also be told to change to cAP mode and join a CAPsMAN centrally managed network by the push of a button. Of course, the device runs RouterOS with all the features, bandwidth shaping, firewall, user access control and many others. The hAP lite is equipped with a powerful 650MHz CPU, 32MB RAM, dual chain 2.4GHz onboard wireless, four Fast Ethernet ports and a RouterOS L4 license. USB power supply is included.
Design - Internal - No
Design - Product colour - Blue
Design - Product colour - White
Design - WPS push button - Yes
dimensionalWeight - 296
dimension depth - 55 mm
dimension height - 180 mm
Dimensions - 124 x 100 x 54 mm
Dimensions - 124x100x54mm
dimension weight - 250 g
dimension width - 120 mm
EAN - 4752224003102
ean - 4752224003102
Features - 2.4 GHz - Yes
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 100
Features - Maximum data transfer rate - 300 Mbit/s
Features - Modulation - DSSS
Features - Modulation - OFDM
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Spread spectrum method - DSSS
Features > MU-MiMO - Yes
Features > Product type - Home access point
Full Description Line - hAP lite TC // RB941-2nD-TC|Type Wireless Access Point|IEEE 802.11b|IEEE 802.11g|IEEE 802.11n|4x10/100M|Dimensions 124x100x54mm
Gross weight - 0.265 kg
guarantee - 12
guarantee_type - normal
height - 0.074 m
I/O ports - 1 x micro USB
I/O ports - 4 x 10/100 Mbit/s
IEEE 802.11b Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
length - 0.2 m
Link - https://routerboard.com/RB941-2nD-TC
Logistics data - Harmonized System (HS) code - 85176990
Management, monitoring, configuration -
Manufacturer - MikroTik
Model name - hAP lite TC // RB941-2nD-TC
mpn - RB941-2nD-TC
MPN - RB941-2ND-TC
name - Access point N300 2.4GHz 4FE RB941-2nD-TC
Name - MikroTik RB941-2ND-TC
Name - MikroTik | Access Point | RB941-2nD-TC hAP Lite | 802.11n | 2.4GHz | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 4 | MU-MiMO Yes | no PoE
Network architecture - FastEthernet
Network Device Type - Wireless Access Point
Networking > Wi-Fi - Yes
Networking > Wi-Fi standards - 802.11b/g/n
Operating frequency - 2,4 GHz
Operational conditions - Operating temperature (T-T) - -20 - 70 °C
Other features - Procesor: QCA9533 Liczba rdzeni procesora: 1 Częstotliwość nominalna procesora: 650 MHz System operacyjny: RouterOS Rozmiar pamięci RAM: 32 MB Rozmiar przechowywania: 16 MB MTBF: Około 100 000 godzin w 25C
Other features > I/O ports - 4 x 10/100 Ethernet ports; Power Jack
Other features > Power consumption (economy mode) - 3 W
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 185 mm
Package features > Gross depth master carton - 660 mm
Package features > Gross height (mm) - 130 mm
Package features > Gross height master carton - 205 mm
Package features > Gross width (mm) - 60 mm
Package features > Gross width master carton - 255 mm
Package features > Net weight master carton - 5.3 kg
Package features > Packing quantity - 20 pc(s)
Package features > Palette Qty - 1000 pc(s)
Package features > Paper/Pasteboard - 114 g
Package features > Plastic (No PET) - 13 g
Package features > Tare weight (kg) - 0.127 kg
Package features > Tare weight master carton - 0.587 kg
Package features > Volume (m3) - 0.001443 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
PDF - http://www.blobs.lt/products/9/9/5/6/6/1/a5ab64d8f653f96dce6002193512cc90/original.pdf
Performance - Built-in processor - Yes
Performance - Minimum system requirements - 32 MB RAM
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Performance > Flash memory - 16 MB
Performance > Frequency band - 2.4GHz
Performance > Internal memory - 32 MB
Performance > Processor cores - 1
Performance > Web-based management - Yes
Ports & interfaces - DC-in jack - No
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB connector type - Micro-USB
Ports & interfaces > Ethernet LAN (RJ-45) ports - 4
Ports & interfaces > POE - no PoE
Ports & interfaces > USB port - 0
Power - Power over Ethernet (PoE) - No
Power > Power consumption (PowerSave) - 3 W
Power > Power consumption (standby) - 3 W
Power > Power consumption (typical) - 3 W
Power > Voltage - 5 V
Power over Ethernet (PoE) > Power over Ethernet (PoE) - No
Power supply - Maksymalne zużycie energii: 3,5 W
Processor special features > CPU configuration (max) - 650 MHz
producer - Mikrotik
producerCode - RB941-2nD-TC
Producer product family - Access Point
Producer product name - RB941-2nD-TC hAP Lite
productName - MikroTik | RB941-2nD-TC hAP Lite | Access Point | 802.11n | 2.4GHz | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 4 | MU-MiMO Yes | no PoE
productSize - Normal
Security -
Shipping Box Depth Shipping/Package Box Dimensions - 66 cm
Shipping Box Height Shipping/Package Box Dimensions - 21 cm
Shipping box quantity - 20
Shipping Box Weight Shipping/Package Box Dimensions - 5.72 kg
Shipping Box Width Shipping/Package Box Dimensions - 25 cm
sizeX - 190
sizeY - 130
sizeZ - 60
Software -
Special functions -
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
System Requirements -
Technical details > Net weight - 0.138 kg
Technical details > Producer - MikroTik
Technical details > Warranty - 12 month(s)
Technical details > Wireless connection - 802.11b/g/n
title - MikroTik hAP lite
Unit Box Height - 0.061
Unit Box Length - 0.185
Unit Box Width - 0.13
Unit Brutto Volume - 0.001733 cubm
Unit Gross Weight - 0.286 kg
Unit Net Weight - 0.2 kg
USB 2.0 Ports - 1
Vendor Homepage - mikrotik.com/product/RB941-2nD-TC
vendpn - RB941-2nD-TC
Warranty - 12
Warranty - 12 months
warrantyLength - 12
warrantyType - G
Weight - 0.28
weight - 0.31 kg
weight - 289
Weight & dimensions - Weight - 162 g
width - 0.13 m
Wireless LAN features > Wi-Fi band - 802.11n
