ARTIKEL1 - TAA 1000SX/LC PCIE ADPTCARD
ARTIKEL2 - 990-005524-901
Brand - Allied Telesis
BrandPartCode - AT-2911SX/LC-901
Category - Network Cards
Design - Certification - UL
FCC/EN55022 A
TUV
EN55024
CE
C-TICK
VCCI
Design - Internal - Yes
Design - LED indicators - Yes
EANCode - 0767035196794
GRUPPE1 - Network
GRUPPE2 - Network Adapters
GTIN - 0767035196794
GTIN - 767035196794
HERSTELLER - ALLIED TELESIS
HSTNUMMER - AT-2911SX/LC-901
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Allied Telesis AT-2911 Series Network Interface Cards feature a PCI Express (PCIe x1) design, providing the maximum possible bandwidth and bus efficiency while providing the benefits of low power consumption.High ReliabilityThe AT-2911 Series Gigabit interface comes with a comprehensive Microsoft Windows utility which performs detailed tests, diagnostics and analysis.Advanced ManageabilityThe priority queuing offered by the AT-2911 Series can help users set up the network based on their own needs. The comprehensive diagnostics and configuration software suite provides system administrators and engineers with a profound tool to analyze the interface card and check specific data.
LongProductName - 1000BASE-SX Single-port Fiber NIC for PCIe x1 bus, LC connector, Federal/Government
LongSummaryDescription - Allied Telesis AT-2911SX/LC-901. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Fiber. Maximum data transfer rate: 1000 Mbit/s
Network - Fiber ethernet cabling technology - 1000BASE‑SX
Network - Jumbo frames support - Yes
Network - Maximum data transfer rate - 1000 Mbit/s
Network - Networking standards - IEEE 802.1p, IEEE 802.1Q, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Operational conditions - Operating relative humidity (H-H) - 5 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -25 - 70 °C
Other features - Flow control support - Yes
Other features - Link/Act LED - Yes
Other features - Management protocols - SNMP
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - Fiber optic connector - LC
Ports & interfaces - Fiber ports quantity - 1
Ports & interfaces - Host interface - PCI Express
Ports & interfaces - Interface - Fiber
Power - Output voltage - 3.3 V
Power - Power consumption (typical) - 9.2 W
ProductName - AT-2911SX/LC-901
ShortSummaryDescription - Allied Telesis AT-2911SX/LC-901, Internal, Wired, PCI Express, Fiber, 1000 Mbit/s
Stck_Kart - 20
Stck_Pal - 40
Storno - Y
System requirements - Linux operating systems supported - Yes
System requirements - Windows operating systems supported - Yes
Technical details - Compliance certificates - RoHS
Title - Allied Telesis AT-2911SX/LC-901 network card Internal Fiber 1000 Mbit/s
URL - https://www.alliedtelesis.com/
WarrantyInfo -
Weight & dimensions - Height - 56 mm
Weight & dimensions - Weight - 700 g
Weight & dimensions - Width - 87 mm
