ARTIKEL1 - MX-2402 24IN CLINICAL REVIEW
ARTIKEL2 - DISPLAY FHD 1920X1080 300CD/QM 2
Brand - AG Neovo
BrandPartCode - MX24B0A1E0100
Breite - 0
Category - Computer Monitors
Design - Market positioning - Medical
Design - Product colour - White
Display - Colour gamut standard - NTSC
Display - Contrast ratio (dynamic) - 20000000:1
Display - Contrast ratio (typical) - 1000:1
Display - Digital horizontal frequency - 24 - 83 kHz
Display - Digital vertical frequency - 50 - 75 Hz
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 60.5 cm (23.8")
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LCD
Display - HD type - Full HD
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 72%
Display - Panel type - VA
Display - Pixel pitch - 0.274 x 0.274 mm
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Supported graphics resolutions - 1920 x 1080 (HD 1080)
Display - Surface hardness - 9H
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 4710739594775
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Height adjustment - No
Ergonomics - Panel mounting interface - 75 x 75,100 x 100 mm
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - 3 - 21°
Ergonomics - VESA mounting - Yes
Gewicht - 0
GRUPPE1 - Medical Equipment
GRUPPE2 - Medical Display
GTIN - 4710739594775
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0
HSTNUMMER - MX2420A1E0100
Laenge - 0
Logistics data - Harmonized System (HS) code - 85285210
LongDesc - The MX-24 is a 24-inch DICOM monitor featuring Full HD 1080p resolution, low-voltage medical power supply with IEC / EN 60601-1 certified. Compatible with DICOM Part 14 standard, it ensures accurate and excellent medical image quality, colour reproduction, and image contrast. Equipped with NeoV™ Optical Hard Glass, the MX-24 withstands alcohol and other commonly used cleaning solutions, allowing medical professionals to sanitize it easily.EASY CLEAN AND ROBUST PROTECTIONThe special design of NeoV Optical Hard Glass and white metal casing prevent dust and waterproof for easy clean and robust protection.DICOM PART 14 CALIBRATIONDICOM Part 14 calibration corrects gamma and luminance to achieve the smooth grayscale for the accurate and consistent appearance of clinical data and other medical images.MEDICAL-GRADE POWER SUPPLY WITH EN/IEC60601-1 CERTIFIEDLow-voltage medical power supply with IEC / EN 60601-1 certified to ensure safety, performance, and reliable operation in any professional medical environment.PIP/PBP SUPPORTThis 24-Inch DICOM monitor enhances work efficiency with PiP/PbP support for multitasking.
LongProductName - 23.8" VA, FHD 1920 x 1080, 5 ms, 250 cd/m², 20000000:1 (DCR), 16.7M, VGA, DVI-D, HDMI, DP 1.2
LongSummaryDescription - AG Neovo MX-24. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: White
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 4 W
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - RoHS, Low Voltage Directive (LVD), UKCA, WEEE, CE, REACH
Packaging content - Cables included - AC, Audio (3.5mm), VGA
Packaging content - Power adapter included - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 249 mm
Packaging data - Package height - 517 mm
Packaging data - Package weight - 10.9 kg
Packaging data - Package width - 672 mm
Performance - AMD FreeSync - No
Performance - NVIDIA G-SYNC - No
Ports & interfaces - Audio input - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DVI-D ports quantity - 1
Ports & interfaces - DVI port - Yes
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - Energy consumption (SDR) per 1000 hours - 18 kWh
Power - Energy efficiency class (SDR) - E
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 670707
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 18 W
Power - Power supply type - External
ProductName - MX-24
ShortSummaryDescription - AG Neovo MX-24, 60.5 cm (23.8"), 1920 x 1080 pixels, Full HD, LCD, 5 ms, White
Stck_Kart - 0
Stck_Pal - 0
Storno - N
Title - AG Neovo MX-24 computer monitor 60.5 cm (23.8") 1920 x 1080 pixels Full HD LCD White
URL - https://nl.agneovo.com/nl/content/mx-series_w.asp
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 56.2 mm
Weight & dimensions - Depth (with stand) - 196 mm
Weight & dimensions - Height (without stand) - 352.6 mm
Weight & dimensions - Height (with stand) - 392.8 mm
Weight & dimensions - Weight (without stand) - 7 kg
Weight & dimensions - Weight (with stand) - 7.8 kg
Weight & dimensions - Width (without stand) - 562.4 mm
Weight & dimensions - Width (with stand) - 562.4 mm
