Aerocool VX PLUS 700, 700W

Accessories included -
Brand - Aerocool
BrandPartCode - AEROPGSVX-700PLUS-80
Category - Power Supply Units
Category - Root/Electronics/PC parts/PC power supply units
Certificates - Certification - CE, FCC, EAC
Certificates 80+ - None
Description - Zasilacz VX PLUS 700W ATX Koncentrując się na dostarczaniu zasilacza o najlepszej wartości, VX PLUS umożliwia łatwą instalację, zapewniając jednocześnie niezawodną jakość i doskonałą wydajność, co czyni go idealnym zasilaczem dla początkujących konstruktorów systemów. Jest wyposażony w ulepszony transformator i 12-centymetrowy wentylator ze zoptymalizowaną termiczną kontrolą prędkości. Najlepszy zasilacz dla początkujących konstruktorów systemów Kompatybilny z ATX 12V 2.3 Zmodernizowany transformator pozwala na obsługę ciężkich systemów ładowania 12V Potężna pojedyncza linia +12V oferuje kompatybilne wyjście DC Cichy wentylator 12 cm ze zoptymalizowaną termiczną kontrolą prędkości wentylatora Zabezpieczenie elektryczne OPP/OVP/UVP/SCP/SIP w zestawie
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 940
dimension depth - 100 mm
dimension height - 200 mm
Dimensions - 86 x 140 x 150 mm
dimension weight - 1512 g
dimension width - 240 mm
ean - 4713105962796
Eans - 4713105962796
Fan - 12 cm
GTIN - 4713105962796
guarantee - 24
guarantee_type - normal
LongDesc - Focused on delivering the best value power supply unit, the VX PLUS allows for easy installation while delivering reliable quality and excellent performance, making this the perfect PSU for entry-level system builders. Comes equipped with an upgraded transformer and a 12cm fan with optimized thermal fan speed control. UNBEATABLE VALUEVX PLUS offers the best value you could ask for in a power supply with easy installation and top-notch performance, making this the perfect starting PSU for entry-level system builders.IMPROVED DESIGNEquipped with a unique, top cover design, the VX PLUS looks better than ever and enhances the entire look and feel of any proper gaming setup.UPGRADED TRANSFORMERUpgraded transformer improves balance between 12V, 3.3V, and 5V voltage regulations and enhances the stability, allowing for heavy 12V loading system support.OPTIMIZED FAN RPMSilent 12cm fan with optimized smart fan speed control. Fan runs in startup speed before reaching 50% load at 25℃ ambient temperatures.
LongProductName - 700 W, 12 cm, ATX 12V 2.3, APFC
LongSummaryDescription - Aerocool VX PLUS 700. Total power: 700 W, AC input voltage: 230 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 50 cm, Peripheral (Molex) power cable length: 600,750 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX. Product colour: Black, Fan diameter: 12 cm, Number of fans: 1 fan(s). Certification: CE, FCC, EAC
MB power connector - 20 + 4 pin
Modular power supply - No
MOLEX power connectors - 3
Name - AEROCOOL PGS VX-700plus 700W 80+ BOX PSU
name - Power supply VX PLUS 700W ATX
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connectors PCI-E 6 +2 pin - 2
Other features -
Performance - ATX version - 2.3
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - Supported motherboard form factors - ATX
PFC - Active
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 55 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 50 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - PCI Express power cable length - 55 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 1
Ports & interfaces - Peripheral (Molex) power cable length - 600,750 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 3
Power - AC input frequency - 47 - 63 Hz
Power - AC input voltage - 230 V
Power - Combined power (+3.3V) - 130 W
Power - Combined power (+5V) - 130 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 648 W
Power - Combined power (-12V) - 3.6 W
Power - Input current - 4.5 A
Power - Input current - 5 A
Power - Max output current (+3.3V) - 22 A
Power - Max output current (+5V) - 18 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 54 A
Power - Max output current (-12V) - 0.3 A
Power - Power factor - 0.9
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over power
Power - Power protection features - Over power, Over voltage, Short circuit, Under voltage
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 700 W
Power supply - 700 W
producer - AeroCool
Producer - AeroCool
producerCode - AEROPGSVX-700PLUS-80
ProducerCode - AEROPGSVX-700PLUS-80
productName - POWER SUPPLY AEROCOOL PGS VX-700PLUS 700W 80+ BOX
ProductName - VX PLUS 700
productSize - Normal
SATA power connectors - 6
ShortDescription - 700 | ATX | 120mm | 24 pin | 140mm x 150mm x 86mm |
ShortSummaryDescription - Aerocool VX PLUS 700, 700 W, 230 V, 47 - 63 Hz, 4.5 A, Active, 130 W
sizeX - 200
sizeY - 235
sizeZ - 100
Title - Aerocool VX PLUS 700 power supply unit 700 W 20+4 pin ATX ATX Black
URL - https://aerocool.io/product/vx-plus-800/
vendpn - AEROPGSVX-700PLUS-80
WarrantyInfo -
warrantyLength - 24
warrantyType - G
weight - 1505
