ARTIKEL1 - TX-1902 TFT LCD 18.9IN
ARTIKEL2 - 1280X1024 0.293MM 250CD/M
Brand - AG Neovo
BrandPartCode - TX192011E0100
Category - Computer Monitors
Design - Glass thickness - 3.1 mm
Design - Housing material - Metal
Design - Market positioning - Business
Design - Product colour - Black
Display - Anti-glare screen - Yes
Display - Backlight type - LED
Display - Colour gamut standard - NTSC
Display - Contrast ratio (typical) - 1000:1
Display - Digital horizontal frequency - 31 - 80 kHz
Display - Digital vertical frequency - 50 - 75 Hz
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 48.3 cm (19")
Display - Display diagonal (metric) - 48.2 cm
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1280 x 1024 pixels
Display - Display technology - LCD
Display - Haze rate - 25%
Display - HD type - SXGA
Display - Native aspect ratio - 4:3
Display - NTSC coverage (typical) - 72%
Display - Number of simultaneous touchpoints - 10
Display - Panel type - TN
Display - Pixel pitch - 0.294 x 0.294 mm
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Surface hardness - 7H
Display - Touchscreen - Yes
Display - Touchscreen technology - Projected capacitive system
Display - Touchscreen type - Tabletop
Display - Touch technology - Multi-touch
Display - Viewing angle, horizontal - 170°
Display - Viewing angle, vertical - 160°
EAN - 4710739597271
EANCode - 4710739597271
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Height adjustment - No
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 90°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
GRUPPE1 - Displays
GRUPPE2 - Lcd Touchscreen
GTIN - 4710739597271
HERSTELLER - AG NEOVO TECHNOLOGY
HSTNUMMER - TX-1902
LongDesc - AG Neovo TX-1902 19-inch touch screen monitor provides a smooth and responsive touch experience with 10-point projected capacitive (PCAP) multi-touch screens, including responsiveness to latex gloves. With DisplayPort, HDMI and VGA input connectivity, the TX-1902 supports analogue and digital signals respectively, making them flexible for various applications such as factory automation, information displays, digital signage, and self-service kiosks. The TX-1902 touch monitor is complemented by a metal housing with an edge-to-edge tempered glass design which enhances durability for continuous operation in demanding and high-traffic areas.PREMIUM PCAP MULTI TOUCH SCREENBased on PCAP touch screen technology, the TX-1902 touch screen monitor can register up to 10 simultaneous touch points with fast, accurate, and extremely sensitive touch responses. These seamless touch senses are identical to those used in smartphones and tablets.CROSS-PLATFORM TOUCH CAPABILITYMulti-Touch capability is optimized to work with various operating systems, providing compatibility with Windows, Linux, macOS, and certain Android versions. This enables more choice to the operating system you use.IP65 DUST AND WATER PROTECTIONThe TX-1902 front IP65 touch screen monitor is designed to protect against dust and liquid spills. This makes the TX-1902 a durable touch monitor ideal for the industrial workplace or the demanding, high-use, and high-traffic public locations.CONSISTENT FORM FACTOR DESIGNReplacing AG Neovo touch screens never requires users to change their whole infrastructure. This is because AG Neovo offers a consistent form factor and long product life cycles. Even as technology advances, no change is made to exterior dimensions or design.DURABLE AND SCRATCH RESISTANT TOUCH SCREENFor 24/7 operations in public settings, the TX-1902 uses metal housing and 7H tempered glass displays to offer high durability and scratch resistance levels, all without compromising touch sensitivity.ERGONOMIC MONITORS WITH FLEXIBLE MOUNTINGThe TX-1902 touch monitor offers flexible mounting options, from the adjustable stand that come with the monitor to desk mounts, wall mounts, and all monitor mounts feature VESA mounting patterns. The TX-1902 features adjustable tilt stands. With a tilt capacity ranging from -5 to 90 degrees, users can work in the position most comfortable for them. Tilt stands are beneficial for facilitating public access by non-disabled and disabled users.VERSATILE CONNECTIVITYThe TX-1902 provides new and legacy systems the best of both worlds since it has both analogue (VGA) and digital (DisplayPort and HDMI) video inputs, which provide maximum versatility and facilitate users to connect to a variety of devices.
LongProductName - 19", SXGA 1280 x 1024, TN, LCD, 5 ms, 16.7M, 170°/160°, 250 cd/m², VGA, HDMI, USB, DisplayPort, 427.0 x 374.6 x 214.2 mm
LongSummaryDescription - AG Neovo TX-1902. Display diagonal: 48.3 cm (19"), Display resolution: 1280 x 1024 pixels, HD type: SXGA, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 4:3, Viewing angle, horizontal: 170°, Viewing angle, vertical: 160°. VESA mounting. Product colour: Black
Manufacturer Name - Neovo
Multimedia - Built-in camera - No
Multimedia - Built-in microphone - No
Multimedia - Built-in speaker(s) - No
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Certification - CE, LVD, WEEE, RoHS, REACH, EAC
Other features - Compliance certificates - CE, Low Voltage Directive (LVD), REACH, RoHS, WEEE
Other features - International Protection (IP) code - IP65
Other features - Mobile operating systems supported - Android
Packaging content - Cables included - AC, HDMI, USB, VGA
Packaging content - Stand included - Yes
Packaging data - Package depth - 300 mm
Packaging data - Package height - 460 mm
Packaging data - Package weight - 8.3 kg
Packaging data - Package width - 500 mm
Performance - AMD FreeSync - No
Performance - Linux operating systems supported - Yes
Performance - Mac operating systems supported - Yes
Performance - NVIDIA G-SYNC - No
Performance - Operating hours (hours/days) - 24/7
Performance - Operating system installed - Windows 10
Performance - Windows operating systems supported - Windows 10, Windows 2000, Windows 7, Windows 8, Windows CE, Windows Vista, Windows XP
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - Headphone out - No
Ports & interfaces - Number of upstream ports - 1
Ports & interfaces - USB upstream port type - USB Type-B
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - European Product Registry for Energy Labelling (EPREL) code - 456262
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.8 W
Power - Power consumption (typical) - 12 W
Power - Power supply type - External
ProductName - TX-1902
Short description - Neovo LCD/LED TX-1902 Touch BLACK Glass+++
ShortSummaryDescription - AG Neovo TX-1902, 48.3 cm (19"), 1280 x 1024 pixels, SXGA, LCD, 5 ms, Black
Stck_Kart - 1
Stck_Pal - 9
Storno - Y
Title - AG Neovo TX-1902 computer monitor 48.3 cm (19") 1280 x 1024 pixels SXGA LCD Touchscreen Tabletop Black
URL - https://www.agneovo.com/global/touchscreens/touch-monitors/tx-series/tx-1902
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 48.8 mm
Weight & dimensions - Depth (with stand) - 214.2 mm
Weight & dimensions - Height (without stand) - 355 mm
Weight & dimensions - Height (with stand) - 374.6 mm
Weight & dimensions - Weight (without stand) - 4.5 kg
Weight & dimensions - Weight (with stand) - 6.5 kg
Weight & dimensions - Width (without stand) - 427 mm
Weight & dimensions - Width (with stand) - 427 mm
