8-pin 12V power connectors - 0
Accessories included -
Category - Root/Electronics/PC parts/PC power supply units
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates 80+ - 80 PLUS Gold
Description - The Toughpower GF A3 850W Gold F Modular 12cm Gen5 Snow power supply is characterized by solid workmanship and impressive power of up to 850 W. Thanks to this, it will easily power even the most demanding computer configurations, ensuring stable and reliable operation. Equipped with an active power factor correction (PFC) system, which translates into efficiency and energy savings. An additional advantage is the 80 PLUS Gold certificate, confirming the high efficiency of the power supply and low energy consumption. The modular design of the power supply allows you to optimize energy conduction in the computer case, eliminating unnecessary cables and improving air flow. Thanks to this, the entire structure becomes more transparent and aesthetic. The Toughpower GF A3 850W Gold F Modular 12cm Gen5 Snow power supply also has a rich set of connectors, including: power connectors SATA, PCI-E 6-pin, PCI-E 6+2-pin and PCI-E 8-pin. This makes it easy to connect various devices and graphics cards without worrying about the lack of appropriate connectors. A 12-cm fan that effectively dissipates heat outside, ensuring proper cooling of computer components. Thanks to this, the power supply operates more quietly and efficiently, which is important especially during long-term use.
Designation - CE+WEEE
dimension depth - 135 mm
dimension height - 225 mm
Dimensions - 150 x 86 x 140 mm
dimension weight - 2880 g
dimension width - 325 mm
ean - 4711475640092
Eans - 4711475640092
EAN_code - 4711475640092
Fan - 12 cm
Floppy power connectors - 1
guarantee - 60
guarantee_type - statutory
Manufacturer - Thermaltake
Manufacturer_code - PS-TPD-0850FNFAGE-N
MB power connector - 24 pin
Modular power supply - Yes
MOLEX power connectors - 8
name - Thermaltake Toughpower GF A3 850W Gold Snow
Name - Thermaltake Toughpower GF A3 850W White
Name - Thermaltake Toughpower GF A3 Snow 850W, PC power supply (white, 1x 12VHPWR, 5x PCIe, cable management, 850 watts)
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 0
Number of power connectors PCI-E 16-pin Gen 5 - 1
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 4
Other features -
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
PFC - Active
Power supply - 850 W
producer - Thermaltake
Producer - Thermaltake
ProducerCode - PS-TPD-0850FNFAGE-N
SATA power connectors - 5
ShortDescription - 850 | ATX | 120mm | 20+4 | 86mm x 150mm x 140mm | modularny | 80+ Gold EU | PCIe Gen 5.0 | biały
Technical_details - The Thermaltake Toughpower GF A3 Series is 80 PLUS Gold certified and compatible with Intel's ATX 3.0 specifications. It is equipped with a native PCIe Gen 5.0 connector and can power next-generation technology with a new 12VHPWR cable. The wattage shown on the 12VHPWR connector is the recommended wattage (Ref. Intel Design Guideline). The GF A3 850W's native 16 PIN (12VHPWR) PCIe connector can deliver up to 600W for PCIe 5.0 graphics cards. The 120mm liquid bearing fan provides excellent airflow. Additionally, the Smart Zero Fan only rotates when the load exceeds 40% of the power supply, minimizing unwanted noise. Item No.: 100000161 Type PC power supply color white EAN 4711475640092 Manufacturer no. PS-TPD-0850FNFAGE-N Total power 850 W Control Temperature controlled Standard ATX12V 3.0 ATX design Certification 80 PLUS Gold Current strengths +3.3 V 22 A Power factor correction Active PFC Connectors 1x 24-pin ATX12V-2.x, 1x 4+4-pin 12V, 4x 4-pin 5.25", 4x 6+2-pin graphics, 1x 8-pin 12V, 1x 12VHPWR, 12x 15-pin SATA Cable lengths mainboard main connection 24-pin: 60 cm, mainboard additional connections 8-pin: 2x 65 cm, drive connections 5.25 inch: 1x 50 cm, 1x 65 cm, 1x 80 cm, 1x 95 cm, drive connections 3.5 inch Floppy: 10 cm, drive connectors SATA: 3x 50 cm, 3x 65 cm, 3x 80 cm, 3x 95 cm, graphics connectors 6-/8-pin: 2x 50 cm, 2x 65 cm, graphics connectors 12VHPWR: 50 cm Cooling Number of fans 1x 140 mm fan Volume 0 dB(A) at 20% load, 8.7 dB(A) at 50% load, 23.4 dB(A) at 100% load Protection functions Current surge protection (OCP), Over voltage protection (OVP), Under voltage protection (UVP), Overload protection (OLP/OPP), Short circuit protection (SCP), Overheating protection (OTP) Accessories available: 1x floppy adapter Dimensions Width: 150mm x Height: 86mm x Depth/Length: 160mm
vendpn - PS-TPD-0850FNFAGE-N
Weight - 2,92
