MSI MAG A750BN PCIE5, 750W, 80PLUS Bronze

8-pin 12V power connectors - 0
Accessories included -
Brand - MSI
BrandPartCode - 306-7ZP2C11-CE0
Category - Datortehnika :: Datoru komponentes :: Barošanas bloki (PSU)
category - PC Components|Power Supplies|80 Plus Bronze
Category - Power Supply Units
Category - Root/Electronics/PC parts/PC power supply units
Category Code - PSU
Certificates 80+ - 80 PLUS Bronze
code - 306-7ZP2C11-CE0
Code - MAG A750BN PCIE5
Colour - Black
Cooling System - 12cm fan
Desc - Jauda: 750W, Energoefektivitāte: 80 Plus Bronze, PFC: Aktīvs, Ventilators: 120mm, SATA pieslēgumi: 5, MOLEX PATA pieslēgumi: 2, PCI-E: 2 x 6 + 2 PIN, Garantija: 2 gadi
Description - Charakterystyczne wzory konstrukcyjne MAG A750BN PCIE5 symbolizują jedność i siłę. Jednoczy wszystkie komponenty, niezawodnie i stabilnie dostarczając energię do całego systemu. Dzięki MAG A750BN PCIE5 każdy system ma moc potrzebną do przetrwania wszystkich wyzwań.
Gotowy na PCIE5.0
Posiada port wyjściowy zgodny ze standardem PCIe 5.0, umożliwiający obsługę kart graficznych z serii RTX 4070.
Certyfikat 80 Plus Bronze
Wydajność zasilacza ma bezpośredni wpływ na wydajność systemu i zużycie energii. Certyfikat 80 PLUS gwarantuje niższe zużycie energii i kwalifikowany poziom wydajności.
Adaptacja temperatury
Zaprojektowany z myślą o niezawodności, system działa bezpiecznie z maksymalną wydajnością nawet w warunkach wysokiej temperatury. Ten wytrzymały zasilacz zapewnia ciągłą pracę niezależnie od otoczenia.
Wentylator 120 mm o niskim poziomie hałasu
Wentylator 120 mm redukuje generowany hałas, zachowując jednocześnie doskonałe odprowadzanie ciepła.
Description - The MAG series fights alongside gamers in pursuit of honor. With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability. The MAG A750BN PCIE5's distinctive design patterns symbolize unity and strength. It unites all the components by reliably and stably supplying power to the entire system. With the MAG A750BN PCIE5's , any system has the power it needs to survive all challenges.
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Illumination - No
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
dimensionalWeight - 1638
dimension depth - 130 mm
dimension height - 300 mm
Dimensions -
Dimensions - 140mm x 150mm x 86mm
dimension weight - 2427 g
dimension width - 220 mm
EAN - 4711377126595
ean - 4711377126595
Eans - 4711377126595
Efficiency - 80 PLUS BRONZE
Fan - 12 cm
Floppy power connectors - 0
Full Description Line - MAG A750BN PCIE5|For gaming|750 Watts|Cooling System 12cm fan|80 PLUS BRONZE|PFC Active|Colour Black
GTIN - 4711377126595
GTIN - 4711377126601
guarantee - 84
guarantee_type - normal
ImageUrl - https://www.balticdata.lv/Gfx/ProductImages/Info/Product_114750_1.png
LargeDescHTML -
LongDesc - The MAG series fights alongside gamers in pursuit of honor. With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.The MAG A750BN PCIE5's distinctive design patterns symbolize unity and strength. It unites all the components by reliably and stably supplying power to the entire system. With the MAG A750BN PCIE5's , any system has the power it needs to survive all challenges.PCIE5.0 READYIt has an output port that is compliant with PCIe 5.0, enabling to support the RTX 4070* series graphics cards.80 PLUS BRONZE CERTIFICATIONThe efficiency of your power supply directly influences your system’s performance and power consumption. The 80 PLUS certification promises lower energy consumption and qualified efficiency level.PROTECTION DEISGNProtection is designed to protect the unit mechanisms and provides comprehensive protection.TEMPERATURE ADAPTATIONEngineered for reliability, your system operates safely at peak performance even in high-temperature conditions. This rugged power supply ensures sustained operation regardless of your environment.120MM LOW NOISE FANThe 120mm fan reduces the noise generated while maintaining excellent heat dissipation.
LongProductName - 750W, 120 mm, 100-240 V, 50-60Hz, 140 x 150 x 86 mm
LongSummaryDescription - MSI MAG A750BN PCIE5. Total power: 750 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Package width: 150 mm, Package depth: 140 mm, Package height: 86 mm
MB power connector - 24 pin
Model name - MAG A750BN PCIE5
Modular power supply - Yes
MOLEX power connectors - 2
Name - Barošanas bloks MSI MAG A750BN PCIE5
name - MAG A750BN PCIE5 750W 80PLUS BRONZE F.MODULAR
Name - MSI MAG A750BN PCIE5
name - MSI MAG A750BN PCIe5 Netzteil, 80 PLUS Bronze, ATX 2.4, PCIe 5.0 - 750 Watt
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 0
Number of power connectors PCI-E 16-pin Gen 5 - 1
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 2
Other features -
Packaging data - Package depth - 140 mm
Packaging data - Package height - 86 mm
Packaging data - Package width - 150 mm
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Active
Ports & interfaces - ATX Power connector (24-pin) - Yes
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - EPS power connector (4+4 pin) - Yes
Ports & interfaces - Floppy drive power connector - 1
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of SATA power connectors - 5
Ports & interfaces - PCI Express power connectors (6+2 pin) - 2
Ports & interfaces - PCI Express power connectors (16-pin) - 1
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 2
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 120 W
Power - Combined power (+5V) - 120 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 750 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 85%
Power - Maximum input current (@110V) - 10 A
Power - Maximum input current (@220V) - 5 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 62.5 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current
Power - Power protection features - Over current, Over power, Over voltage, Short circuit
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Total power - 750 W
Power supply - 750 W
producer - MSI
Producer - MSI
producerCode - 306-7ZP2C11-CE0
ProducerCode - 306-7ZP2C11-CE0
ProductName - MAG A750BN PCIE5
productName - MSI MAG A750BN PCIE5 power supply unit 750 W 24-pin ATX ATX Black
productSize - Normal
PSU features - For gaming
PSU Output Power - 750 Watts
SATA power connectors - 5
Shipping Box Depth Shipping/Package Box Dimensions - 60 cm
Shipping Box Height Shipping/Package Box Dimensions - 23 cm
Shipping box quantity - 6
Shipping Box Weight Shipping/Package Box Dimensions - 14.68 kg
Shipping Box Width Shipping/Package Box Dimensions - 41 cm
ShortDescription - 750 | ATX | 120 mm | 20 + 4 pin |290mm x 206mm x 126mm | 80PLUS Bronze |
ShortSummaryDescription - MSI MAG A750BN PCIE5, 750 W, 100 - 240 V, 50/60 Hz, 10 A, 5 A, Active
sizeX - 210
sizeY - 130
sizeZ - 300
Title - MSI MAG A750BN PCIE5 power supply unit 750 W 24-pin ATX ATX Black
Unit Box Height - 0.21
Unit Box Length - 0.29
Unit Box Width - 0.125
Unit Brutto Volume - 0.00943 cubm
Unit Gross Weight - 2.45 kg
Unit Net Weight - 2 kg
URL - https://www.msi.com/Power-Supply/MAG-A750BN-PCIE5/Overview
Vendor Homepage - www.msi.com/Power-Supply/MAG-A750BN-PCIE5
vendpn - MAG A750BN PCIE5
Warranty - 24 months
WarrantyInfo -
warrantyLength - 60
warrantyType - G
weight - 2400
