ARTIKEL1 - TX-2401 TOUCH SCREEN MONITOR
ARTIKEL2 - 23.8IN 1920X1080 LED-BACKLIT
Brand - AG Neovo
BrandPartCode - TX241011E0100
Breite - 0
Category - Computer Monitors
Design - Detachable stand - Yes
Design - Glass thickness - 3.3 mm
Design - Housing material - Metal
Design - Market positioning - Business
Design - Product colour - Black
Display - Colour gamut standard - NTSC
Display - Contrast ratio (typical) - 3000:1
Display - Digital horizontal frequency - 30 - 84 kHz
Display - Digital vertical frequency - 56 - 76 Hz
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 60.5 cm (23.8")
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - HD type - Full HD
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 72%
Display - Number of simultaneous touchpoints - 10
Display - Panel type - VA
Display - Pixel pitch - 0.274 x 0.274 mm
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Surface hardness - 7H
Display - Touchscreen - Yes
Display - Touchscreen technology - Projected capacitive system
Display - Touchscreen type - Tabletop
Display - Touch technology - Multi-touch
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 4710739597547
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Cable management - Yes
Ergonomics - Height adjustment - No
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 180°
Ergonomics - VESA mounting - Yes
GRUPPE1 - Displays
GRUPPE2 - Led Small Format
GTIN - 4710739597547
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0
HSTNUMMER - TX241011E0100
Laenge - 0
LongDesc - The TX-2401 touch screen monitor adopts PCAP multi-touch technology that is relatively unaffected by contamination, offering 10-point multi-touch capability, giving an accurate and responsive touch experience, even responsiveness to latex gloves. Featuring DisplayPort, HDMI and VGA input connectivity, the TX-2401 touch monitor is built for flexible use such as self-check-in, endless aisle, self-ordering and price checking. The screen is complemented by the IP65 and IK08 rating, metal casing, and an edge-to-edge 7H tempered glass design, enhancing durability for continuous operation in public and high-traffic spaces.10-POINT PCAP TOUCH SCREENThe TX-2401 touch screen adopts PCAP touch technology with a 10-point multi-touch capability that is unaffected by contamination, giving a fast, accurate, and responsive touch experience. These seamless touch senses are identical to those used in smartphones and tablets, even responsive to latex gloves.EASY TO MAINTAIN FOR NON-STOP USEA commercial-grade panel, high-quality components and 7H scratch-resistant tempered glass screen ensure the display can be 24/7 constant used. Additionally, the screen is resistant to chemical disinfectants like alcohol for frequent cleaning.FRONT IP65 DUST AND WATER PROTECTIONThe TX-2401 multi-touch monitor with a front-sided IP65 rating is designed to protect from dust and liquid spills, making it ideal for high-use public locations.HIGH IMPACT-RESISTANT AGAINST VANDALISMThe touch display with an IK08 rating and metal casing prevents damage from impacts or acts of vandalism in high-traffic areas, ensuring a long service life.MULTIPLE LAYOUTS FOR PUBLIC ACCESSThanks to VESA compatibility, the TX-2401 offers flexible mounting options, from desk mount to wall mount or attached to a monitor arm. The included ergonomic stand allows a huge -2 to 180 degrees of tilt adjustment, creating extra ergonomics when using. The display is 178-degrees wide viewing angles to provide consistent colour performance for better viewing.VERSATILE CONNECTIVITYThe TX-2401 provides maximum versatility and facilitates users to connect to their own devices, such as a high-performance PC or a media player, using the DisplayPort, HDMI or VGA inputs.CABLE MANAGEMENTA specially designed monitor stand with integrated cable management keeps cables organized, prevents them from interfering when adjusting the screen up or down, and provides a clutter-free space.SEAMLESS INTEGRATIONTouch support works with various operating systems, compatible with Windows, Linux, macOS, and certain Android versions. This enables more choice of the operating system you use.
LongProductName - 23.8", VA FHD 1920 x 1080, 250 cd/m², 3000:1, 178°/178°, 16.7M, DisplayPort, HDMI, VGA, 17 W
LongSummaryDescription - AG Neovo TX-2401. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - CE, Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE
Other features - International Protection (IP) code - IP65
Packaging content - Cables included - AC, HDMI, USB, VGA
Packaging content - Power adapter included - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 660 mm
Packaging data - Package height - 530 mm
Packaging data - Package type - Box
Packaging data - Package weight - 11.4 kg
Packaging data - Package width - 370 mm
Performance - AMD FreeSync - No
Performance - NVIDIA G-SYNC - No
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.2a
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.3
Ports & interfaces - Headphone connectivity - 3.5 mm
Ports & interfaces - Headphone out - Yes
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - USB Touch port - Yes
Ports & interfaces - USB Touch ports quantity - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - Energy consumption (SDR) per 1000 hours - 17 kWh
Power - Energy efficiency class (SDR) - E
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 1121207
Power - Power consumption (off) - 0.2 W
Power - Power consumption (standby) - 0.4 W
Power - Power consumption (typical) - 17 W
ProductName - TX-2401
ShortSummaryDescription - AG Neovo TX-2401, 60.5 cm (23.8"), 1920 x 1080 pixels, Full HD, LED, 5 ms, Black
Stck_Kart - 1
Stck_Pal - 10
Storno - Y
Title - AG Neovo TX-2401 computer monitor 60.5 cm (23.8") 1920 x 1080 pixels Full HD LED Touchscreen Tabletop Black
URL - https://www.agneovo.com/global/touchscreens/touch-monitors/tx-series/tx-2401
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 42.4 mm
Weight & dimensions - Depth (with stand) - 279.7 mm
Weight & dimensions - Height (without stand) - 347 mm
Weight & dimensions - Height (with stand) - 451.3 mm
Weight & dimensions - Weight (without stand) - 5.7 kg
Weight & dimensions - Weight (with stand) - 7.8 kg
Weight & dimensions - Width (without stand) - 575.1 mm
Weight & dimensions - Width (with stand) - 575.1 mm
