Accessories included - NETGEAR GS752TXP z zarządzaniem w chmurze Przewód zasilający (zależnie od regionu) Zestaw do montażu w stelażu Podręcznik instalacji
Application - Medium and large companies
ARTIKEL1 - 48-PORT 1G SMART POE SWITCH
ARTIKEL2 - 380W POE+ BUDGET 4XSFP+
Brand - NETGEAR
BrandPartCode - GS752TXP-300EUS
Breite - 0.41
Category - Network Switches
Certificates - Emisje elektromagnetyczne i odporność: CE, FCC Class A, RCM, ICES Class A, VCCI, KC, BSMI, UKCA Bezpieczeństwo: CB, CE, CSA, RCM, KC, BSMI
Chassis type - Rack
Console port - No
Data transmission - Latency (10 Gbps) - 4.107 µs
Data transmission - MAC address table - 16000 entries
Data transmission - Number of static routes - 32
Data transmission - Packet buffer memory - 16 MB
Data transmission - Static route - Yes
Description - 48-portowy inteligentny przełącznik PoE+ Gigabit Ethernet z opcjonalnym zarządzaniem zdalnym/chmurowym i 4 portami SFP (380W) Autonomiczny przełącznik Smart Switch przeznaczony do sieci konwergentnych, dużych lub małych. Roczna subskrypcja Insight. Rozwiązanie Total Network Solution pomaga w pełni wykorzystać możliwości sieci Łatwe wdrażanie, zarządzanie i monitorowanie zarządzanych przez Netgear insight routerów, przełączników i punktów dostępu z jednego okienka. NETGEAR Insight ZDALNE ZARZĄDZANIE Zarządzaj lokalnie lub zdalnie za pośrednictwem chmury, aby uzyskać prostą, ale potężną kontrolę nad siecią w dowolnym miejscu i czasie. W zestawie znajduje się 1-letnia subskrypcja.
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Stackable - Yes
Designation - CE+WEEE
dimension depth - 400 mm
dimension height - 105 mm
Dimensions - 440 x 310 x 43.2 mm
dimension weight - 12000 g
dimension width - 520 mm
ean - 606449171181
EAN - 606449171181
EANCode - 0606449171181
Environment requirements - Temperatura pracy: 0° do 50°C (32° do 122°F) Wilgotność robocza: 90% maksymalnej wilgotności względnej (RH), bez kondensacji Temperatura przechowywania: 20° do 70°C ( 4° do 158°F) Wilgotność przechowywania: (względna) maksymalna wilgotność względna 95%, bez kondensacji
Fan - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 130.94 Mpps
Gross Weight Kg - 5
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0606449171181
GTIN - 606449171181
guarantee - 0
guarantee_type - perpetual
HERSTELLER - NETGEAR
Hoehe - 0.11
HSTNUMMER - GS752TXP-300EUS
Jumbo frame size - 10 KB
L2 features - Broadcast, multicast, unknown unicast storm control IEEE 802.3ad - LAGs (LACP) IEEE 802.3x (full duplex and flow control) IEEE 802.1D Spanning Tree Protovcol IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.1s Multiple Spanning Tree Protocol Layer 2 DHCP Relay Layer 2 DHCP Relay IGMP snooping (v1, v2 and v3) MLD snooping support (v1 and v2) IGMP snooping querier (v2) MLD snooping querier (v1) Multicast VLAN Registration (MVR)
L3 features - DHCP client DHCP snooping IPv4 static routing: 32 IPv6 static routing: 32 VLAN routing Host ARP table (number of entries) 512 ARP ICMP Router Discovery Protocol (IRDP) Number of IP VLAN interfaces (routed VLANs)
Laenge - 0.53
LongDesc - 48-Port Gigabit Ethernet PoE+ Smart Switch w/ optional Remote/Cloud Management and 4 SFP+ Ports (380W)Standalone Smart Switch designed for converged networks, big or small. 1-Year Insight subscription included.
LongProductName - 48 x GE ports, 4 x 10G ports, 440 x 310 x 43.2 mm, 5.03 kg
LongSummaryDescription - NETGEAR 52-Port PoE Gigabit/10G Stackable Smart Switch (GS752TXP). Switch type: Managed, Switch layer: L2/L3/L4. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 16000 entries. Networking standards: IEEE 802.1ab, IEEE 802.1as, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE.... Power over Ethernet (PoE). Rack mounting
MAC address table size - 16000
Management, monitoring, configuration - Cloud/Remote management Insight mobile app & Insight Cloud Portal management uPnP Discovery Lite Command-line Interface (CLI) Networking monitoring Data/performance logs Centralized network configuration/policies (network-centric management) Device auto-join and configure (zero-touch provisioning) Multi-site, multi-network single pane-of-glass view Multi-switch, multi-port concurrent configuration Network/global password (for all Insight Managed devices on a network) Password management Configurable management VLAN Admin access control via RADIUS and TACACS+ IPv6 management SNTP client over UDP port 123 Port mirroring Many-to-one port mirroring: 52 Web browser-based graphical user interface (GUI) Dual software (firmware) image Cable test utility TLS/HTTPS Web-based access (version) File transfers (uploads, downloads) HTTP upload/download (firmware) Syslog (RFC 3164) USB port for firmware and config upload/download
Management features - Switch layer - L2/L3/L4
Management features - Switch type - Managed
Manufacturer Code - GS752TXP-300EUS
Manufacturer Name - Netgear
Mean time between failures (MTBF) - 1296949 h
name - Smart Switch GS752TXP 48GE PoE+ 4SFP+
Network - 10G support - Yes
Network - Broadcast storm control - Yes
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1ab, IEEE 802.1as, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Voice VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100/1000 Mbps ports - 48
Number of 10Gb ports - 4
Number of PoE+ ports - 48
Number of SFP+ ports - 4
Number of VLAN groups - 256
Operational conditions - Heat dissipation - 2944.6 BTU/h
Operational conditions - Non-operating altitude - 0 - 3000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Łączna moc portów PoE: 380 W Maksymalne zużycie bez PoE: 51 W
Other functions -
Packet buffer - 1.5 MB
Performance - Built-in processor - Yes
Performance - Flash memory - 64 MB
Performance - Mean time between failures (MTBF) - 1296949 h
Performance - Noise level - 36.6 dB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 48
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 10G Ethernet (100/1000/10000)
Ports & interfaces - SFP+ module slots quantity - 2
Power - Power consumption (max) - 51 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption - 436 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 48
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 380 W
Power supply -
Power supply - Internal
producer - Netgear
ProductName - 52-Port PoE Gigabit/10G Stackable Smart Switch (GS752TXP)
QoS - Port-based rate limiting Port-based QoS Support for IPv6 fields DiffServ QoS IEEE 802.1p COS Destination MAC and IP IPv4 and v6 DSC IPv4 and IPv6 ToS TCP/UDP-based Weighted Round Robin (WRR) Strict priority queue technology Auto-VoIP VLAN / Auto-Voice VLAN Auto-VoIP Voice VLAN Auto-Video VLAN
Security - IEEE 802.1x Guest VLAN RADIUS-based VLAN assignment via .1x MAC-based .1x RADIUS accounting Access Control Lists (ACLs) L2 / L3 / L4 IP-based ACLs (IPv4 and IPv6) MAC-based ACLs TCP/UDP-based ACLs MAC lockdown MAC lockdown by the number of MACs Control MAC # Dynamic learned entries: 16384 Control MAC # static entries: 256 IEEE 802.1x RADIUS port access authentication Port-based security by locked MAC addresses Dynamic ARP inspection Broadcast, unicast, multicast DoS protection DoS attacks prevention Network storm protection, DoS Broadcast, unicast, multicast DoS protection DoS attacks prevention
Security - Access Control List (ACL) - Yes
Security - DHCP features - DHCP client
Security - IGMP snooping - Yes
Security - MAC address filtering - Yes
Security - SSH/SSL support - Yes
Short description - Netgear 52Port Switch 10/100/1000 GS752TXP
ShortSummaryDescription - NETGEAR 52-Port PoE Gigabit/10G Stackable Smart Switch (GS752TXP), Managed, L2/L3/L4, 10G Ethernet (100/1000/10000), Full duplex, Power over Ethernet (PoE), Rack mounting
Stackability - No
Stck_Kart - 1
Stck_Pal - 23
Storno - Y
Supported protocols and standards - IEEE 802.3 Ethernet IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3af PoE IEEE 802.3at PoE+ IEEE 802.3az Energy Efficient Ethernet (EEE) IEEE 802.3ad Trunking (LACP) IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX IEEE 802.3x Full-Duplex Flow Control IEEE 802.1Q VLAN Tagging IEEE 802.1AB LLDP with ANSI/TIA-1057 (LLDP-MED) IEEE 802.1p Class of Service IEEE 802.1D Spanning Tree (STP) IEEE 802.1s Multiple Spanning Tree (MSTP) IEEE 802.1w Rapid Spanning Tree (RSTP) IEEE 802.1x RADIUS Network Access Control
Support for Jumbo frames - Yes
Switch class - SMART
Switch layer - L3
Throughput - 176 Gb/s
Title - NETGEAR 52-Port PoE Gigabit/10G Stackable Smart Switch (GS752TXP)
URL - https://www.netgear.com/uk/business/wired/switches/smart-cloud/gs752txpv3/
vendpn - GS752TXP-300EUS
VLAN - IEEE 802.1Q VLAN tagging IP-based VLANs MAC-based VLANs Auto-VoIP VLAN / Auto-Voice VLAN Auto-VoIP Voice VLAN Auto-Video VLAN GARP with GVRP Private VLAN
WarrantyInfo -
Weight - 5.03 kg
Weight & dimensions - Depth - 345 mm
Weight & dimensions - Height - 43 mm
Weight & dimensions - Weight - 5.54 kg
Weight & dimensions - Width - 440 mm
