TP-LINK Omada SG3428XMPP

10Base-T / 100Base-TX / 1000Base-T Ports - 24
Accessories included -
Application - Medium and large companies
ARTIKEL1 - 24-PORT 1G L2+ MANAGED SWITCH
ARTIKEL2 - 4X10G SFP+ + 16XPOE+ + 8XPOE++
Brand - TP-Link
BrandPartCode - SG3428XMPP
Breite - 0
Category - Network Switches
Category Code - SWI
Certificates - CE FCC
Certificates - Certification - CE, FCC, RoHS
Chassis type - Rack
CnCode CnCode - 85176200
Console Ports - 1
Data transmission - Forwarding rate - 95.23 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 16000 entries
Data transmission - Packet buffer memory - 12 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 128 Gbit/s
Description - Omada 24-Port Gigabit and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++ - 4× 10 Gbps SFP+ slots - 8× Gigabit 802.af/at/bt PoE++ ports (Max 90 W PoE budget for each port) - 16× Gigabit 802.3af/at PoE+ ports (Max 30 W budget for each port) - 500 W total PoE budget* - Centralized cloud management via the web or the Omada app† - Standalone management via web, CLI, SNMP, and RMON - Static Routing, VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM - ERPS supports rapid protection and recovery in a ring topology - Durable metal casing and rack-mountable design
Description - Przełącznik zarządzalny Omada 24-portowy Gigabit i 4-portowy 10GE SFP+ L2+ z 16-portowym PoE+ i 8-portowym PoE++ 4 gniazda SFP+ 10 Gb/s 8 portów Gigabit 802.af/at/bt PoE++ (maksymalny budżet PoE 90 W dla każdego portu) 16 portów Gigabit 802.3af/at PoE+ (maksymalny budżet PoE 30 W dla każdego portu) 500 W całkowitego budżetu PoE Centralne zarządzanie w chmurze za pośrednictwem sieci lub aplikacji Omada Samodzielne zarządzanie za pośrednictwem sieci, CLI, SNMP i RMON Statyczne trasowanie, VLAN, ACL, QoS, IGMP Snooping, OAM i DDM ERPS obsługuje szybką ochronę i odzyskiwanie w topologii pierścieniowej Wytrzymała metalowa obudowa i konstrukcja umożliwiająca montaż w szafie
Design - Form factor - 1U
Design - LED indicators - Yes
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Reset button - Yes
dimension depth - 90 mm
dimension height - 540 mm
Dimensions - 440 x 330 x 44 mm
Dimensions - 440×330×44 mm
dimension weight - 5000 g
dimension width - 470 mm
ean - 8885020620856
EAN - 8885020620856
EANCode - 8885020620856
Environment requirements -
Fan - No
Forwarding rate - 95.23 Mpps
Forwarding rate - 95.23 Mpps
Full Description Line - Series Omada|Rack|24x10Base-T / 100Base-TX / 1000Base-T|4xSFP+|1xConsole|1xMicro-USB|PoE+ ports 16|PoE power budget 500 Watts|Switching capacity 128 Gbps|Forwarding rate 95.23 Mpps|Dimensions 440×330×44 mm|Unit Net Weight 5.6 kg
Gewicht - 6.25
Gross Weight Kg - 6,2
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 8885020620856
GTIN - 8885020620863
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - SG3428XMPP
Jumbo frame size - 9 KB
L2 features - 128 IP Interfaces: Support IPv4/IPv6 Interface Static Routing: 48 IPv4/IPv6 Static Routes Static ARP: 128 static entries 512 ARP Entries Proxy ARP Gratuitous ARP DHCP Server DHCP Relay: DHCP Interface Relay, DHCP VLAN Relay DHCP L2 Relay Link Aggregation Spanning Tree Protocol Loopback Detection 802.3x Flow Control Mirroring Supports 1000 (IPv4, IPv6) IGMP groups IGMP Snooping IGMP Authentication Multicast VLAN Registration (MVR) MLD Snooping Multicast Filtering: 256 profiles and 16 entries per profile
L3 features -
Laenge - 0
LongDesc - Empowering the High-Power Devices with Gigabit PoE++ PortsEasily Build a Whole 10G Multi-gigabit NetworkSoftware Defined Networking (SDN) with Cloud AccessRemotely manage your access points, switches, and gateways across multiple sites all from a single interface.
LongProductName - Omada 24-Port Gigabit and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++
LongSummaryDescription - TP-Link Omada SG3428XMPP. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45/Micro-USB. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
MAC address table size - 16000
Management, monitoring, configuration -
Management features - ARP inspection - Yes
Management features - Cloud-managed - Yes
Management features - Configuring Location Settings (CLI) - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2+
Management features - Switch type - Managed
Management features - System event log - Yes
Management features - Web-based management - Yes
Manufacturer Code - SG3428XMPP
Manufacturer Name - TP-LINK
Memory buffer - 12 MB
Micro-USB Input/Output connectors - 1
Model name - SG3428XMPP
Multicast features - Multicast support - Yes
name - SG3428XMPP Switch 24xGE PoE+ 4xSFP+
Network - 10G support - Yes
Network - Broadcast storm control - Yes
Network - Flow control support - Yes
Network - Head-of-line (HOL) blocking - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.3af, IEEE 802.3at
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Spanning tree protocol - Yes
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100/1000 Mbps ports - 24
Number of PoE+ ports - 16
Number of PoE ports (PoE & PoE+) - 8
Number of SFP+ ports - 4
Operational conditions - Heat dissipation - 1658.78 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Packaging content - Cables included - AC
Packaging content - Quick start guide - Yes
PoE+ ports - 16
PoE power budget - 500 Watts
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Console port - RJ-45/Micro-USB
Ports & interfaces - Power connector - AC-in jack
Ports & interfaces - SFP+ module slots quantity - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 486.2 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption - 486.2 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Power over Ethernet 4PPoE (PoE++) ports quantity - 8
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 16
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 500 W
Power supply - 100-240 V AC~50/60 Hz
Primary port count - 24
producer - TP-LINK
ProductName - SG3428XMPP
QoS - 8 kolejek priorytetowych Priorytet 802.1p CoS/DSCP Harmonogram kolejek: SP (Strict Priority), WRR (Weighted Round Robin), SP+WRR Kontrola przepustowości: Ograniczanie oceny na podstawie portu/przepływu Płynniejsza wydajność Działanie dla przepływów: Uwaga QoS (Uwaga 802.1P, Uwaga DSCP)
Rack Mounting Type - Yes
Security - Powiązanie IP-MAC-Port
- 512 wpisów
- Podsłuchiwanie DHCP
- Inspekcja ARP
- Ochrona źródła IPv4: 100 wpisów  Powiązanie IPv6-MAC-Port
- 512 wpisów
- Podsłuchiwanie DHCPv6
- Wykrywanie ND
- Podsłuchiwanie ND
- Ochrona źródła IPv6: 100 wpisów Obrona DoS Filtr DHCP Statyczne/dynamiczne zabezpieczenia portu: Do 64 adresów MAC na port Kontrola sztormu rozgłoszeniowego/wielokierunkowego/jednokierunkowego: tryb kontroli kbps/współczynnik/pps 802.1X
- Uwierzytelnianie na podstawie portu
- Uwierzytelnianie na podstawie MAC
- Przypisanie VLAN
- MAB
- Gościnna sieć VLAN
- Obsługa uwierzytelniania i rozliczania RADIUS AAA (w tym TACACS+) Izolacja portu Bezpieczne zarządzanie siecią przez HTTPS z SSLv3/TLS 1.2 Bezpieczne zarządzanie interfejsem wiersza poleceń (CLI) z SSHv1/SSHv2 Kontrola dostępu oparta na IP/Port/MAC
Security - Access Control List (ACL) - Yes
Security - Authentication - Auto VLAN, Guest VLAN
Security - BPDU filtering/protection - Yes
Security - DHCP features - DHCP client, DHCP relay, DHCP server
Security - IGMP snooping - Yes
Security - IP-MAC-Port binding - Yes
Security - MAC address filtering - Yes
Security - SSH/SSL support - Yes
Security - Static port security - Yes
Series - Omada
SFP+ Ports - 4
Shipping Box Depth Shipping/Package Box Dimensions - 53 cm
Shipping Box Height Shipping/Package Box Dimensions - 10.1 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 6.2 kg
Shipping Box Width Shipping/Package Box Dimensions - 44 cm
Short description - TP-LINK Switch SG3428XMPP 24xGBit/4xSFP+ 8x PoE++ (500W) Managed
ShortSummaryDescription - TP-Link Omada SG3428XMPP, Managed, L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
Stck_Kart - 1
Stck_Pal - 2
Storno - Y
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Managed
Switching capacity - 128 Gbps
Switch layer - L2
Switch layer - L2+
Throughput - 128 GB/s
Title - TP-Link Omada SG3428XMPP network switch Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
Unit Box Height - 0.47
Unit Box Length - 0.53
Unit Box Width - 0.1
Unit Brutto Volume - 0.02355 cubm
Unit Gross Weight - 6.2 kg
Unit Net Weight - 5.6 kg
URL - https://www.tp-link.com/ae/business-networking/omada-switch-poe/sg3428xmpp/#specifications
Vendor Homepage - www.tp-link.com/en/business-networking/omada-switch-poe/sg3428xmpp/
vendpn - SG3428XMPP
VLAN - VLAN Group: Max 4K VLAN Groups 802.1q Tagged VLAN MAC VLAN: 30 Entries Protocol VLAN: Protocol Template 16, Protocol VLAN 16 Private VLAN GVRP VLAN VPN: VLAN Mapping, VLAN Replace Voice VLAN
Warranty - 24 months
WarrantyInfo -
Weight & dimensions - Depth - 330 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Width - 440 mm
