10/100/1000/2500 Mbps ports - 5
Accessories included -
Application - Home and small office
ARTIKEL1 - 5-PORT 2.5G UNMANAGED SWITCH
ARTIKEL2 - MULTI-GIG
Brand - NETGEAR
BrandPartCode - MS105-100EUS
Breite - 0
Category - Network Switches
Certificates - Electromagnetic certifications and compliance: CE, FCC part 15 Class B, ISED, VCCI, KC, CCC, BSMI, RCM Safety certificates: CB, CSA, CCC, BSMI, RCM, CE LVD
Chassis type - Desktop
Console port - No
Data transmission - MAC address table - 16000 entries
Data transmission - Packet forwarding rate (1 Gbps) - 1488000 pps
Data transmission - Switching capacity - 25 Gbit/s
Description - MS105 NETGEAR 5-Port Multi-Gigabit Ethernet 2.5G Unmanaged Switch The NETGEAR MS305 5-Port Unmanaged Multi-Gigabit Switch helps businesses cost-effectively expand their networks at multi-gigabit speeds. The MS305 Multi-Gigabit Ethernet Switch features five 2.5G ports in a metal housing and can be placed on a desk or mounted on a wall with the included wall mount kit. This switch is energy efficient, built to last, and thoroughly tested for the reliability businesses need. 801.2p traffic prioritization and jumbo frame support allow seamless integration into more complex networks. Reliable performance Superior non-blocking network performance delivers true Multi-Gig speed without compromise Energy saving Energy Efficient Ethernet standard (IEEE 802.3az) that reduces power consumption when there is light traffic on an active port or when no link or activity is detected Plug-and-Play No software to install. Configuration is not needed. No maintenance required Quiet operation Fanless design means no noise, making it ideal for noise-sensitive environments Versatile mounting options Install the switch on a desktop or mount it on a wall using the mounting hardware provided in the package
Design - Form factor - 1U
Design - Rack mounting - Yes
Design - Stackable - Yes
Designation - CE+WEEE
dimension depth - 90 mm
dimension height - 165 mm
Dimensions - 158 x 101 x 29 mm
dimension weight - 839 g
dimension width - 210 mm
ean - 606449160093
EAN - 606449160093
EANCode - 0606449160093
Environment requirements - Operating temperature: 0° to 40°C Operating humidity (RH): 90% maximum relative humidity (RH), non-condensing Working altitude: maximum 3000 m Storage temperature: -20° to 70°C Storage humidity (RH): 95% of maximum relative humidity (RH), non-condensing Storage altitude: 3000 m
Fan - No
Gewicht - 0.85
Gross Weight Kg - 0,51
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 0606449160093
GTIN - 606449160093
GTIN - 10606449160090
guarantee - 0
guarantee_type - perpetual
HERSTELLER - NETGEAR
Hoehe - 0
HSTNUMMER - MS105-100EUS
Jumbo frame size - 9.72 KB
L2 features -
L3 features -
Laenge - 0
LongDesc - The NETGEAR 5-port Multi-Gigabit Unmanaged Switch, MS305, helps businesses cost-effectively expand their networks with multi-gig speeds. The MS305 Multi-Gigabit Ethernet switch comes with five (5) 2.5G ports in a metal case and can be placed on a desk or mounted on a wall with the included wall mount kit. This switch is energy efficient, built to last, and rigorously tested to provide the reliability businesses need. 802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks.RELIABLE PERFORMANCESuperior network performance at non-blocking rate delivers true Multi-Gig speed with no compromiseENERGY EFFICIENTEnergy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detectedPLUG-AND-PLAYNo software to install. No configuration needed. Zero maintenance requiredSILENT OPERATIONThe fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environmentsVERSATILE MOUNTING OPTIONSInstall your switch on your desktop, or mount it to your wall with the hardware provided in the box.
LongProductName - 2.5G, PoE++, 1mb, 16k
LongSummaryDescription - NETGEAR MS105-100EUS. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 16000 entries, Switching capacity: 25 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3x. DC input voltage: 12 V. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
MAC address table size - 16000
Management, monitoring, configuration -
Management features - Switch type - Unmanaged
Manufacturer Code - MS105-100EUS
Manufacturer Name - Netgear
Mean time between failures (MTBF) - 1401743 h
name - Switch MS105 5x 2.5GE
Network - 10G support - No
Network - Networking standards - IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3x
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - None
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - None
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features -
Other functions -
Packet buffer - 1 MB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 2.5G Ethernet (100/1000/2500)
Power - DC input voltage - 12 V
Power - Power consumption (typical) - 9.24 W
Power - Power source - DC
Power - Power supply included - Yes
Power consumption - 9.24 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power supply - 12V/1.0A
Power supply - External
producer - Netgear
ProductName - MS105-100EUS
QoS - 802.1p-based QoS/CoS Supported Honors DSCP (DiffServ) Tags
Security -
Short description - Netgear 5Port Switch 10/100/1000 MS105 Fanless, Wandmontage
ShortSummaryDescription - NETGEAR MS105-100EUS, Unmanaged, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting, 1U
Stackability - No
Stck_Kart - 6
Stck_Pal - 12
Storno - Y
Supported protocols and standards - IEEE 802.3 Ethernet IEEE 802.3bz 2.5GBASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.1p Priority IEEE 802.3az Energy Efficient Ethernet (deactivated by default) IEEE 802.3 CSMA/CD IEEE 802.3x Full-duplex Flow Control
Support for Jumbo frames - Yes
Switch class - Unmanaged
Throughput - 25 Gb/s
Title - NETGEAR MS105-100EUS network switch Unmanaged 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U
URL - https://www.netgear.com/business/wired/switches/unmanaged/ms105/
vendpn - MS105-100EUS
VLAN -
WarrantyInfo -
Weight - 0.48 kg
Weight & dimensions - Depth - 101 mm
Weight & dimensions - Height - 29 mm
Weight & dimensions - Weight - 480 g
Weight & dimensions - Width - 158 mm
