ARTIKEL1 - TX-1502 LED-BACKLIT TFT LCD
ARTIKEL2 - 15IN 1024X768 250CD 700:01:00
Brand - AG Neovo
BrandPartCode - TX152011E0100
Category - Computer Monitors
Design - Detachable stand - Yes
Design - Glass thickness - 3.1 mm
Design - Housing material - Metal
Design - Market positioning - Business
Design - Product colour - Grey
Display - Anti-glare screen - Yes
Display - Backlight type - LED
Display - Colour gamut standard - NTSC
Display - Contrast ratio (typical) - 800:1
Display - Display brightness (typical) - 350 cd/m²
Display - Display diagonal - 38.1 cm (15")
Display - Display diagonal (metric) - 38.1 cm
Display - Display number of colours - 16.78 million colours
Display - Display resolution - 1024 x 768 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - XGA
Display - Horizontal scan range - 31 - 61 kHz
Display - Native aspect ratio - 4:3
Display - NTSC coverage (typical) - 60%
Display - Number of simultaneous touchpoints - 10
Display - Panel type - VA
Display - Pixel pitch - 0.297 x 0.297 mm
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Surface hardness - 7H
Display - Touchscreen - Yes
Display - Touchscreen technology - Projected capacitive system
Display - Touchscreen type - Tabletop
Display - Touch technology - Multi-touch
Display - Vertical scan range - 55 - 75 Hz
Display - Viewing angle, horizontal - 160°
Display - Viewing angle, vertical - 150°
EANCode - 4710739597257
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Height adjustment - No
Ergonomics - LED indicators - Yes
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 90°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
GRUPPE1 - Displays
GRUPPE2 - Lcd Touchscreen
GTIN - 4710739597257
HERSTELLER - AG NEOVO TECHNOLOGY
HSTNUMMER - TX152011E0100
Logistics data - Harmonized System (HS) code - 85285210
LongDesc - AG Neovo TX-Series touch screen monitors, available in sizes 15” to 22”, provide a smooth and responsive touch experience with 10-point PCAP touch screens, including responsiveness to latex gloves. With DisplayPort, HDMI and VGA input connectivity, the TX-Series support analogue and digital signals respectively, making them flexible for various applications such as factory automation, information displays, digital signage, and self-service kiosks. These touch screen monitors are complemented by a metal housing with an edge-to-edge tempered glass design which enhances durability for continuous operation in demanding and high-traffic areas.Premium PCAP Multi Touch ScreenBased on projected capacitive (PCAP) touch screen technology, AG Neovo touch screen monitors can register up to 10 simultaneous touch points with fast, accurate, and extremely sensitive touch response. These seamless touch senses are identical to those used in smartphones and tablets.Cross-Platform Touch CapabilityMulti-Touch capability is optimized to work with various operating systems, providing compatibility with Windows, Linux, macOS, and certain Android versions. This enables more choice to the operating system you use.IP65 Dust and Water ProtectionThe TX-Series front IP65 touch screen monitors are designed to protect against dust and liquid spills. This makes these durable touch monitors ideal for the industrial workplace or the demanding, high-use, and high-traffic public locations. Consistent Form Factor DesignReplacing AG Neovo touch screens never requires users to change their whole infrastructure. This is because AG Neovo offers a consistent form factor and long product life cycles. Even as technology advances, no change is made to exterior dimensions or design.Durable and Scratch Resistant Touch ScreenFor 24/7 operations in public settings, AG Neovo uses metal housing and 7H tempered glass displays to offer high durability and scratch resistance levels, all without compromising touch sensitivity.Ergonomic Monitors with Flexible MountingTX-Series touch monitors offer flexible mounting options, from the ergonomic monitor stands that come with the monitors to desk mounts, wall mounts, and all monitor mounts feature VESA mounting patterns. These ergonomic monitors feature adjustable tilt stands. With a tilt capacity ranging from -5 to 90 degrees, users can work in the position most comfortable for them. Tilt stands are beneficial for facilitating public access by non-disabled and disabled users.Versatile ConnectivityThe TX-Series provides new and legacy systems the best of both worlds since it has both analog (VGA) and digital (DisplayPort and HDMI) video inputs, which provide maximum versatility and facilitate users to connect to a variety of devices.
LongProductName - 15" LED-Backlit TFT LCD (TN) Touch Screen, 1024 x 768, 350 cd/m², 800:1, 5 ms, DisplayPort, HDMI, VGA, RJ-11, 24/7, IP65
LongSummaryDescription - AG Neovo TX-1502. Display diagonal: 38.1 cm (15"), Display resolution: 1024 x 768 pixels, HD type: XGA, Display technology: LED, Response time: 5 ms, Native aspect ratio: 4:3, Viewing angle, horizontal: 160°, Viewing angle, vertical: 150°. VESA mounting. Product colour: Grey
Multimedia - Built-in camera - No
Multimedia - Built-in microphone - No
Multimedia - Built-in speaker(s) - No
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Certification - CE, LVD, WEEE, RoHS, REACH,EAC
Other features - Compliance certificates - CE, REACH, RoHS, WEEE
Other features - International Protection (IP) code - IP65
Other features - Mobile operating systems supported - Android
Packaging content - Cables included - AC, HDMI, USB, VGA
Packaging content - Stand included - Yes
Packaging data - Package depth - 290 mm
Packaging data - Package height - 370 mm
Packaging data - Package weight - 7 kg
Packaging data - Package width - 415 mm
Performance - AMD FreeSync - No
Performance - Linux operating systems supported - Yes
Performance - Mac operating systems supported - Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Performance - NVIDIA G-SYNC - No
Performance - Operating hours (hours/days) - 24/7
Performance - Operating system installed - Windows 10
Performance - Windows operating systems supported - Windows 10, Windows 7, Windows 8
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - USB Touch port - Yes
Ports & interfaces - USB Touch ports quantity - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC adapter output voltage - 12 V
Power - European Product Registry for Energy Labelling (EPREL) code - 456259
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.6 W
Power - Power consumption (typical) - 8 W
Power - Power supply type - External
ProductName - TX-1502
ShortSummaryDescription - AG Neovo TX-1502, 38.1 cm (15"), 1024 x 768 pixels, XGA, LED, 5 ms, Grey
Stck_Kart - 1
Stck_Pal - 15
Storno - Y
Sustainability - Sustainability compliance - Yes
Title - AG Neovo TX-1502 computer monitor 38.1 cm (15") 1024 x 768 pixels XGA LED Touchscreen Tabletop Grey
URL - https://displays.agneovo.com/gl/products/tx-series-advanced/17517-tx-1502
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 46.6 mm
Weight & dimensions - Depth (with stand) - 214.2 mm
Weight & dimensions - Height (without stand) - 276.4 mm
Weight & dimensions - Height (with stand) - 312.7 mm
Weight & dimensions - Weight (without stand) - 2.7 kg
Weight & dimensions - Weight (with stand) - 4.6 kg
Weight & dimensions - Width (without stand) - 348.4 mm
Weight & dimensions - Width (with stand) - 348.4 mm
