ID: 306982
Product code: ACFAN00135A
Can be ordered 26 units Availability: 14 days after order approval
Warranty: 3 years
Arctic P12, Black, 5 Pack
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
Delivery options
- Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
- Courier delivery 11.99 €: 10.12.2024
Main product parameters All parameters
- Producer: Arctic
- LED izgaismojuma krāsa: Nav
- Output Interface: 3-pin (DC)
- Revolutions (MIN), rpm: Nav norādīts
- RPM (MAX), rpm: 1800
- Size, mm: 120
- Sound level (MAX), dB(A): 23.5
- Units in package: 5
All parameters
Producer
: Arctic
Type of lighting
: Bez apgaismojuma
Basic information
LED izgaismojuma krāsa
: Nav
Output Interface
: 3-pin (DC)
RPM (MAX), rpm
: 1800
Size, mm
: 120
Sound level (MAX), dB(A)
: 23.5
Units in package
: 5
More detailed specification
Brand - ARCTIC
BrandPartCode - ACFAN00135A
category - Aircooling|Fans|PWM Fans
Category - Computer Cooling Systems
Category_1 - Computer Cases and Cooling
Category_2 - Fans
code - ACFAN00135A
Design - Fan connector - 3-pin
Design - Number of fan blades - 5
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
dimensionalWeight - 422
ean - 4895213701617
EAN_code - 4895213701617
GTIN - 0872767009554
GTIN - 872767009554
GTIN - 4895213701617
Logistics data - Harmonized System (HS) code - 84733080
LongDesc - The P12 fan features completely redesigned fan blades and is optimised for high static pressure. Thus, the P12 is especially effective when used on heatsinks and with higher air resistance.
LongProductName - 120 mm, 1800 RPM, 56.3 CFM, 95.65 m3/h, 12 V DC, 3-pin, 139 g, 5 pcs
LongSummaryDescription - ARCTIC P12 - Pressure-optimised 120 mm Fan. Type: Fan, Fan diameter: 12 cm, Rotational speed (max): 1800 RPM, Noise level: 0.3 sone, Maximum airflow: 56.3 cfm, Airflow: 95.65 m³/h, Bearing type: Fluid Dynamic Bearing (FDB). Voltage: 12 V. Width: 120 mm, Depth: 120 mm, Height: 25 mm. Product colour: Black
Manufacturer - Arctic
Manufacturer_code - ACFAN00135A
Name - Arctic P12 120x120x25, case fan (black, pack of 5)
name - Arctic P12 Lüfter - 120mm, 5er Pack
Other features - Country of origin - China
Packaging content - Number of screws - 20
Packaging content - Package type - Box
Packaging content - Screws included - Yes
Performance - Airflow - 95.65 m³/h
Performance - Bearing type - Fluid Dynamic Bearing (FDB)
Performance - Compatible processor series - Not supported
Performance - Fan diameter - 12 cm
Performance - Maximum airflow - 56.3 cfm
Performance - Noise level - 0.3 sone
Performance - Rotational speed (max) - 1800 RPM
Performance - Suitable location - Computer case
Performance - Supported processor sockets - Not supported
Performance - Type - Fan
Power - Rated current - 0.2 A
Power - Starting voltage - 2.8 V
Power - Voltage - 12 V
producerCode - ACFAN00135A
productName - ARCTIC P12 - Pressure-optimised 120 mm Fan
ProductName - P12 - Pressure-optimised 120 mm Fan
productSize - Normal
ShortSummaryDescription - ARCTIC P12 - Pressure-optimised 120 mm Fan, Fan, 12 cm, 1800 RPM, 0.3 sone, 56.3 cfm, 95.65 m³/h
sizeX - 130
sizeY - 130
sizeZ - 125
Technical_details - When developing the Arctic P12 120x120x25, particular emphasis was placed on focused airflow and high static pressure. The fan therefore offers extremely efficient cooling, even with increased air resistance. The P12 is therefore particularly suitable for use on heat sinks, radiators as well as pinhole panels and filters. Item no.: 1856973 Fan type Color: Black EAN 4895213701617 Manufacturer no. ACFAN00135A Type of case fan Quantity 5 pieces Use for PC cases Fastening screwed Volume 0.3 sone Speed 1,800 rpm Fan bearing FDB - Fluid Dynamic Bearing Flow rate 95.7 m3/h (563 cfm) Air pressure up to 2.2 mm/H2O 3-pin power connection Voltage range 2.8 - 12 volts Cable length 40 cm Dimensions Fan1 quantity: 5 pieces, width: 120 mm, height: 120 mm, depth: 25 mm
Title - ARCTIC P12 - Pressure-optimised 120 mm Fan
URL - https://www.arctic.ac/eu_en/p12.html
WarrantyInfo - 6 yars
warrantyLength - 72
warrantyType - G
Weight - 0,80
weight - 768
Weight & dimensions - Cable length - 0.4 m
Weight & dimensions - Depth - 120 mm
Weight & dimensions - Height - 25 mm
Weight & dimensions - Package depth - 127 mm
Weight & dimensions - Package height - 123 mm
Weight & dimensions - Package weight - 800 g
Weight & dimensions - Package width - 130 mm
Weight & dimensions - Weight - 139 g
Weight & dimensions - Width - 120 mm
