ID: 215684
Product code: VI 2200 RLE
In stock 6 units
Warranty: 2 years
Power Walker VI 2200 RLE, 2200VA 1320W, IEC 2U
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
Delivery options
- Courier delivery 11.99 €: 21.03.2025
Main product parameters All parameters
- Battery capacity (VA): 2200 VA
- Output power (W): 1320
Display characteristics
Display
: Ir
Basic information
Battery capacity (VA)
2200 VA
The capacity of the battery pack is the index of the long-term operation of the UPS device without a permanent power supply source. This parameter applies to a UPS device with a fully charged battery pack. If you want to verify how big capacity is required for your computer equipment visit www.apc.ru where you will find the UPS capacity determination configuration tool.
Battery type
: Nav norādīts
Charging time (hours)
: 4h
Output power (W)
: 1320
Ports and equipment
Number of nests (total)
: 4
Number of sockets (Battery Backup)
: 4
RJ-45
: 2
Socket type
: IEC320
USB
: 0
More detailed specification
Accessories included -
Active power - 1320 W
Apparent power - 2200 VA
Backup time (100% load) - 3.1 min
Battery - Battery capacity - 9 Ah
Battery - Battery recharge time (90%) - 4 h
Battery - Battery voltage - 12 V
Battery - Number of batteries supported - 2
Battery - Typical backup time at full load - 1.1 min
Battery - Typical backup time at half load - 7.1 min
Battery capacity - 9 Ah
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category_1 - Power
Category_2 - UPS
Charging time - 4 h
Chassis type - Rack
Color - Black
Description - PowerWalker VI 1200-3000 RLE is a compact LINE-INTERACTIVE series topology designed for rack 19 units. The device provides a full sine wave output, offering optimal protection for small motor loads and servers with APFC power supplies. The USB port has HID support, which allows native communication with almost all typical operating systems - eliminating the need to install additional software. Better internal heat dissipation makes the UPS run quietly during standard operation. The extensive LCD panel provides all the necessary information and automatically dims after a few seconds. These features make the UPS series an attractive solution for home use as well.
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 14168
dimension depth - 230 mm
dimension height - 560 mm
Dimensions - 88 x 430 x 438 mm
dimension weight - 19120 g
dimension width - 560 mm
ean - 4260074981186
Eans - 4260074981186
EAN_code - 4260074981186
Environment requirements - 0 - 40 °C
Features - Input frequency - 45/55 Hz
Features - Input operation voltage (max) - 290 V
Features - Input operation voltage (min) - 165 V
Features - Noise level - 50 dB
Features - Output operation voltage (max) - 230 V
Features - Output operation voltage (min) - 230 V
Features - Output power - 1320 W
Features - Output power capacity - 2.2 kVA
Features - Output power factor - 0.6
Features - Power protection features - Overload
Features - UPS topology - Line-Interactive
Filters / protection - Surge
guarantee - 24
guarantee_type - normal
Hold-up time (maks) - 4 ms
I/O connectors - 2 x RJ-45 LAN
Input power ports - IEC-C14
Logistics data - Harmonized System (HS) code - 85078000
Manufacturer - Bluewalker
Manufacturer_code - 10121100
Name - Bluewalker PowerW VI 2200 RLE
Name - Power Walker VI 2200 RLE
name - UPS Line-Interactive 2200VA Rack 19 4x IEC Out, RJ11/RJ45 In/Out, USB, LCD, EPO
No. of batteries - 2
Number of phases input - 1 (120V)
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features - Waveform: sinusoid
Output power ports - 4 x IEC-C13
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - USB port - Yes
producer - PowerWalker
Producer - Power Walker
producerCode - VI 2200 RLE
ProducerCode - VI 2200 RLE
productName - PowerWalker VI 2200 RLE Line-Interactive 2.2 kVA 1320 W 4 AC outlet(s)
productSize - Normal
ShortDescription - Line-Interactive 2200VA | Rack 19" | 4X IEC C13 | USB | RJ11/45 In/Out | LCD
sizeX - 230
sizeY - 560
sizeZ - 550
Software - PowerMaster
Special functions -
Transfer time (max) - 4 ms
UPS Architecture - line-interactive
vendpn - VI 2200 RLE
Voltage - 230 V
warrantyLength - 24
warrantyType - G
Weight - 19,00
weight - 19200
Weight & dimensions - Depth - 430 mm
Weight & dimensions - Height - 88 mm
Weight & dimensions - Weight - 16.7 kg
Weight & dimensions - Width - 438 mm
