10/100/1000/2500 Mbps ports - None
Accessories included -
Application - Medium and large companies
ARTIKEL1 - 52-PORT LAYER2 GIGABIT SWITCH
ARTIKEL2 - 48X POE SMART MANAGED
Brand - D-Link
BrandPartCode - DGS-1210-52MP/E
Breite - 0.56
Category - Network Switches
Certificates - EMI: CE Class A, VCCI Class A, FCC Class A, BSMI, CCC Safety: CB, UL, BSMI, CCC
Certificates - Compliance certificates - BSMI, CB, CCC, cUL
Chassis type - Rack
Console port - No
Data transmission - Forwarding rate - 77.4 Mpps
Data transmission - Jumbo frames - 10000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 16000 entries
Data transmission - Number of static routes - 256
Data transmission - Packet buffer memory - 12 MB
Data transmission - Static route - Yes
Data transmission - Switching capacity - 104 Gbit/s
Description - DGS-1210 Series Gigabit Managed Smart+ Switches L2 management and security with L3 capabilities CLI and web interface Static and MSTP routes PoE option with up to 370W power budget Dual images and configurations Lifetime-Limited warranty upon registration Command line CLI via Telnet Support for a compact command line interface for system configuration and management. Static routing Segregation of L3 traffic between switches, regardless of VLAN segemntation. Fibre optic uplink ports Ideal for connecting distributed devices while maintaining gigabit throughput. Dual software images and configuration files Perform firmware updates and configuration testing without any risk. Surveillance Mode Interface D-Link's easy-to-use Surveillance Mode interface provides instant recognition of the topology of installed cameras. Limited Lifetime Warranty Register your product to benefit from the Lifetime Limited Warranty. A large PoE power budget and extensive Layer 2 features make the DGS-1210+ family switches a flexible and cost-effective solution for expanding any business network. Advanced L2 management with L3 static routing The advanced network management options of the DGS-1210 Smart+ family switches are available via the CLI console or a browser-based graphical user interface. This gives your business the ability to use VLANs, multiple spanning tree protocol (MSTP), link aggregation (LACP), static routes, dual software images and dual configuration files. With powerful security features in the form of IGMP snooping, access control lists, port security tools and the D-Link Safeguard Engine, which protects the network from malicious denial-of-service attacks from broadcast, multicast and unicast flooding, the DGS-1210 Smart+ switch family is a versatile tool for network edge and access environments. Fibre optic Uplink ports Network expansion to suit the needs of any business is possible with fibre uplink ports with advanced management and security features. PoE The DGS-1210+ switch family includes switches with a large PoE power budget to facilitate the installation of IP phones, wireless access points and IP cameras. D-View 7: free network design and management system D-Link's free Network Assistant (DNA) system provides information about all connected devices and speeds up initial configuration. The free D-View 7 network management system comes with a licence for 25 nodes and 2 probes and full access to management tools. An optional licence upgrade allows for expanded network and analysis capabilities. Energy saving D-Link's DGS-1210+ family of switches with D-Link Green technology enables energy savings without affecting performance or functionality. Surveillance Mode Select Surveillance Mode in the graphical user interface to take advantage of easy-to-use monitoring features that also allow you to easily manage your surveillance network. The devices that make up the security system are automatically detected and grouped in a dedicated Auto Surveillance VLAN, so that surveillance traffic is secured and is transmitted unhindered.
Design - LED indicators - Yes
Design - Product colour - Black, Grey
Designation - CE+WEEE
dimension depth - 150 mm
dimension height - 550 mm
Dimensions - 440 x 430 x 44 mm
dimension weight - 8500 g
dimension width - 560 mm
ean - 790069467806
EANCode - 0790069467806
Environment requirements - Operating temperature: -5 to 50°C Storage temperature: -20 to 70°C Operation humidity: 0% to 95% relative humidity Storage humidity: 0% to 95% relative humidity
Fan - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 77.4 Mpps
Gewicht - 8.44
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 790069467806
GTIN - 0790069467806
GTIN - 5704174940425
guarantee - 0
guarantee_type - perpetual
HERSTELLER - D-LINK
Hoehe - 0.15
HSTNUMMER - DGS-1210-52MP/E
Jumbo frame size - 10 KB
L2 features - MAC Address Table: 16K entries (DGS-1210-52/52MP only) IGMP Snooping IGMP v1/v2 Snooping IGMP v3 awareness Supports 256 IGMP groups Supports at least 64 static multicast addresses IGMP per VLAN Supports IGMP Snooping Querier Loopback Detection 802.3ad Link Aggregation LLDP LLDP-MED Jumbo Frame: Up to 10,000 bytes Spanning Tree Protocol 802.1D STP 802.1W RSTP 802.1s MSTP Flow Control 802.3x Flow Control HOL Blocking Prevention Port Mirroring One-to-One Many-to-One Supports Mirroring for Tx/Rx/Both Multicast Filtering Forwards all unregistered groups Filters all unregistered groups Configurable MDI/MDIX MLD snooping v1/v2 (256 groups)
L3 features -
Laenge - 0.57
LongSummaryDescription - D-Link DGS-1210-52MP. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48, Installed SFP modules quantity: 4. Full duplex. MAC address table: 16000 entries, Switching capacity: 104 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE.... Power over Ethernet (PoE)
MAC address table size - 16000
Management, monitoring, configuration - Web-based GUI D-Link Network Assistant Utility Compact CLI Telnet Server TFTP Client Configurable MDI/MDIX SNMP Supports v1/v2c/v3 SNMP Trap Backup/upgrade firmware Smart Wizard Upload/download configuration file BootP/DHCP Client System Log Max. 500 log entries SNTP ICMP v6 IPv4/v6 Dual Stack DHCP Auto Configuration Time setting SNTP RMONv1 Trusted host Dual image Dual configuration
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Web-based management - Yes
Mean time between failures (MTBF) - 236406 h
Memory buffer - 12 MB
name - Switch DGS-1210-52MP 48GE PoE+ 4SFP
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Broadcast storm control - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Half duplex - Yes
Network - Head-of-line (HOL) blocking - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Number of VLANs - 256
Network - Port mirroring - Yes
Network - Spanning tree protocol - Yes
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 52
Number of 10Gb ports - None
Number of COMBO ports - 4
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - 48
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP ports - 4
Number of VLAN groups - 256
Operational conditions - Heat dissipation - 507.23 BTU/h
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -5 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - PoE ports: 1-24 Maximum PoE budget: 370 W
Other functions -
Performance - Flash memory - 32 MB
Performance - Internal memory - 128 MB
Performance - Mean time between failures (MTBF) - 236406 h
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 48
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Installed SFP modules quantity - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Number of power supply units - 1
Power - Power consumption (max) - 54.4 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption - 454.1 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 48
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 370 W
Power supply - 100 - 240 V AC 50/60 Hz
Power supply - Internal
producer - D-Link
ProductName - DGS-1210-52MP
QoS - 802.1p Quality of Service 8 queues per port Queue Handling Strict Weighted Round Robin (WRR) Bandwidth Control Port-based (ingress/egress, min granularity 10/100/1000 is 16 Kbps) QoS based on: 802.1p priority queues DSCP MAC address EtherType IP address Protocol type ToS IP preference IPv6 Traffic Class TCP/UDP port
Security - Broadcast/Multicast/Unicast Storm Control D-Link Safeguard Engine Traffic segmentation SSH v2 TLS v1.0 DoS attack prevention 802.1X Port-based Access Control Port Security Supports up to 64 MAC addresses per port ARP Spoofing Prevention Max. 127 entries DHCP Server Screening IP-MAC-Port Binding (Smart Binding) ARP Inspection Max. 256 entries IPv4 Inspection Max. 127 entries IPv6 Inspection Max. 63 entries DHCP Snooping Max. 512 entries
Security - IGMP snooping - Yes
Security - Loop protection - Yes
ShortSummaryDescription - D-Link DGS-1210-52MP, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE)
Stackability - No
Stck_Kart - 1
Stck_Pal - 0
Storno - N
Supported protocols and standards - IEEE 802.3 10BASE-T Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper) IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic IEEE 802.3az Energy Efficient Ethernet (EEE) IEEE 802.3x Flow Control IEEE 802.3af/at compliance
Support for Jumbo frames - Yes
Sustainability - Sustainability compliance - Yes
Switch class - SMART
Switch layer - L2
Switch layer - L3
Throughput - 104 Gb/s
Title - D-Link DGS-1210-52MP Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey
vendpn - DGS-1210-52MP/E
VLAN - 802.1Q VLAN Group Max. 256 static VLAN groups Configurable VID from 1 - 4094 Asymmetric VLAN Auto Voice VLAN Max. 10 user-defined OUI Max. 8 default OUI Auto Surveillance VLAN
Weight - 6.26 kg
Weight & dimensions - Depth - 430 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 6.26 kg
Weight & dimensions - Width - 440 mm
