Accessories included - Software CD Documentation CD Installation Guide Mounting rails for rack mounting Smart-UPS signaling cable USB cable
Active power - 700 W
Alarm - Alarm when on battery : distinctive low battery alarm : configurable delays
Apparent power - 1000 VA
ARTIKEL1 - APC SMART-UPS 1000VA LCD
ARTIKEL2 - RM 2U 230V WITH SMARTCONNECT IN
Backup time (100% load) - 8.7 min
Battery - Automatic battery test - Yes
Battery - Battery life (max) - 6 year(s)
Battery - Battery recharge time - 3 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - Yes
Battery - Number of batteries supported - 1
Battery - Replacement battery cartridge - APCRBC132
Battery recharge time, h - 3
BatteryType -
Maintenance-free sealed Lead-Acid battery with suspended electrolyteleakproof
Brand - APC
BrandPartCode - SMT1000RMI2UC
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Certification - CSA , EAC , EN/IEC 62040-1 , EN/IEC 62040-2 , RCM , UL 1778 , VDE
Charging time - 3 h
Chassis type - Rack
Color - Black
Connections - RJ-45 Serial
Connections - Smart-Slot
Connections - USB
ControlPanel - Multi-function LCD status and control console
Depth - 477 mm
Depth, mm - 457
Description - APC SMART-UPS 1000VA LCD RM 2U 230V WITH SMARTCONNECT
Description - APC Smart-UPS 1000VA LCD RM 2U 230V with SmartConnect
Intelligent and efficient power protection in networks, from the basic level to the possibility of scaling back-up time. The perfect solution for servers, POS terminals, routers, switches, hubs and other network devices.
APC SmartConnect - a function that allows you to view the UPS status via a secure internet portal. Thanks to the innovative remote monitoring interface you will receive automatic notifications, firmware updates and advanced support. The easy-to-use APC SmartConnect network communication provides additional value - and even more important - peace of mind.
Design - Certification - EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH
Design - Display type - LCD
Design - Form factor - Rackmount
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack capacity - 2U
dimension depth - 240 mm
dimension height - 605 mm
Dimensions - 86 x 432 x 477 mm
dimension weight - 31500 g
dimension width - 595 mm
ean - 731304332985
EAN - 0731304332985
EANCode - 0731304332985
Eans - 0731304332985
Environment requirements - Operating temperature 0 - 40 ° C Relative humidity during operation 0 - 95% Height m.p. during operation 0-3000 meters Temperature (storage) -15 - 45 ° C Relative humidity (storage) 0 - 95% Height m.p. (storage) 0-15000 meters The noise is heard at a distance of 1 m from the surface of the device 45.0dBA Heat dissipation in online mode 56.0BTU / hour.
Features - Auto-restart - Yes
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 302 V
Features - Input operation voltage (min) - 151 V
Features - Noise level - 45 dB
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 700 W
Features - Output power capacity - 1 kVA
Features - Output voltage Total Harmonic Distortion (THD) - 5%
Features - Response time - 10 ms
Features - Surge energy rating - 459 J
Features - Surge protection - Yes
Features - Temperature voltage compensation - Yes
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
Features - Web-based management - Yes
FormFactor - Rack
Form factor - Rack
Frequency range, Hz - 47 - 53 Hz for 50 Hz nominal , 57 - 63 Hz for 60 Hz nominal
GrossWeight - 28.000 kg
Gross Weight Kg - 31,45
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304332985
GTIN - 0731304332985
guarantee - 24
guarantee_type - external
Height - 86 mm
Height - 250.000000
Height, mm - 89
HERSTELLER - APC
HSTNUMMER - SMT1000RMI2UC
I/O connectors - 1 x RJ-45 (iLO Remote Management Network)
I/O connectors - 1 x USB (Type B)
Input connection - IEC-320 C14
InputConnections - IEC-320 C14
Input current, A - 0
InputFrequency - 50/60 Hz +/- 3 Hz (auto sensing)
Input frequency, Hz - 50/60 +/- 3
Input power ports - IEC-C14
InputVoltage - 160-286 V
Input voltage, V - 160 - 286
InterfacePorts - RJ-45 Serial, SmartSlot, USB
Length - 600.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 8 pc(s)
LongDesc -
LongProductName - Smart-UPS, Line Interactive, 1000VA, Rackmount 2U, 230V, 4x IEC C13 outlets, SmartConnect Port+SmartSlot, AVR, LCD
LongSummaryDescription - APC SMT1000RMI2UC. UPS topology: Line-Interactive, Output power capacity: 1 kVA, Output power: 700 W. AC outlet types: C13 coupler, AC outlets quantity: 4 AC outlet(s), USB port type: USB Type-A. Battery technology: Sealed Lead Acid (VRLA), Battery life (max): 6 year(s), Battery recharge time: 3 h. Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Width: 432 mm, Depth: 477 mm, Height: 86 mm
Manufacturer - APC
Manufacturer Code - SMT1000RMI2UC
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - SMT1000RMI2UC
MANUFDATASHEET - https://www.apc.com/shop/hr/en/products/APC-Smart-UPS-1000VA-LCD-RM-2U-230V-with-SmartConnect/P-SMT1000RMI2UC?isCurrentSite=true
Maximum power, W - 700
MPN - SMT1000RMI2UC
Name - APC Smart-UPS Rack SMT1000RMI2UC 1000VA 700W 2HE LCD
Name - APC Smart SMT1000RMI2UC
name - Uninterruptible Power Supply SMT1000RMI2UC 1kVA/700W 2U SmartConne
Noise level, dB - 45
Nominal input voltage, V - 230
Nominal output voltage, V - 230
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0 - 95
Operating temperature range (T-T), °C - 0 - 40
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Other features - Confirmation of conformity CSA, EAC, EN / IEC 62040-1, EN / IEC 62040-2, RCM, UL 1778, VDE
OutputConnections - (2) IEC Jumpers (Battery Backup)(4) IEC 320 C13 (Battery Backup)
OutputFrequency - 50/60Hz +/- 3 Hz
Output interface - 2 x IEC Jumpers (Battery Backup)
4 x IEC 320 C13 (Battery Backup)
Output power, W - 700
Output power capacity (VA) - 1000
Output power ports - 4 x IEC-C13
OutputVoltage - 220V, 230V, 240V
PackageContents - CD with softwareDocumentation CDInstallation guideRack Mounting bracketsUSB cable
Packaging data - Cables included - RS-232, USB cable
Packaging data - Quick installation guide - Yes
Packaging data - Rack mount kit - Yes
Packaging data - Resource CD - Yes
Packaging data - Software CD - Yes
PeriodofWarranty - 3 Y
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RJ-45
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port type - USB Type-A
PowerVAW - 1000 VA
PowerW - 700 W
ProdDesc - APC Smart-UPS 1000VA LCD RM 2U 230V with SmartConnect
producer - APC
Producer - APC
ProducerCode - SMT1000RMI2UC
ProductName - SMT1000RMI2UC
ProductPicture - http://www.tdbaltic.ee/images/ds4/SMT1000RMI2UC-01.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
Rack height (units) - 2
RechargeTime - 3 h
RJ45 - Yes
Runtime - 31.3/8.7
ShortDescription -
Short description - APC Smart-UPS 1000 VA LCD RM mit SmartConnect
ShortSummaryDescription - APC SMT1000RMI2UC, Line-Interactive, 1 kVA, 700 W, Sine, 151 V, 302 V
SmartSlot - Yes
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 8
Storage temperature range (T-T), °C - -15 - 45
Storno - Y
Surge energy rating, J - 459
Technical details - Compliance certificates - RoHS
Technical details - Sustainability certificates - Green Premium
Title - APC SMT1000RMI2UC uninterruptible power supply (UPS) Line-Interactive 1 kVA 700 W 4 AC outlet(s)
Topology - Line interactive
UPS Architecture - line-interactive
UPS devices and accessories - Yes
URL - https://www.apc.com/shop/sk/en/products/APC-Smart-UPS-Line-Interactive-1000VA-Rackmount-2U-230V-4x-IEC-C13-outlets-SmartConnect-Port-SmartSlot-AVR-LCD/P-SMT1000RMI2UC
USB - Yes
vendpn - SMT1000RMI2UC
Warranty - 3 years
WarrantyInfo - 3 years
WaveformType - Sine wave
Weight - 22.500 Kg
Weight - 27.1 kg
Weight - 32
Weight - 32.000000
Weight & dimensions - Depth - 477 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Package depth - 603 mm
Weight & dimensions - Package height - 251 mm
Weight & dimensions - Package weight - 31.4 kg
Weight & dimensions - Package width - 594 mm
Weight & dimensions - Weight - 22.5 kg
Weight & dimensions - Width - 432 mm
Weight, kg - 28.18
Width - 432 mm
Width - 600.000000
Width, mm - 432
