Accessories included - OLS1000ERT2UA UPS Rack rails Rack holders Screw set Power cord USB cable User manual
Active power - 900 W
Apparent power - 1000 VA
Battery - Battery capacity - 9 Ah
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 12 V
Battery - Charging current - 1.5 A
Battery - Hot-swap battery - Yes
Battery - Number of batteries supported - 2
Battery - Replacement battery cartridge - RBP0156
Battery - Typical backup time at full load - 4.6 min
Battery - Typical backup time at half load - 13.9 min
Brand - CyberPower
BrandPartCode - OLS1000ERT2UA
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Certification - CE, EAC, RoHS
Charging time - 4 h
Chassis type - Rack
Chassis type - Tower
Color - Black
Description - UPS OLS1000ERT2UA 8xC13/USB/RS232/Relay/Dry contact emergency power supply Online UPS (double conversion) topology Generator compatibility Zero switching time Extended Battery Module Auto-detection Key/non-key workloads Telephone, fax, modem, DSL, network protection Variable speed fans PowerPanel management software Adaptation to the rack/tower mounting system ECO mode Overload protection Smart Battery Management (SBM) Protection against interference and surges EMI and RFI filtering Color LCD panel Emergency Power Off (EPO) Port SNMP/HTTP remote management (optional)
Design - Cable length - 1.5 m
Design - Display type - LCD
Design - Form factor - Rackmount/Tower
Design - Housing material - Metal
Design - Product colour - Black
Design - Rack capacity - 2U
Designation - CE+WEEE
dimension depth - 600 mm
dimension height - 230 mm
Dimensions - 438 x 88 x 430 mm
dimension weight - 17500 g
dimension width - 540 mm
ean - 4712856273809
Environment requirements - Operating Temperature: 32 ~ 104 (°F) Operating temperature: 0 ~ 40 (°C) Relative operating humidity (non-condensing): 20 ~ 90 (%) Operating altitude: 0-5,000 feet (0-1,500 meters) (feet/meters) Storage Temperature: 4 ~ 122 (°F) Storage temperature: -20 ~ 50 (°C) Relative storage humidity (non-condensing): 10 ~ 90 (%) Storage Altitude (feet/meters): 0-5000 feet (0-1500 meters) Online heat dissipation: 380 (BTU/hr) Variable speed fans: 20 automatic steps Audible noise from 1.5 M from the device surface: 45 (dBA)
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Fault, Low battery alarm, Overload alarm
Features - Crest factor - 3:1
Features - ECO mode - Yes
Features - Efficiency (ECO mode) - 95%
Features - EMI/RFI noise filtering - Yes
Features - Input current Total Harmonic Distortion (THD) - 3%
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 300 V
Features - Input operation voltage (min) - 160 V
Features - Input power factor - 0.99
Features - Maximum current - 4.5 A
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 208 V
Features - Output power - 900 W
Features - Output power capacity - 1 kVA
Features - Power factor - 0.9
Features - Power protection features - Surge protection
Features - Response time - 0 ms
Features - Surge energy rating - 363 J
Features - Surge protection - Yes
Features - Surge protection features - Modem, Network, Telephone
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Pure sine
Filters / protection - Overload
Filters / protection - Suppression
Filters / protection - Surge
GTIN - 4712856273809
GTIN - 4712856273830
guarantee - 24
guarantee_type - external
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
I/O connectors - 2 x RJ-11/RJ-45
Input power ports - IEC-C14
Logistics data - Country of origin - China
Logistics data - Harmonized System (HS) code - 8504408590
LongDesc - CyberPower OLS1000ERT2UA is a high-performance UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS and servers, DVRs/surveillance systems, transportation and infrastructure, and emergency systems. It’s typically integrated in the back office, server room, and data center environment. The UPS features color LCD panel for users to monitor power system and configure settings easily, and relay-type dry contact to perform local management. This model is designed with extended battery module auto-detection, which can automatically detect the quantity of connected Extended Battery Modules (EBM) to estimate UPS's runtime. The variable speed fans provide automatic thermal management based on power load to reduce noise and provide greater comfort for users.
LongProductName - Online, 1000 VA, 900 W, Sine Wave, IEC C13 x 8, 12 V, 9 Ah, 2U
LongSummaryDescription - CyberPower OLS1000ERT2UA. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 900 W. AC outlet types: C13 coupler, AC outlets quantity: 8 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 12 V. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Certification: CE, EAC, RoHS
name - UPS OLS1000ERT2UA 8xC13/USB/RS232/Relay/Dry contact
Number of phases input - 1 (230V)
Operational conditions - Non-operating altitude - 0 - 1500 m
Operational conditions - Operating altitude - 0 - 1500 m
Operational conditions - Operating relative humidity (H-H) - 20 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 50 °C
Other features -
Output power ports - 8 x IEC-C13
Packaging content - Cables included - USB cable
Packaging data - Package depth - 550 mm
Packaging data - Package height - 230 mm
Packaging data - Package weight - 16.2 kg
Packaging data - Package width - 540 mm
Ports & interfaces - AC outlets quantity - 8 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Modem (RJ-11) ports - 1
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
producer - CyberPower
ProductName - OLS1000ERT2UA
ShortSummaryDescription - CyberPower OLS1000ERT2UA, Double-conversion (Online), 1 kVA, 900 W, Pure sine, 160 V, 300 V
Software - PowerPanel Business
Special functions -
The shape of the output voltage - Full sine wave
Title - CyberPower OLS1000ERT2UA uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 900 W 8 AC outlet(s)
Transfer time (max) - 0 ms
UPS Architecture - on-line double conversion
URL - https://www.cyberpower.com/global/en/product/sku/ols1000ert2ua#specification
vendpn - OLS1000ERT2UA
WarrantyInfo -
Weight - 13.5 kg
Weight & dimensions - Depth - 430 mm
Weight & dimensions - Height - 88 mm
Weight & dimensions - Weight - 10.4 kg
Weight & dimensions - Width - 438 mm
