Accessories included - OLS6000ERTXL3U UPS Rack rails Parallel port cover Terminal connector cover Compression connectors Screw set USB cable
Active power - 5400 W
Apparent power - 6 kVA
Brand - CyberPower
BrandPartCode - OLS6000ERTXL3U
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Certification - CE
Certificates - Compliance certificates - RoHS
Chassis type - Rack
Chassis type - Tower
Color - Black
Description - OLS6000ERTXL3U 6000VA/5400W LCD online UPS. The CyberPower OLS6000ERTXL3U is a highly efficient UPS unit that uses an online double conversion topology to provide uninterrupted pure sine wave voltage to key NAS devices, servers, surveillance/DVR systems, transport and infrastructure solutions and emergency systems. It is typically installed in a technical room, server room or data centre. The unit requires the purchase of an external battery module. The product is equipped with a service bypass switch. When the switch is pressed, energy is safely transferred to the grid. This allows quick repairs to be carried out by service personnel on site without having to shut down connected equipment. UPS (double conversion) online topology Generator compatibility Zero switchover time Extended battery module (EBM) EMI and RFI filtering Emergency stop (EPO) port SNMP / HTTP remote management (optional) ECO mode Overload protection Intelligent battery management (SBM) Interference and surge protection LCD status display PowerPanel management software Adaptation to rack/tower mounting system
Design - Display type - LCD
Design - Form factor - Rackmount/Tower
Design - Housing material - Metal
Design - LED indicators - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 900 mm
dimension height - 270 mm
Dimensions - 438 x 130,5 x 680 mm
dimension weight - 26000 g
dimension width - 550 mm
ean - 4712856270914
Environment requirements - Operating Temperature: 32 ~ 104 (°F) Operating temperature: 0 ~ 40 (°C) Relative operating humidity (non-condensing): 0 ~ 90 (%) Operating altitude: above/equal to 1000, load power reduction 1% per 100 m between 1000 m and 2000 m (feet/meters) Storage Temperature: 5 ~ 113 (°F) Storage temperature: -15 ~ 45 (°C) Relative storage humidity (non-condensing): 0 ~ 95 (%) Storage altitude (feet/meters): 0-50000 feet (0-15000 meters) Online heat dissipation: 1603 (BTU/hr) Audible noise from 1.5 M from the device surface: 60 (dBA)
Features - Crest factor - 3:1
Features - ECO mode - Yes
Features - Efficiency (ECO mode) - 96%
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 276 V
Features - Input operation voltage (min) - 110 V
Features - Input power factor - 0.99
Features - Number of output phases - 1
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 208 V
Features - Output power - 5400 W
Features - Output power capacity - 6 kVA
Features - Output voltage regulation - 0.1%
Features - Power factor - 0.9
Features - Surge energy rating - 445 J
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Pure sine
Filters / protection - Overload
Filters / protection - Suppression
Filters / protection - Surge
guarantee - 24
guarantee_type - external
I/O connectors - 1 x EPO
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
Input power ports - Input terminal
LongDesc - CyberPower OLS6000ERTXL3U is a high-performance UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS and servers, DVRs/surveillance systems, transportation and infrastructure, and emergency systems. It’s typically integrated in the back office, server room, and data center environment. Selected product is equipped with a Maintenance Bypass Switch. By flipping the switch, the power supply is safely transferred to utility. This allows service personnel to carry out fast on-site maintenance without having to shut down any connected equipment.
LongProductName - Single Phase, Online Double Conversion, Online ECO Mode Efficiency > 96%, 110 ~ 276V
LongSummaryDescription - CyberPower OLS6000ERTXL3U. UPS topology: Double-conversion (Online), Output power capacity: 6 kVA, Output power: 5400 W. AC outlets quantity: 1 AC outlet(s), Serial interface type: RS-232. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Compliance certificates: RoHS, Certification: CE. Width: 438 mm, Depth: 680 mm, Height: 130.5 mm
name - UPS online OLS6000ERTXL3U 6000VA/5400W LCD
Number of phases input - 1 (230V)
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 2000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Other features -
Output power ports - Output terminals
Ports & interfaces - AC outlets quantity - 1 AC outlet(s)
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RS-232
Ports & interfaces - USB port - Yes
producer - CyberPower
ProductName - OLS6000ERTXL3U
ShortSummaryDescription - CyberPower OLS6000ERTXL3U, Double-conversion (Online), 6 kVA, 5400 W, Pure sine, 110 V, 276 V
Software - PowerPanel Business
Special functions -
The shape of the output voltage - Full sine wave
Title - CyberPower OLS6000ERTXL3U uninterruptible power supply (UPS) Double-conversion (Online) 6 kVA 5400 W 1 AC outlet(s)
Transfer time (max) - 0 ms
UPS Architecture - on-line double conversion
URL - https://www.cyberpower.com/in/en/product/sku/ols6000ertxl3u#
vendpn - OLS6000ERTXL3U
WarrantyInfo -
Weight - 17.5 kg
Weight & dimensions - Depth - 680 mm
Weight & dimensions - Height - 130.5 mm
Weight & dimensions - Weight - 17.5 kg
Weight & dimensions - Width - 438 mm
