Accessories included - Software CD USB cable User manual
Apparent power - 2000 VA
ARTIKEL1 - EASY UPS SRV 2000VA 230V
ARTIKEL2 - WITH EXTERNAL BATTERY PACK IN
Battery - Battery recharge time - 4 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Brand - APC
BrandPartCode - SRV2KIL
Breite - 0.8
Category - Uninterruptible Power Supplies (UPSs)
Charging time - 5.5 h
Chassis type - Tower
Color - Black
Description - APC Easy UPS On-Line SRV 2000 VA 230 V with extended battery pack Automatic internal bypass: purely static bypass switch without contactor bridging for fast and reliable transitions in and out of bypass, suitable for 125% of the rated load. Automatic restart of loads after UPS shutdown: automatically restarts connected equipment when mains power returns. ECO mode: an operating mode that bypasses unused electrical components under good power conditions to achieve high operational efficiency without sacrificing protection Input power factor correction: Minimises installation costs by allowing the use of smaller generators and cabling. Intelligent battery management: maximises battery performance, life and reliability through intelligent, precise charging. Intelligent card slot: customise the UPS's capabilities with management cards. LCD graphic display: text and synoptic diagrams that display operating modes, system parameters and alarms. Serial connectivity: Provides UPS management via a serial port. USB connectivity: Provides UPS management via the USB port (not available on all models).
Design - Certification - CE, IEC 62040-1-1, IEC 62040-1-2
REACH
Design - Display type - LCD
Design - Form factor - Tower
Design - LED indicators - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 330 mm
dimension height - 800 mm
Dimensions - 336 x 335 x 425 mm
dimension weight - 51000 g
dimension width - 560 mm
ean - ABEAN-AU70223
EANCode - 0731304337966
Environment requirements -
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Low battery alarm
Features - Auto-restart - Yes
Features - ECO mode - Yes
Features - Input frequency - 40/70 Hz
Features - Input operation voltage (max) - 280 V
Features - Input operation voltage (min) - 160 V
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 1600 W
Features - Output power capacity - 2 kVA
Features - Output voltage Total Harmonic Distortion (THD) - 3%
Features - Surge energy rating - 600 J
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Gewicht - 100
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0731304337966
GTIN - 731304337966
GTIN - 7330381238802
GTIN - 8592978188351
guarantee - 24
guarantee_type - external
HERSTELLER - APC
Hoehe - 0.75
HSTNUMMER - SRV2KIL
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
Input power ports - IEC-C14
Laenge - 1.2
Logistics data - Harmonized System (HS) code - 85078000
LongDesc - This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 2000VA double-conversion on-line tower UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. The SRV comes with IEC 320 C14 input and 3x IEC 320 C13 outlets. The On-Line UPS has a intelligent card slot for optional Network Management Card (AP9544, SRVSMB001, VGL9601l) that enables network-based UPS monitoring and management. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The Built-in automatic and manual bypass provide seamless power to the load even in the event of an internal detected fault or error in UPS. The UPS and the built-in lead-acid battery has a 2-year warranty. Ideal for small data centers, manufacturing facilities, computer rooms, network storage devices, telecommunication, and healthcare IT.
LongProductName - Easy UPS On-Line, 2000VA/1600W, Tower, 230V, 4x IEC C13 outlets, Intelligent Card Slot, LCD, Extended runtime
LongSummaryDescription - APC Easy UPS On-Line, 2000VA/1600W, Tower, 230V, 4x IEC C13 outlets, Intelligent Card Slot, LCD, Extended runtime. UPS topology: Double-conversion (Online), Output power capacity: 2 kVA, Output power: 1600 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 4 h. Form factor: Tower, Product colour: Black, Display type: LCD. Width: 335 mm, Depth: 425 mm, Height: 336 mm
name - SRV2KIL SRV 2000VA 230V with Ex
No. of batteries - 1
Number of phases input - 1 (230V)
Operational conditions - Non-operating altitude - 0 - 14763.6 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 50 °C
Other features -
Other features - Nominal input voltage - 230 V
Other features - Nominal output voltage - 230 V
Output power ports - 4 x IEC-C13
Packaging data - Cables included - USB cable
Packaging data - Manual - Yes
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RS-232
Ports & interfaces - Serial ports quantity - 1
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
producer - APC
ProductName - Easy UPS On-Line, 2000VA/1600W, Tower, 230V, 4x IEC C13 outlets, Intelligent Card Slot, LCD, Extended runtime
ShortSummaryDescription - APC Easy UPS On-Line, 2000VA/1600W, Tower, 230V, 4x IEC C13 outlets, Intelligent Card Slot, LCD, Extended runtime, Double-conversion (Online), 2 kVA, 1600 W, Sine, 160 V, 280 V
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 1
Storno - N
Technical details - Compliance certificates - RoHS
The shape of the output voltage - Full sine wave
Title - APC Easy UPS On-Line, 2000VA/1600W, Tower, 230V, 4x IEC C13 outlets, Intelligent Card Slot, LCD, Extended runtime
UPS Architecture - on-line double conversion
URL - https://www.apc.com/
vendpn - SRV2KIL
Voltage - 72 V
WarrantyInfo -
Weight - 45.4 kg
Weight & dimensions - Battery depth - 35.5 cm
Weight & dimensions - Battery height - 35.5 cm
Weight & dimensions - Battery weight - 18.1 kg
Weight & dimensions - Battery width - 23.5 cm
Weight & dimensions - Depth - 425 mm
Weight & dimensions - Height - 336 mm
Weight & dimensions - Weight - 45.4 kg
Weight & dimensions - Width - 335 mm
