Synology Adapter E10G18-T1 10GbE

Accessories included -
Antenna - Not applicable
Category Code - NIC
Category_1 - Network and Servers
Category_2 - NAS
Chipset type -
Code - E10G18-T1
Compatible with - Series FS: FS2500, FS6400, FS3600, FS3400, FS3017, FS2017, FS1018 Series SA: SA3600, SA3400, SA3200D Series UC: UC3200 Series 22: DS3622xs+, DS2422+ Series 21: RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+, RS1221RP+, RS1221+, DS1821+, DS1621xs+, DS1621+ Series 20: RS820RP+, RS820+ Series 19: RS1619xs+, RS1219+, DS2419+, DS2419+II, DS1819+ Series 18: RS3618xs, RS2818RP+, RS2418RP+, RS2418+, RS818RP+, RS818+, DS3018xs, DS1618+ Series 17: RS18017xs+, RS4017xs+, RS3617xs+, RS3617RPxs, RS3617xs, DS3617xs, DS3617xsII, DS1817+, DS1517+ Series 16: RS18016xs+ Series 15: RC18015xs+, DS3615xs Series 14: RS3614xs+, RS3614RPxs, RS3614xs Series 13: RS10613xs+, RS3413xs+ Series 12: RS3412RPxs, RS3412xs, DS3612xs Series 11: RS3411RPxs, RS3411xs, DS3611xs
Data transmission speed - 10 Gbps
Description - Equipped with an RJ-45 connector with support for IEEE 802.3an / bz (10GBASE-T / NBASE-T) and 802.3x standards, E10G18-T1 helps smoothly migrate to a 10GbE network environment with existing infrastructure.
Description - Single-port, high-speed 10GBASE-T/NBASE-T add-in card for Synology NAS servers Equipped with an RJ-45 connector and supports IEEE 802.3an/bz (10GBASE-T/NBASE-T) and 802.3x, E10G18-T1 helps you smoothly migrate to a 10GbE networking environment with your existing infrastructure. Supporting backward compatibility and auto-negotiation between 10Gbps, 5Gbps, 2.5Gbps, 1Gbps, and 100Mbps, E10G18-T1 is an economic solution to overcome the data transmission bottleneck for small businesses and home users.
Design - Compatible products - FS series:FS2500, FS6400, FS3600, FS3400, FS3017, FS2017, FS1018
SA series:SA3600, SA3400, SA3200D
UC series:UC3200
22 series:DS3622xs+, DS2422+
21 series:RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+, RS1221RP+, RS1221+, DS1821+, DS1621xs+, DS1621+
20 series:RS820RP+, RS820+
19 series:RS1619xs+, RS1219+, DS2419+, DS2419+II, DS1819+
18 series:RS3618xs, RS2818RP+, RS2418RP+, RS2418+, RS818RP+, RS818+, DS3018xs, DS1618+
17 series:RS18017xs+, RS4017xs+, RS3617xs+, RS3617RPxs, RS3617xs, DS3617xs, DS3617xsII, DS1817+, DS1517+
16 series:RS18016xs+
15 series:RC18015xs+, DS3615xs
14 series:RS3614xs+, RS3614RPxs, RS3614xs
13 series:RS10613xs+, RS3413xs+
12 series:RS3412RPxs, RS3412xs, DS3612xs
11 series:RS3411RPxs, RS3411xs, DS3611xs
Design - Internal - Yes
Design - Product colour - Black
Design - Product colour - Blue
dimensionalWeight - 141
dimension depth - 30 mm
dimension height - 175 mm
Dimensions -
dimension weight - 140 g
dimension width - 135 mm
ean - 846504003105
EAN - 4711174723102
EAN_code - 4711174723102
Full Description Line - PCIE|Number of ports 1|Data transmission speed 10 Gbps
Gross Weight Kg - 1
guarantee - 60
guarantee_type - normal
I/O ports - 1 x 10GBASE-T
Interface - PCIe
Link - https://www.synology.com/en-global/products/E10G18-T1
Logistics data - Harmonized System (HS) code - 85176990
Manufacturer - Synology
Manufacturer Code - E10G18-T1
Manufacturer Name - Synology
Manufacturer_code - E10G18-T1
name - Expansion card E10G18-T1 10GbE
Name - Synology E10G18-T1, LAN adapter
Name - Synology | E10G18-T1 Single Port 10Gb RJ45 PCIe Network Interface Card | PCIe 3.0 x4
Network - Auto-negotiation - Yes
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000 Mbit/s
Network - Ethernet LAN data rates - 2500 Mbit/s
Network - Ethernet LAN data rates - 5000 Mbit/s
Network - Ethernet LAN data rates - 10000 Mbit/s
Network - Full duplex - Yes
Network - Jumbo frames - 9000
Network - Jumbo frames support - Yes
Network - Maximum data transfer rate - 10000 Mbit/s
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3an
Network - Networking standards - IEEE 802.3bz
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Number of antennas - Not applicable
Number of ports - 1
Operating frequency - Not applicable
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features -
Other features - Flow control support - Yes
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 176 mm
Package features > Gross height (mm) - 33 mm
Package features > Gross width (mm) - 137 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 2172 pc(s)
Package features > Paper/Pasteboard - 80.00 g
Package features > Plastic (No PET) - 20.00 g
Package features > Tare weight (kg) - 0.10 kg
Package features > Volume (m3) - 0.000795696 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - No
Packaging data - Quantity - 1
PCIE Slot Type - Yes
PDF - https://www.blobs.lt/products/7/0/7/9/5/3/332eb4c1866e23f3811477c75d67f989/original.pdf
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Host interface - PCI Express
Ports & interfaces - Interface - Ethernet
Ports & interfaces - PCI Card form factor - Full-height (low-profile)
Ports & interfaces - PCI version - 3.0
Ports & interfaces > Host interface - PCIe 3.0 x4
producer - Synology
producerCode - E10G18-T1
Producer product name - E10G18-T1 Single Port 10Gb RJ45 PCIe Network Interface Card
productName - Synology E10G18-T1 network card Internal Ethernet 10000 Mbit/s
productSize - Normal
Security -
Shipping Box Depth Shipping/Package Box Dimensions - 18 cm
Shipping Box Height Shipping/Package Box Dimensions - 3 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.14 kg
Shipping Box Width Shipping/Package Box Dimensions - 13 cm
Short description - Synology NAS 1x 10GBase-T RJ45 Netzwerkkarte E10G18-T1
sizeX - 175
sizeY - 135
sizeZ - 30
Standards - 802.3ab
Standards - 802.3an
Standards - 802.3bz
Standards - 802.3u
Standards - 802.3x
System Requirements -
System requirements > Compatibility - FS series:FS2500, FS6400, FS3600, FS3400, FS3017, FS2017, FS1018; SA series:SA3600, SA3400, SA3200D; UC series:UC3200; 22 series:DS3622xs+, DS2422+; 21 series:RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+, RS1221RP+, RS1221+, DS1821+, DS1621xs+, DS1621+; 20 series:RS820RP+, RS820+; 19 series:RS1619xs+, RS1219+, DS2419+, DS2419+II, DS1819+; 18 series:RS3618xs, RS2818RP+, RS2418RP+, RS2418+, RS818RP+, RS818+, DS3018xs, DS1618+; 17 series:RS18017xs+, RS4017xs+, RS3617xs+, RS3617RPxs, RS3617xs, DS3617xs, DS3617xsII, DS1817+, DS1517+; 16 series:RS18016xs+; 15 series:RC18015xs+, DS3615xs; 14 series:RS3614xs+, RS3614RPxs, RS3614xs; 13 series:RS10613xs+, RS3413xs+ ;12 series:RS3412RPxs, RS3412xs, DS3612xs; 11 series:RS3411RPxs, RS3411xs, DS3611xs
Technical details > Gross weight - 0.139 kg
Technical details > Net weight - 0.039 kg
Technical details > Producer - Synology
Technical details > Warranty - 60 month(s)
Type - LAN
Unit Box Height - 0.03
Unit Box Length - 0.18
Unit Box Width - 0.13
Unit Brutto Volume - 0.000702 cubm
Unit Gross Weight - 0.14 kg
Unit Net Weight - 0.12 kg
Vendor Homepage - www.synology.com/en-global/products/E10G18-T1
vendpn - E10G18-T1
Warranty - 60
Warranty - 60 months
warrantyLength - 60
warrantyType - F
Weight - 0,19
weight - 140
Weight & dimensions - Depth - 13.6 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 68.1 mm
