10/100/1000/2500 Mbps ports - None
Accessories included - M4250-26G4F-POE++ (GSM4230UP) Przewody zasilające Kable Console USB typu C i RJ45-DB9 Standardowe wsporniki do montażu w szafie typu Rack Dłuższe wsporniki do montażu wpuszczanego Gumowe podkładki pod stopy do montażu na stole Podręcznik instalacji
Application - Medium and large companies
ARTIKEL1 - AV LINE M4250-26G4F-POE++ 24X1G
ARTIKEL2 - ULTRA90 POE++ 4XSFP 1440W
Brand - NETGEAR
BrandPartCode - GSM4230UP-100EUS
Breite - 0.47
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Certificates -
Chassis type - Rack
Console port - No
Description - Przełącznik zarządzalny 24 x 1 G PoE++ 1,440 w 2x1G i 4 x SFP
Przełączanie zaprojektowane z myślą o technologii AV over IP 1 G z tyłem do kierunku montażu portów, zapewniające czystą integrację ze stelażami AV. Wstępnie skonfigurowany do działania po wyjęciu z pudełka! Przełączniki zarządzane liniowo AV M4250
Seria NETGEAR AV Line M4250 została zaprojektowana przy udziale profesjonalistów AV. Rezultatem jest linia przełączników zbudowanych od podstaw w celu obsługi dźwięku i obrazu 1 Gb przez IP z dostosowanym sprzętem i oprogramowaniem wraz z dedykowanym serwisem i wsparciem.
Design - Form factor - 1U
Design - Product colour - Black
Design - Rack mounting - Yes
Designation - CE+WEEE
dimension depth - 530 mm
dimension height - 470 mm
Dimensions - 440 x 400 x 43.2 mm
dimension weight - 9200 g
dimension width - 125 mm
ean - 606449151701
EAN - 0606449151701
EANCode -
EANCode - 0606449151701
Environment requirements -
Fan - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 44.64 Mpps
Gewicht - 9.49
Gewicht - 9.54
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0606449151701
GTIN - 606449151701
guarantee - 0
guarantee_type - perpetual
HERSTELLER - NETGEAR
Hoehe - 0.13
HSTNUMMER - GSM4230UP-100EUS
Jumbo frame size - 12000 KB
L2 features -
L3 features -
Laenge - 0.54
Logistics data - Harmonized System (HS) code - 85176990
LongDesc -
LongProductName - AV Line 24x1G Ultra90 PoE++ 802.3bt 1,440W 2x1G and 4xSFP Managed Switch
LongSummaryDescription - NETGEAR GSM4230UP. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Networking standards: IEEE 802.3bt. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
MAC address table size - 16000
Management, monitoring, configuration -
Management features - Switch layer - L2/L3
Management features - Switch type - Managed
Manufacturer - NETGEAR
MPN - GSM4230UP-100EUS
Name - AV LINE M4250-26G4F-POE++ 24X1G
name - Switch GSM4230UP 24xGE PoE++ 4xSFP
Network - Networking standards - IEEE 802.3bt
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 30
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE++ ports - 1
Number of PoE+ ports - 24
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - 4
Other features -
Other functions -
Packet buffer - 16 MB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Power connector - AC-in jack
Ports & interfaces - SFP module slots quantity - 4
Power - Power consumption (typical) - 1400 W
Power - Power supply included - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 24
Power supply -
Power supply - Internal
producer - Netgear
ProductName - GSM4230UP
QoS - Wejście/wyjście Kształtowanie 1 Kb/s Na podstawie czasu Kontrola jednolitej stawki
Security -
ShortSummaryDescription - NETGEAR GSM4230UP, Managed, L2/L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
Stck_Kart - 1
Stck_Pal - 0
Stck_Pal - 6
Storno - Y
Supported protocols and standards - Auto-VoIP Policy-based routing (PBR) LLDP-MED IEEE 1588 PTPv2 1-Step End-to-End Transparent Clock AVB*: 802.1AS, 802.1Qav, 802.1Qat MSRP, 802.1ak MMRP, 802.1ak MVRP
Support for Jumbo frames - Yes
Switch class - Managed
Throughput - 60 Gb/s
Title - NETGEAR GSM4230UP Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
URL - https://www.netgear.com/support/product/GSM4230UP.aspx#docs
vendpn - GSM4230UP-100EUS
VLAN - 4K VLANs
WarrantyInfo -
Weight - 6.75 kg
Weight & dimensions - Weight - 6.75 kg
