Logic Atos ARGB Mini, Tempered Glass, White

Category - Root/Electronics/PC parts/Computer casings
Chassis type - Mini Tower
Color - White
Cooling - Front fans diameters supported - 120
Cooling - Front fans diameters supported - 140 mm
Cooling - Front fans installed - 2x 120 mm
Cooling - Number of front fans supported (max) - 2
Cooling - Number of rear fans supported (max) - 1
Cooling - Rear fans diameters supported - 120 mm
Cooling - Rear fans installed - 1x 120 mm
Description - READY FOR GAMES Logic Atos is a chassis created to build an efficient and modern gaming PC. Optimal airflow, practical solutions and pre-installed ARGB fans make up its gaming character. INDUSTRIAL STYLE The front panel designed in a confusingly similar industrial style not only fits well with a gaming PC, but also provides great airflow. TEMPERED GLASS As befits a gaming PC case, Logic Atos features tempered glass on the side Cases. It was intentionally limited to the side panel only, in favor of an airy front panel. 160 mm CPU COOLING Space for mounting an air cooler for a CPU with a maximum height of 160 mm is the optimal amount of space for high-performance cooling systems, especially for such a compact case. In addition, the ability to mount graphics cards up to 290 mm allows the installation of most high-performance components available on the market. OPTIMUM AIR SUPPLY The ventilated front panel provides airflow with two, efficiently operating 120mm fans. This allows you to effectively cool the installed components of the computer's interior, positively influencing the culture of their operation and service life. As an option, it is possible to mount two 140 millimeter fans on the front of Cases on your own, in place of the factory-installed ones. ARGB BEAUTY Case for gamers must look nice. That's why the pre-installed ARGB fans add beauty to the case and the gaming stand. The backlight color can be changed at will from the predefined settings using the RESET button on the control panel Cases. HOME & OFFICE Despite its gaming pedigree, Case will also perform well in office tasks and everyday work. The ability to build a versatile and powerful computer is undoubtedly its advantage. OPTIMAL AND PRACTICAL SOLUTIONS The mounting of HDD or SSD drives is obviously thought out here as well. Inside Cases at tunnel level there is a basket for 2 x 3.5" or 2.5" drives. On the motherboard tray, on the other hand, there is the possibility of mounting an additional 1 x 2.5'' drive (installation before mounting the motherboard). SIMPLE INSTALLATION Everything here is well thought out and intuitive. Building a computer in this case is a pleasure and is child's play. CONVENIENT ACCESS TO THE TOP PANEL Convenient access to the top panel, and there are two USB 2.0 and one USB 3.0 connectors, plus HD audio jacks for headphones and a microphone, a power button and a reset button (which allows control of ARGB backlighting). POWER SUPPLY IN THE TUNNEL The small holes under the PSU's mounting location serve a filtering function by restricting dust and dirt from entering Cases. At the same time, they provide air flow to the power supply 4 PCIe expansion card slots Four slots for PCIe expansion cards. This is the optimal number for mounting, for example, a graphics card and a network card. IDEAL FOR ANY ROOM Supporting mini-ITX and Micro-ATX motherboards, it is a compact solution for building a computer for study, work and play. It takes up less space in the room than other standard Cases ATX motherboards, yet is highly functional.
Design - Cable management - Yes
Design - Form factor - Mini Tower
Design - Illumination - ARGB
Design - Maximum CPU cooler height - 16 cm
Design - Maximum graphics card length - 29 cm
Design - Number of 2.5" bays - 3
Design - Number of 3.5" bays - 2
Design - Number of expansion slots - 4
Design - On/off button - Yes
Design - Product colour - White
Design - Side window - Yes
Design - Supported motherboard form factors - micro ATX
Design - Supported motherboard form factors - Mini-ITX
Design - Tempered glass panel(s) - Yes
Design - Type - PC
dimensionalWeight - 8944
dimension depth - 397 mm
dimension height - 430 mm
Dimensions - Dimensions without front panel: 300 x 200 x 375 mm Housing with panel and legs: 340 x 200 x 385 mm
dimension weight - 371 g
dimension width - 250 mm
Drive bays 2.5'' extern. - 0
Drive bays 2.5'' intern. - 1
Drive bays 3.5'' extern. - 0
Drive bays 3.5'' intern. - 2
Drive bays 5.25'' extern. - 0
Drive bays 5.25'' intern. - 0
ean - 5903560981060
Eans - 5903560981060
Fan - 12 cm
Form-factor - Micro ATX
Front panel connectors - 1 x headphones
Front panel connectors - 1 x USB 3.0
Front panel connectors - 1x microphone
Front panel connectors - 2 x USB 2.0
guarantee - 24
guarantee_type - statutory
name - Computer case ATOS ARGB MINI 3.0 White
Name - Logic Atos ARGB White
No. of drive bays - 3
Other features - PCI expansion cards: x 4 ATX power supply installation: at the bottom Maximum motherboard size: micro-ATX Possibility to install graphics cards: up to 290 mm Maximum CPU cooling height: 160 mm Fan installation locations: Front 2 x 120 mm or 2 x 140 mm. Rear 1 x 120 mm. Installed illuminated fans: 2 x 120 mm on the ARGB front panel 1 x 120 mm on ARGB rear panel
Ports & interfaces - Audio input - Yes
Ports & interfaces - Audio output - Yes
Ports & interfaces - Reset button - Yes
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) ports quantity - 1
Power supply - Power supply included - No
Producer - Logic
producer - Logic Concept
producerCode - AM-ATOS-20-0000000-0002
ProducerCode - AM-ATOS-20-0000000-0002
productName - LOGIC ATOS ARGB Mini USB 3.0 Enclosure White
productSize - Normal
ShortDescription - Micro Tower | biała | bez zasilacza | 1 x USB 3.0 i 2 x USB 2.0 | 340mm x 200mm x 385 mm |
Side panel - Tempered Glass
sizeX - 260
sizeY - 430
sizeZ - 400
Storage - Supported HDD sizes - 2.5
Storage - Supported HDD sizes - 3.5"
vendpn - AM-ATOS-20-0000000-0002
warrantyLength - 24
warrantyType - G
weight - 4555
Weight & dimensions - Depth - 340 mm
Weight & dimensions - Height - 385 mm
Weight & dimensions - Width - 200 mm
