1 WAN Fixed ports - Yes
10/100/1000M LAN Ports - 3
Antenna - Antenna design - External
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 4
Antenna - Antenna type - External
Antenna - Detachable antenna(s) - No
Antenna > Antennas quantity - 4
Antenna > Antenna type - 4xFixed
Antenna Gain - 5 dB
Antenna Type - Omni-Directional
Available bandwidth - 1800 Mbps
Brand - TP-Link
BrandPartCode - MR70X
Category - Root/Electronics/Networks and communication/Routers
Category - Tīkla produkti, Gudrā māja :: Maršrutētāji / Rūteri
Category - Wireless Routers
Category Code - WRO
Code - MR70X
Data transmission speed - 1200 Mbps
Desc - Portu ātrums: 10/100/1000 Mb/s, Tips: LAN/Wifi, WiFi protokoli: IEEE 802.11a/b/g/n/ac/ax, WiFi ātrums: 1800 Mb/s, WiFi frekvenču josla: 2.4 GHz / 5 GHz (Divu joslu), LAN portu skaits: 3, Ugunsmūris | Firewall: Ir, Garantija: 2 gadi
Description - MERCUSYS MR70X AX1800 Dual-Band WiFi 6 Router Next-Gen WiFi 6 Speeds Optimal WiFi 6 speeds reaching up to 1.8 Gbps (1201 Mbps on the 5 GHz band and 574 Mbps on the 2.4 GHz band) 4× More Capacity OFDMA and MU-MIMO allow simultaneous data transmission to and from several devices, improving overall network efficiency Broader, Stronger Coverage 4× multi-directional high-gain antennas with Beamforming boost stable connections throughout your home for strong WiFi signals in every corner Overall Security Protection The latest WPA3 provides improved WiFi security Gigabit Wired Connections Make full use of your internet access and transfer data at dizzying speeds for peak performance Eco-Friendly Power Saving Target Wake Time (TWT) reduces power consumption for your mobile and IoT devices during data transmissions Less WiFi Interference Minimizes the interference from neighboring signals to improve transmission efficiency with BSS color Smart Connect Intelligently chooses the best available band for each device Access Point Mode Extends a wired network and makes it wireless
Design - Housing material - Plastic
Design - LED indicators - LAN, Power, WLAN
Design - LED indicators - Power, WLAN
Design - On/off switch - Yes
Design - Product colour - Black
Design - Product type - Tabletop router
Design - Wall mountable - Yes
Design > Colour of product - Black
dimensionalWeight - 1638
Dimensions - 208.8 × 171.6 × 41.7 мм
EAN - 6957939000509
Eans - 6957939000509
Features - Built-in processor - Yes
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - Yes
Full Description Line - MR70X|Available bandwidth 1800 Mbps|Data transmission speed 1200 Mbps|Wi-Fi 6|1 WAN|3x10/100/1000M|Antenna Type Omni-Directional|Antenna Gain 5 dB|Number of antennas 4|Dimensions 208.8 × 171.6 × 41.7 мм
GTIN - 6957939000509
ImageUrl - https://www.balticdata.lv/Gfx/ProductImages/Info/Product_70597_1.jpg
LargeDescHTML -
Link - https://www.mercusys.com/en/product/details/mr70x
LongSummaryDescription - TP-Link MR70X. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 1800 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Product type: Tabletop router, Product colour: Black, Housing material: Plastic. Antenna design: External, Antenna gain level (max): 5 dBi
Management features - MU-MIMO technology - Yes
Management features - Reset button - Yes
Management features - Web-based management - Yes
Management features - WPS push button - Yes
Mobile network - 3G - No
Mobile network - 4G - No
Mobile network - 5G - No
Model name - MR70X
Name - AX1800 Dual-Band WiFi 6 Router | MR70X | 802.11ax | 1201+574 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 3 | Mesh Support No | MU-MiMO Yes | No mobile broadband | Antenna type 4xFixed
Name - Mercusys AX1800 MR70X
Name - Mercusys MR70X
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Networking standards - IEEE 802.11a
Network - Networking standards - IEEE 802.11ac
Network - Networking standards - IEEE 802.11ax
Network - Networking standards - IEEE 802.11b
Network - Networking standards - IEEE 802.11g
Network - Networking standards - IEEE 802.11n
Network - Port forwarding - Yes
Network - Port triggering - Yes
Network - VPN Passthrough - Yes
Network - Wireless radio - Yes
Number of antennas - 4
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Other features > Ethernet LAN (RJ-45) ports - 3
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 390 mm
Package features > Gross depth master carton - 600 mm
Package features > Gross height (mm) - 70 mm
Package features > Gross height master carton - 360 mm
Package features > Gross width (mm) - 290.00 mm
Package features > Gross width master carton - 410 mm
Package features > Net weight master carton - 8.55 kg
Package features > Packing quantity - 10 pc(s)
Package features > Palette Qty - 190 pc(s)
Package features > Paper/Pasteboard - 280.00 g
Package features > Plastic (No PET) - 70.00 g
Package features > Tare weight (kg) - 0.35 kg
Package features > Tare weight master carton - 1.506 kg
Package features > TI weight (kg) - 0.15 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.007917 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging data - AC adapter included - Yes
Packaging data - Cables included - LAN (RJ-45)
Packaging data - Quick installation guide - Yes
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Performance > Wi-Fi data rate (max) - 1201+574 Mbit/s
Ports & interfaces - Ethernet LAN (RJ-45) ports - 3
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - Memory card slot(s) - No
Ports & interfaces - USB port - No
Ports & interfaces > WAN connection - 1 × Gigabit WAN Port
Power - Power source type - AC
Power - Power source type - DC
Producer - Mercusys
producerCode - MR70X
ProducerCode - MR70X
Producer product family - AX1800 Dual-Band WiFi 6 Router
Producer product name - MR70X
productName - Mercusys AX1800 Dual-Band WiFi 6 Router
ProductName - MR70X
productSize - Normal
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Protocols - Universal Plug and Play (UPnP) - Yes
Security - Access Control List (ACL) - Yes
Security - DMZ support - Yes
Security - Firewall - Yes
Security - Firewall security - SPI Firewall, IP and MAC Address Binding
Security - MAC address filtering - Yes
Shipping Box Depth Shipping/Package Box Dimensions - 60 cm
Shipping Box Height Shipping/Package Box Dimensions - 36 cm
Shipping box quantity - 10
Shipping Box Weight Shipping/Package Box Dimensions - 9.75 kg
Shipping Box Width Shipping/Package Box Dimensions - 40 cm
ShortDescription -
ShortSummaryDescription - TP-Link MR70X, Wi-Fi 6 (802.11ax), Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, Black, Tabletop router
sizeX - 390
sizeY - 300
sizeZ - 70
Technical details > Gross weight - 0.855 kg
Technical details > Net weight - 0.505 kg
Technical details > Producer - Mercusys
Title - TP-Link MR70X wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black
Unit Box Height - 0.292
Unit Box Length - 0.391
Unit Box Width - 0.071
Unit Brutto Volume - 0.00864 cubm
Unit Gross Weight - 0.975 kg
Unit Net Weight - 0.48 kg
Vendor Homepage - www.mercusys.com/en/product/details/mr70x
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
Warranty - 24
Warranty - 24 month(s)
Warranty - 36 months
warrantyLength - 24
warrantyType - G
weight - 830
Weight & dimensions - Depth - 171.6 mm
Weight & dimensions - Height - 41.7 mm
Weight & dimensions - Width - 208.8 mm
Wi-Fi 6 Network standard - Yes
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 6 (802.11ax)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi standards - Wi-Fi 6 (802.11ax)
Wireless LAN features - WLAN data transfer rate (first band) - 574 Mbit/s
Wireless LAN features - WLAN data transfer rate (first band) - 1201 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 1775 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 1800 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 574 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 1201 Mbit/s
Wireless LAN features > Wi-Fi band - 802.11ax
