Kioxia EXCERIA G2, 1TB, M.2 Gen3 x4

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 813672 Product code: LRC20Z001TG8
Can be ordered 55 units Availability: 14 days after order approval
Warranty: 3 years
61.42 €
Delivery options
  • Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
  • Courier delivery 11.99 €: 10.12.2024
Main product parameters All parameters
  • Capacity: 1 TB
  • Type: NVMe
  • Read speed (sequential): 2100 MB/s
  • Write speed (sequential): 1700 MB/s
  • Form factor: M.2 80mm (2280)
  • Interface: PCIe 3.0 x4
Description

Available for purchase, the Kioxia M.2 80mm (2280) format SSD disk with a large volume of 1 TB.

The disk is equipped with the currently most advanced and compact M.2 connection port.

This is a fast-acting NVME SSD drive, based on PCIe technology. It allows data to be transmitted in parallel over multiple channels, ensuring excellent performance. This type of drive is perfectly suited for activities such as processing large files, gaming, and video editing, where maximum data transmission speed is required.

2100 MB/s – this is the data reading speed that this SSD disk is capable of reaching. However, we must remember one crucial nuance - "fast" disks may not show the performance promised by the manufacturer if adequate cooling is not provided.

1700 MB/s - this SSD drive is capable of achieving such data writing speed. The speed parameters promised by the manufacturer may not be reached if the "fast" disk is not provided with an appropriate cooling system.

This SSD drive has an M.2 80mm (2280) format.

The SSD drive has a PCIe 3.0 x4 interface. If it is inserted into an older interface slot, the potential speed of the drive will not be fully utilized, as the older interface will not provide sufficient data transfer bandwidth.

Basic information
Capacity 1 TB
The HDD capacity in Gigabytes indicates how much information can be stored by the HDD. The capacity of the HDD is fixed and cannot be increased after buying the HDD. Therefore, upon buying the HDD you should verify its compliance with your current volume requirements and provides a reserve for future needs.
Type : NVMe
Read speed (sequential) 2100 MB/s

Sequential read speed or the mean data reading speed is the most important criterion of the high-speed operation of the SSD. The data from the SSD will be read much more often than written to it because the operating system stores the processed data in the RAM in most cases.

If you want the reading speed of the purchased SSD to exceed the speed of the classic HDD considerably you should choose the SSD with the reading speed of 200 MB/s or above. The additional increase in the performance will be achieved on the account of the data search (SeekTime) which is of much higher level with SSDs than any HDD.

Write speed (sequential) 1700 MB/s

The writing speed is almost as important as the reading speed. Also this parameter determines the performance of the SSD, however, as the writing to the disc happens not as often as the data reading and average user will find it subjectively difficult to distinguish between any speed above 100 MB/s and higher indices, except the cases when the SSD is used in a server, for audio/video recording, etc.

Functionality
Radiators : Nav
Lighting : Nav
Ports and equipment
Form factor M.2 80mm (2280)

Thanks to the small size provided by the SSD technology the standard size of the discs is 2.5", and it is suitable for an average portable computer. It is possible to install the 2.5" disc in the desktop computer if the transition 2.5" -> 3.5" is used, and this transition can be bought at a low cost at TopPC.fi section"Adapteri". The discs with the format 2.5" + 3.5" have this transition included.

1.8" discs are intended for the ultra-compact class portable computers.

PCI-Express SSDs are intended for desktop computers with a free PCI-Express plug available. This technology in most cases is used for ensuring the performance that exceeds the possibilities of other types of connections.

Interface : PCIe 3.0 x4
Interface M.2

SSDs with SATAII and SATAIII connection are compatible with the connections of both types in the motherboard. Still, it has to be taken into account that the motherboard SATAII connection can provide maximum about 300 MB/s transmission capacity which can reduce the actual transmission capacity of the SSDs whose reading and/or writing speed exceeds this level to the capacity limits of the SATAII.

The situation is similar with the PCI-Express and SATAIII connection slots. Although the SATAIII standard can provide up to 600 MB/s data transmission capacity there are SSDs with the speed exceeding this limit, in this case the manufacturer chooses the PCI-Express connection slot with a higher transmission capacity. The PCI-Express discs cannot be connected to the portable computer.

Specifikācija
Memory type : TLC (Triple-Level Cell)
Random Read IOPS : 400K
Random Write IOPS : 400K
Endurance (TBW) : 400 TB
More detailed specification
Category - Root/Electronics/PC parts/Hard drives
Color - Not applicable
Depth - 22.15 mm
Description - The second generation KIOXIA EXCERIA G2 SSD takes performance to a new level with a maximum sequential read speed of up to 2100MB/s1, enabling faster boot-up, file transfer and system operation. The use of BiCS FLASH 3D flash memory allows the entry-level SSD to reach capacities of up to 2TB and the M.2 2280 interface allows its use in both desktop and notebook computers. Affordable performance KIOXIA EXCERIA Series SSDs set new standards for the everyday storage segment, leaving SATA-based drives behind. Forget latency and enjoy fast and responsive computing and application performance. Compared to SATA SSDs, EXCERIA G2 SSD series offers a better balance of performance and quality that will transform your system. Easy expandability due to compact size Featuring a thin, single-sided M.2 2280 interface, the EXCERIA G2 SSD series connects directly to the motherboard, reducing cable clutter and making upgrading your PC much easier. NVMe technology  What's the point of using interfaces designed for hard disk drives? With the EXCERIA G2 SSD series, NVMe 1.3c reduces the latency on the I/O path between the drive and the processor, allowing the entire system to run smoother and faster. Ultimate 3D Flash Memory All EXCERIA Series SSDs use BiCS FLASH memory and vertical memory cell structure technology for ultimative performance. SSD Utility management software The SSD Utility software allows you to get the most out of your KIOXIA devices, as well as full control over maintenance, monitoring, optimisation, and more! To maximise the performance of your drive and monitor its remaining service life via the status indicator, we strongly recommend that you install and upgrade to the latest version of the software.
dimensionalWeight - 45
dimension depth - 19 mm
dimension height - 120 mm
dimension weight - 42 g
dimension width - 90 mm
Disk type - SSD
Drive type - Internal
ean - 4582563853997
Eans - 4582563853997
Features - Component for - Laptop
Features - Data transfer rate - 32 Gbit/s
Features - Interface - PCI Express 3.1a
Features - Mean time between failures (MTBF) - 1500000 h
Features - Memory type - BiCS FLASH TLC
Features - NVMe - Yes
Features - NVMe version - 1.3c
Features - Random read (4KB) - 400000 IOPS
Features - Random write (4KB) - 400000 IOPS
Features - Read speed - 2100 MB/s
Features - SSD capacity - 1 TB
Features - SSD form factor - M.2
Features - Write speed - 1700 MB/s
Form factor (width) - M.2 2280
guarantee - 60
guarantee_type - normal
HDD capacity - 1 TB
HDD interface - PCI-Express
Height - 2.23 mm
Model - EXCERIA G2 NVMe
Name - Kioxia Exceria (G2) M.2 Pci-e NVMe 1TB
name - SSD Exceria G2 1TB NVMe 2100/1700MB/s
Operational conditions - Operating temperature (T-T) - 0 - 85 °C
Operational conditions - Storage temperature (T-T) - -40 - 85 °C
Other features -
Power - Operating voltage - 3.3 V
Power - Power consumption (max) - 3.5 W
producer - Kioxia
Producer - Kioxia
producerCode - LRC20Z001TG8
ProducerCode - LRC20Z001TG8
productName - Kioxia EXCERIA G2 M.2 1 TB PCI Express 3.1a BiCS FLASH TLC NVMe
productSize - Normal
Random read IOPS (max) - 400 K
Random write IOPS (max) - 400 K
Reading speed - 2100 MB/s
ShortDescription - SSD | 1TB | 2100/1700 MB/s | M.2 | 2280 | PCI-E | NVMe
sizeX - 125
sizeY - 90
sizeZ - 20
TBW - 400 TB
vendpn - LRC20Z001TG8
warrantyLength - 60
warrantyType - G
Weight - 6.8 kg
weight - 40
Weight & dimensions - Depth - 2.23 mm
Weight & dimensions - Height - 22.1 mm
Weight & dimensions - Weight - 6.8 g
Weight & dimensions - Width - 80.2 mm
Width - 80.15 mm
Writing speed - 1700 MB/s
