Brand - ASUS
BrandPartCode - 90YV0KF4-M0NA00
Category - Graphics Cards
category - PC Components|Graphics Cards|NVIDIA
Category 1 - Grafikkarten
Category 2 - NVidia PCI-Express Grafikkarten
code - 90YV0KF4-M0NA00
Design - Cooling technology - ASUS Axial-tech
Design - Cooling type - Active
Design - Number of fans - 2 fan(s)
Design - Number of slots - 2.56
Design - Product colour - Black
ean - 4711387545249
EAN - 4711387545249
GTIN - 4711387545249
LongDesc - 2x Fans. 2x Fun.ASUS Dual GeForce RTX™ 4070 Ti SUPER fuses dynamic thermal performance with broad compatibility. Advanced cooling solutions from flagship graphics cards — including two Axial-tech fans for maximizing airflow to the heatsink — are packed into the 26.7 cm long, 2.56-slot card, delivering more power in less space. These enhancements make ASUS Dual the perfect choice for gamers who want heavyweight graphics performance in a compact build.Axial-tech Fan DesignBetter, faster, strongerTwo tried-and-true Axial-tech fans feature a smaller hub that facilitates longer blades and a barrier ring to increase downward air pressure.0dB TechnologyQuiet intelligenceTo eliminate unnecessary noise, a stop mode halts all fans when the GPU temp falls below 50 degrees and power consumption is low.Dual Ball Fan Bearings2x longer lifespanDifferent bearing types have unique pros and cons. Ball bearings excel at durability and can last up to twice as long as sleeve bearing designs.2.56-slot DesignSink your heat into thisA carefully designed shroud, heatsink, and heatpipe layout allows the two Axial-tech fans to leverage chassis side-panel ventilation and deliver thermal performance that belies the card’s size.Dual BIOSChoose wiselyDo you prioritize low core temps or low noise levels? Performance mode will let the fans spin up to keep the card running cool all the time. Quiet mode keeps the same power target and top-end settings, but offers a less aggressive fan curve for quieter operation at medium temps. For even more customization and control, check out our GPU Tweak III software.Auto-Extreme TechnologyPrecision automated manufacturingAuto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.Protective BackplateThat's so metal!The PCB is reinforced by an aluminum backplate that adds structural rigidity, helping to prevent flex and protect components and trace pathways from damage. The rear features a wide vent that allows hot air to escape towards chassis exhaust fans instead of being recycled back into the GPU cooler.Stainless Steel BracketSteel yourselfThe mounting bracket of the Dual has been beefed up with 304 Stainless Steel that’s harder and more resistant to corrosion.GPU TWEAK IIIMonitor, tweak, and tuneThe ASUS GPU Tweak III utility takes graphics card tuning to the next level. It allows you to tweak critical parameters including GPU core clocks, memory frequency, and voltage settings, with the option to monitor everything in real-time through a customizable on-screen display. Advanced fan control is also included along with many more features to help you get the most out of your graphics card.QuantumCloudProfit from GPU powerQuantumCloud is a safe and easy-to-use application that lets you effortlessly earn extra money by sharing your graphics card’s computing power. Earnings are accessible through your PayPal or WeChat account, and QuantumCloud also supports multiple exchange methods, including Steam. In addition, QuantumCloud doesn’t collect any personal data, so your privacy stays protected. Get started right away with just one click!144-hour Validation Program“Extensive” may be an understatementA 144-hour validation program puts cards through a series of stringent tests to ensure compatibility with the latest games.NVIDIA DLSS 3Max FPS. Max Quality. Powered by AI.DLSS is a revolutionary breakthrough in AI graphics that multiplies performance. Powered by the new fourth-gen Tensor Cores and Optical Flow Accelerator on GeForce RTX 40 Series GPUs, DLSS 3 uses AI to create additional frames and improve image quality.Further With AI, Faster on RTXGet next-level AI performance on GeForce RTX.Discover the RTX AI advantage. Built for the era of AI, GeForce RTX™ GPUs feature specialized AI Tensor Cores that deliver cutting-edge performance and revolutionary capabilities. From enhanced creativity and ultra-efficient productivity to blisteringly fast gaming, the ultimate in AI power on Windows PCs is on RTX.
LongProductName - 16 GB, GDDR6X, 256-bit, PCI Express 4.0, 2610 MHz boost clock, 2640 MHz OC mode, HDMI, 3x DisplayPort, 2.56-slot, 1x 16-pin
LongSummaryDescription - ASUS Dual -RTX4070TIS-16G. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 4070 Ti SUPER. Discrete graphics card memory: 16 GB, Graphics card memory type: GDDR6X, Memory bus: 256 bit. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 2 fan(s)
Manufacturer - ASUS
Memory - Data transfer rate - 21 Gbit/s
Memory - Discrete graphics card memory - 16 GB
Memory - Graphics card memory type - GDDR6X
Memory - Memory bus - 256 bit
MPN - 90YV0KF4-M0NA00
name - ASUS Dual GeForce RTX 4070 Ti SUPER, DUAL-RTX4070TIS-16G, 16GB GDDR6X, HDMI, 3x DP
Name - RTX 4070 Ti Super 16GB ASUS Dual GDDR6X
Packaging content - Manual - Yes
Packaging data - Package depth - 233 mm
Packaging data - Package height - 88.5 mm
Packaging data - Package type - Box
Packaging data - Package weight - 1.75 kg
Packaging data - Package width - 405 mm
Performance - DirectX version - 12 Ultimate
Performance - Dual Link DVI - No
Performance - HDCP - Yes
Performance - HDCP version - 2.3
Performance - NVIDIA G-SYNC - Yes
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 3
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1a
Ports & interfaces - Interface type - PCI Express 4.0
Power - Minimum system power supply - 750 W
Power - Supplementary power connectors - 1x 16-pin
Processor - CUDA - Yes
Processor - CUDA cores - 8448
Processor - Graphics processor - GeForce RTX 4070 Ti SUPER
Processor - Graphics processor family - NVIDIA
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Processor boost clock speed - 2610 MHz
Processor - Processor frequency (OC mode) - 2640 MHz
ProductName - DUAL-RTX4070TIS-16G
ShortSummaryDescription - ASUS Dual -RTX4070TIS-16G, GeForce RTX 4070 Ti SUPER, 16 GB, GDDR6X, 256 bit, 7680 x 4320 pixels, PCI Express 4.0
System requirements - Windows operating systems supported - Windows 10 x64, Windows 11 x64
Title - ASUS Dual -RTX4070TIS-16G NVIDIA GeForce RTX 4070 Ti SUPER 16 GB GDDR6X
URL - https://www.asus.com/motherboards-components/graphics-cards/dual/dual-rtx4070tis-16g/
WarrantyInfo -
Weight - 1.77
Weight & dimensions - Depth - 51.1 mm
Weight & dimensions - Height - 133.9 mm
Weight & dimensions - Length - 267 mm
Weight & dimensions - Weight - 945 g
The GeForce emblem indicates that this graphics card is powerful enough to be compatible with the latest VR (Virtual Reality) devices such as Oculus Rift, HTC Vive (SteamVR), etc.
