ARTIKEL1 - X-22E 22IN 1920X1080 FHD
ARTIKEL2 - 250CD D-SUB DVI HDMI DP BLACK
Audio - Built-in speaker(s) - Yes
Audio - Number of built-in speakers - 2
Audio - RMS rated power - 4 W
Brand - AG Neovo
BrandPartCode - X22E0011E0100
Category - Computer Monitors
Certificates - Certification - CE, WEEE, REACH, GOST-R
Design - Housing material - Metal
Design - Market positioning - Industrial
Design - Panel mounting interface - 75 x 75
Design - Panel mounting interface - 100 x 100 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - VESA mounting - Yes
dimensionalWeight - 11949
Display - Backlight type - LED
Display - Colour gamut standard - NTSC
Display - Contrast ratio (dynamic) - 2000000:1
Display - Contrast ratio (typical) - 1000:1
Display - Digital horizontal frequency - 24 - 83 kHz
Display - Digital vertical frequency - 50 - 75 Hz
Display - Display brightness - 250 cd/m²
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 54.6 cm (21.5")
Display - Display number of colours - 16.78 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - HD type - Full HD
Display - Horizontal scan range - 24 - 82 kHz
Display - Maximum refresh rate - 75 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 72%
Display - Panel type - TN
Display - Pixel pitch - 0.2482 x 0.2482 mm
Display - Response time - 3 ms
Display - Screen shape - Flat
Display - Supported graphics resolutions - 1920 x 1080 (HD 1080)
Display - Supported video modes - 1080p
Display - Surface hardness - 9H
Display - Touchscreen - No
Display - Vertical scan range - 50 - 75 Hz
Display - Viewing angle, horizontal - 170°
Display - Viewing angle, vertical - 160°
EAN - 4710739593747
EANCode - 4710739593747
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Height adjustment - No
Ergonomics - Panel mounting interface - 75 x 75,100 x 100 mm
Ergonomics - Picture-in-Picture - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - 0 - 15°
Ergonomics - VESA mounting - Yes
Gewicht - 8.87
Gross Weight Kg - 9,5
GRUPPE1 - Displays
GRUPPE2 - Lcd Monitor
GTIN - 0190695000345
GTIN - 190695000345
GTIN - 4710739593747
HERSTELLER - AG NEOVO TECHNOLOGY
HSTNUMMER - X22EB011E0100
Logistics data - Harmonized System (HS) code - 85285210
LongDesc - The X-22E semi-industrial monitor with the metal casing is designed for reliable 24/7 operation in demanding environments. With selectable gamma curves and versatile connectivity, this monitor provides an optimal visual experience with excellent colour, brightness, and contrast ratio. NeoV Optical Glass screen and corrosion-resistant metal casing shield it from scratches and chemical exposure which make it ideal for public, laboratory, and light industrial applications.The NeoV Optical Glass attached to the X-22E screen is scratch-resistant with anti-acid and anti-alkali coating treatment and tough enough to withstand repeated cleaning.DURABLE IN LIGHT INDUSTRIAL ENVIRONMENTIts corrosion-resistant metal casing provides enhanced heat dissipation, making the X-22E semi-industrial monitor durable for demanding environments.VERSATILITY, PRODUCTIVITY AND COMPATIBILITYThe X-22E allows viewing critical data and engaging multiple video sources with versatile connectivity, including DisplayPort, HDMI, DVI, and VGA. The PIP/PBP option allows for increased productivity and efficiency. Selectable aspect ratio and zoom functions provide compatibility with different video sources.PATENTED ANTI-BURN-IN TECHNOLOGYAG Neovo’s patented Anti-Burn-in technology tackles the LCD monitor burn-in effect, otherwise known as a ghost image on the screen. Burn-in images result in the polarisation of the liquid crystal material contained within the TFT LCD panel. The Anti-Burn-in technology prolongs the lifetime of AG Neovo monitors featuring this technology to secure user’s investment.CONSISTENT DESIGN WITH A LONGER LIFETIMEReplacing AG Neovo semi-industrial monitors never requires users to change their whole infrastructure. This is because AG Neovo offers a consistent form factor and long product life cycles. Even as technology advances, no change is made to exterior dimensions or design.ENHANCED GAMMA CORRECTIONSelectable gamma curves visually optimise different kinds of images. The AG Neovo specialised image settings enhance colour, brightness, sharpness and contrast ratio, allowing the X-22E semi-industrial monitor with a metal casing to improve the light, shadows and colour balance of videos.
LongProductName - 21.5”, LED-backlit TN LCD, 1920 x 1080, 250 cd/m2, 2000000 : 1, 3 ms, NeoV Optical Glass, 18 W, Black
LongSummaryDescription - AG Neovo X-22E. Display diagonal: 54.6 cm (21.5"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 3 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 170°, Viewing angle, vertical: 160°. Built-in speaker(s). VESA mounting. Product colour: Black
Manufacturer Code - X22E0011E0100
Manufacturer Name - Neovo
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 4 W
Network - Ethernet LAN - No
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - AC adapter included - Yes
Other features - Compliance certificates - RoHS
Other features - Manual - Yes
Packaging content - Cables included - AC
Packaging content - Cables included - AC, Audio (3.5mm), VGA
Packaging content - Cables included - Audio (3.5mm)
Packaging content - Cables included - VGA
Packaging content - Quick start guide - Yes
Packaging content - Stand included - Yes
Packaging data - Package depth - 204 mm
Packaging data - Package depth - 212 mm
Packaging data - Package height - 476 mm
Packaging data - Package height - 477 mm
Packaging data - Package type - Box
Packaging data - Package weight - 9.5 kg
Packaging data - Package width - 602 mm
Packaging data - Package width - 614 mm
Performance - AMD FreeSync - No
Performance - NVIDIA G-SYNC - No
Performance - TV tuner integrated - No
Ports & interfaces - Audio input - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.2a
Ports & interfaces - DVI-D ports quantity - 1
Ports & interfaces - DVI port - Yes
Ports & interfaces - Ethernet LAN - No
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - PC Audio in - Yes
Ports & interfaces - USB port - No
Ports & interfaces - VGA (D-Sub) input ports - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - Energy consumption (SDR) per 1000 hours - 15 kWh
Power - Energy efficiency class (SDR) - E
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 444584
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.3 W
Power - Power consumption (typical) - 18 W
producerCode - X-22E
productName - AG Neovo X-22E Digital signage flat panel 54.6 cm (21.5") LED Full HD Black
ProductName - X-22E
productSize - Normal
Short description - Neovo LCD/LED X-22E BLACK Glass (24-7)
ShortSummaryDescription - AG Neovo X-22E, 54.6 cm (21.5"), 1920 x 1080 pixels, Full HD, LED, 3 ms, Black
sizeX - 614
sizeY - 477
sizeZ - 204
Stck_Kart - 1
Stck_Pal - 24
Storno - Y
Technical details - Sustainability certificates - RoHS
Title - AG Neovo X-22E computer monitor 54.6 cm (21.5") 1920 x 1080 pixels Full HD LED Black
URL - https://www.agneovo.com/global/monitors/industrial/x-series/x-22e
WarrantyInfo -
warrantyLength - 24
warrantyType - G
weight - 9500
Weight & dimensions - Depth - 155 mm
Weight & dimensions - Depth (without stand) - 56.2 mm
Weight & dimensions - Depth (with stand) - 155 mm
Weight & dimensions - Height - 369 mm
Weight & dimensions - Height (without stand) - 324.3 mm
Weight & dimensions - Height (with stand) - 368.5 mm
Weight & dimensions - Weight - 6.3 kg
Weight & dimensions - Weight (without stand) - 6.1 kg
Weight & dimensions - Weight (with stand) - 6.7 kg
Weight & dimensions - Width - 513 mm
Weight & dimensions - Width (without stand) - 513.2 mm
Weight & dimensions - Width (with stand) - 513.2 mm
