ID: 528012
Product code: SMV3000CAI
In stock 1 units
Warranty: 2 years
APC Easy UPS SMV3000CAI 3000VA, 2100W, IEC
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
Delivery options
- Delivery to Smartpost parcel locker 6.99 €: {delivery_2_txt_full}
- Courier delivery 11.99 €: on Friday, 29.11.2024
Main product parameters All parameters
- Battery capacity (VA): 3000 VA
- Output power (W): 2100 W
Display characteristics
Display
: Ir
Basic information
Battery capacity (VA)
3000 VA
The capacity of the battery pack is the index of the long-term operation of the UPS device without a permanent power supply source. This parameter applies to a UPS device with a fully charged battery pack. If you want to verify how big capacity is required for your computer equipment visit www.apc.ru where you will find the UPS capacity determination configuration tool.
Battery type
: Lead acid
Charging time (hours)
: 4h
Output power (W)
: 2100 W
Ports and equipment
Number of nests (total)
: 6
Number of sockets (Battery Backup)
: 6
RJ-45
: 0
Socket type
: IEC320
USB
: 0
More detailed specification
Accessories included - Uninterruptible power supply Documentation CD USB cable User manual
Active power - 2100 W
Apparent power - 3000 VA
ARTIKEL1 - EASY UPS SMV 3000VA 230V WITH
ARTIKEL2 - BATTERY BACKUP + SURGE PROTECTIO
Battery - Battery capacity - 9 Ah
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 4 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 12 V
Battery - Cold start - Yes
Battery - Number of batteries supported - 4
Battery life (max), years - 3 - 5
Battery recharge time, h - 4
Brand - APC
BrandPartCode - SMV3000CAI
Category - Uninterruptible Power Supplies (UPSs)
Charging time - 4 h
Chassis type - Tower
Color - Black
Connections - USB
Depth, mm - 455
Description - APC EASY UPS SMV 3000VA 230V
Description - Easy UPS provides power protection in unstable power conditions, ensuring constant and reliable connectivity at the most critical times.
Design - Certification - CE
Design - Display type - LCD
Design - Form factor - Tower
Design - International Protection (IP) code - IP20
Design - LED indicators - Yes
Design - Product colour - Black
dimension depth - 600 mm
dimension height - 420 mm
Dimensions - 455 x 180 x 240 mm
dimension weight - 29000 g
dimension width - 320 mm
ean - 731304346555
EANCode - 0731304346555
Environment requirements - Operating temperature: 0 - 40 °C Relative humidity: 0 - 95 % (non-condensing) Operating altitude: 0 - 3,000 metres Storage temperature: -10 - 40 ° C Storage relative humidity: 0 - 95 % (non-condensing) Storage altitude: 0 - 15,000 metres Audible noise at a distance of 1 metre from the device: 45.0 dBA Protection class: IP20
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Low battery alarm, Overload alarm
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Crest factor - 3:1
Features - Input frequency - 45/65 Hz
Features - Input operation voltage (max) - 303 V
Features - Input operation voltage (min) - 157 V
Features - Maximum current - 25 A
Features - Noise level - 45 dB
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 230 V
Features - Output operation voltage (min) - 230 V
Features - Output power - 2100 W
Features - Output power capacity - 3 kVA
Features - Output voltage regulation - -1 - 1%
Features - Power protection features - Overload, Short circuit
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
Filters / protection - Circuit
Filters / protection - Overload
Filters / protection - Surge
Form factor - Tower
Frequency range, Hz - 50/60
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0731304346555
GTIN - 731304346555
guarantee - 24
guarantee_type - external
Height - 410.000000
Height, mm - 240
HERSTELLER - APC
HSTNUMMER - SMV3000CAI
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
Input connection - IEC-320 C20
Input frequency, Hz - 45 - 65
Input power ports - IEC-C20
Length - 605.000000
Logistics data - Harmonized System (HS) code - 85078000
LongSummaryDescription - APC Easy UPS SMV. UPS topology: Line-Interactive, Output power capacity: 3 kVA, Output power: 2100 W. AC outlet types: IEC 320, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 12 V. Form factor: Tower, Product colour: Black, Display type: LCD. Width: 180 mm, Depth: 455 mm, Height: 240 mm
Manufacturer - APC
ManufacturerPartNumber - SMV3000CAI
name - UPS SMV3000CAI Easy UPS SMV 3000VA
No. of batteries - 1
Noise level, dB - 45
Nominal input voltage, V - 157 - 303
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0-95
Operating temperature range (T-T), °C - 0-40
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -10 - 40 °C
Other features -
Output interface - 6 x IEC 320 C13
Output power, W - 2100
Output power capacity (VA) - 3000
Output power ports - 6 x IEC-C13
Packaging data - Cables included - USB cable
Packaging data - Manual - Yes
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 6 AC outlet(s)
Ports & interfaces - AC outlet types - IEC 320
Ports & interfaces - USB port - Yes
producer - APC
ProductName - Easy UPS SMV
ShortSummaryDescription - APC Easy UPS SMV, Line-Interactive, 3 kVA, 2100 W, Sine, 157 V, 303 V
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 4
Storage temperature range (T-T), °C - -10-40
Storno - Y
The shape of the output voltage - Full sine wave
Title - APC Easy UPS SMV uninterruptible power supply (UPS) Line-Interactive 3 kVA 2100 W 6 AC outlet(s)
Transfer time (max) - 6 ms
UPS Architecture - line-interactive
UPS devices and accessories - Yes
vendpn - SMV3000CAI
Voltage - 48 V
Weight - 25.2 kg
Weight - 29.120000
Weight & dimensions - Battery depth - 60.1 cm
Weight & dimensions - Battery height - 41 cm
Weight & dimensions - Battery weight - 28.9 kg
Weight & dimensions - Battery width - 32.6 cm
Weight & dimensions - Depth - 455 mm
Weight & dimensions - Height - 240 mm
Weight & dimensions - Weight - 25.2 kg
Weight & dimensions - Width - 180 mm
Weight, kg - 25.2
Width - 320.000000
Width, mm - 180
