APC Smart-UPS SRT1000RMXLI 1000VA, 1000W, IEC, 2U

Accessories included - Software CD Communication cable CD with documentation Installation Guide Brackets for mounting in the cabinet Elements for mounting in the cabinet Mounting rails for rack mounting USB cable Warranty Car
Active power - 1000 W
Apparent power - 1000 VA
ARTIKEL1 - SMART-UPS SRT 1000VA RM 230V
ARTIKEL2 - IN
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 3 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Hot-swap battery - Yes
Brand - APC
BrandPartCode - SRT1000RMXLI
Category - Uninterruptible Power Supplies (UPSs)
Charging time - 3 h
Chassis type - Rack
Color - Black
Description - APC Smart-UPS SRT 1000VA RM 230V High-density power and double-conversion online protection with scalable working time.
Design - Cable length - 1.5 m
Design - Certification - CE, EAC
Design - Form factor - Rackmount/Tower
Design - International Protection (IP) code - IP20
Design - LED indicators - Status
Design - Product colour - Black
dimension depth - 740 mm
dimension height - 235 mm
Dimensions - 432 x 505 x 85 mm 2U
dimension weight - 30050 g
dimension width - 600 mm
ean - 731304340256
EAN - 0731304340256
EANCode - 0731304340256
Environment requirements - Working temperature: 0 - 40 ° C Relative humidity during operation: 0 - 95% (without condensation) Working height: 0-3000 meters Storage temperature: -20 - 50 ° C Relative humidity of the memory: 0 - 95% (without condensation) Storage height: 0-15000 meters
Features - Audible alarm(s) - Yes
Features - Crest factor - 3:1
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 40/70 Hz
Features - Input operation voltage (max) - 150 V
Features - Input operation voltage (min) - 50 V
Features - Noise level - 50 dB
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 1000 W
Features - Output power capacity - 1 kVA
Features - Surge energy rating - 432 J
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Filters / protection - Surge
Filters / protection - Voltage drop
Gross Weight Kg - 29,6
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304340256
GTIN - 0731304340256
guarantee - 36
guarantee_type - external
HERSTELLER - APC
HSTNUMMER - SRT1000RMXLI
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB 2.0
Input power ports - IEC-C14
Input power ports - Type F Schuko
Input power ports - Type G British
Input power ports - Wtyczka sieciowa
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 12 pc(s)
LongDesc - High density, double-conversion on-line power protection with scalable runtimeIncludes: CD with software, Comms cable, Documentation CD, Installation guide, Rack Mounting brackets, Rack mounting hardware, Rack Mounting support rails, USB cable, Warranty cardBattery failure notificationProvides early-warning fault analysis on batteries enabling timely preventive maintenanceECO ModeOperating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protectionLCD graphics displayText and mimic diagrams that display modes of operation, system parameters and alarms.Rack/Tower convertibleProtects the initial investment in the UPS when migrating from tower to rack-mount environment.Temperature-compensated battery chargingProlongs battery life by regulating the charge voltage according to battery temperature.Automatic internal bypassSupplies utility power to the connected loads in the event of a UPS power overload or fault.Scalable runtimeAllows additional run time to be quickly added as needed.Hot-swappable batteriesEnsures clean, uninterrupted power to protected equipment while batteries are being replacedIntelligent battery managementMaximizes battery performance, life, and reliability through intelligent, precision charging.Automatic restart of loads after UPS shutdownAutomatically starts up the connected equipment upon the return of utility power.LED status indicatorsQuickly understand unit and power status with visual indicators.Serial connectivityProvides management of the UPS via a serial port.InfraStruXure Manager CompatibleEnables centralized management via the APC InfraStruXure Manager.SmartSlotCustomize UPS capabilities with management cards.Network manageableProvides remote power management of the UPS over the network.Flash upgradeable firmwareInstall maintenance releases of firmware remotely using FTP.Plug-and-Play external batteriesEnsures clean, uninterrupted power to the loads when adding extra runtime to the UPS.Rack/Tower convertibleProtects the initial investment in the UPS when migrating from tower to rack-mount environment.User-replaceable batteriesIncreases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)Automatic self-testPeriodic battery self-test ensures early detection of a battery that needs to be replaced.Predictive failure notification.Provides early-warning fault analysis ensuring proactive component replacement.Disconnected battery notificationWarns when a battery is not available to provide backup power.Audible alarmsProvides notification of changing utility power and UPS power conditionsGenerator compatibleEnsures clean, uninterrupted power to protected equipment when generator power is used.Cold-start capableProvides temporary battery power when the utility power is out.Frequency and voltage regulationGives higher application availability by correcting poor frequency and voltage conditions without using the battery.Power conditioningProtects connected loads from surges, spikes, lightning, and other power disturbances.Safety-agency approvedEnsures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.Input power factor correctionMinimizes installation costs by enabling the use of smaller generators and cabling.Resettable circuit breakerEasy recovery from overloads; no need to replace a fuse. (Not available on Wall Tap SKUs)
LongProductName - 432 J, 1 kW, 1 kVA, 2U, 230V, 1.83 m, 50/60 Hz, 40-70 Hz, RJ-45, Smart-Slot, USB
LongSummaryDescription - APC SRT1000RMXLI. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 1000 W. Serial interface type: RJ-45. Battery technology: Sealed Lead Acid (VRLA), Battery life (max): 5 year(s), Battery recharge time: 3 h. Form factor: Rackmount/Tower, Product colour: Black, Cable length: 1.5 m. Width: 432 mm, Depth: 505 mm, Height: 85 mm
Manufacturer Code - SRT1000RMXLI
Manufacturer Name - APC by Schneider Electric
name - SRT1000RMXLI Smart-UPS SRT1kVA/1kW 230V Rack
No. of batteries - 1
Number of phases input - 1 (230V)
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 50 °C
Other features - Output power: 1.0 kWat / 1.0 kVA Output frequency (synchronization with the network): 50 / 60Hz +/- 3 Hz Input frequency: 40-70 Hz (automatic detection) Cable length: 1.83 meters Audible noise at a height of 1 meter from the surface of the device: 50.0 dBA Protection class IP 20
Output power ports - 6 x IEC-C13
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RJ-45
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
producer - APC
ProductName - SRT1000RMXLI
Short description - APC Smart-UPS SRT 1000 VA RM SRT1000RMXLI
ShortSummaryDescription - APC SRT1000RMXLI, Double-conversion (Online), 1 kVA, 1000 W, Sine, 50 V, 150 V
Software - PowerNet MIB v4.2.8
Special functions -
Stck_Kart - 1
Stck_Pal - 8
Storno - Y
Technical details - Compliance certificates - RoHS
Technical details - Sustainability certificates - Green Premium
Title - APC SRT1000RMXLI uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 1000 W
UPS Architecture - on-line double conversion
URL - https://www.apc.com/shop/uk/en/products/APC-Smart-UPS-SRT-1000VA-RM-230V/P-SRT1000RMXLI
vendpn - SRT1000RMXLI
Voltage - 230 V
WarrantyInfo - 3 years
Weight - 21 kg
Weight & dimensions - Depth - 505 mm
Weight & dimensions - Height - 85 mm
Weight & dimensions - Package depth - 749 mm
Weight & dimensions - Package height - 246 mm
Weight & dimensions - Package weight - 29.6 kg
Weight & dimensions - Package width - 594 mm
Weight & dimensions - Weight - 21 kg
Weight & dimensions - Width - 432 mm
