10/100/1000M LAN Ports - 1
Accessories included - EAP620 HD Zasilacz Zestaw montażowy Instrukcja instalacji
Antenna - Built-in
Antenna - Antenna direction type - Omni-directional
Antenna - Antenna type - Internal
Antenna > Antenna type - Internal
Antenna > Antenna type - Omni directional internal
Antenna gain - 5 dBi
Antenna Type - Built-in
ARTIKEL1 - AX1800 WI-FI 6 ACCESS POINT
ARTIKEL2 - CEILING MOUNT DUAL-BAND V3.0
Brand - TP-Link
BrandPartCode - EAP620 HD
Category - Root/Electronics/Networks and communication/Access points
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Code - EAP620 HD
Code - EAP620 HD/
Color - White
Colour - White
Data transmission speed - 1800 Mbps
Description - AX1800 Wireless Dual Band Ceiling Mount Access Point - Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds.† - High-Density Connectivity: 4× increased capacity to connect more devices simultaneously.‡ - Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)§, Centralized Cloud Management, and Intelligent Monitoring. - Centralized Management: Cloud access and Omada app for ultra convenience and easy management. - Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.? - PoE+ Support: Supports Power over Ethernet (802.3at) for convenient deployment and installation. - Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.
Description - Gigabitowy, dwupasmowy, bezprzewodowy punkt dostępowy z możliwością montażu na suficie, standard AX1800 Błyskawiczne prędkości w standardzie Wi-Fi 6: Jednoczesna obsługa prędkości dochodzących do 574 Mb/s w paśmie 2,4 GHz i 1201 Mb/s w paśmie 5 GHz, co daje łącznie nawet 1775 Mb/s. Stabilna praca w mocno obciążonych środowiskach: 4 razy wyższa wydajność niż w standardzie poprzedniej generacji oznacza możliwość jednoczesnego łączenia się znacznie większej liczby urządzeń. Możliwość korzystania z Omada SDN: Platforma zapewnia dostęp do bezobsługowej konfiguracji ZTP§, centralnego zarządzania w chmurze oraz inteligentnego monitoringu. Scentralizowane zarządzanie: Zarządzanie jest niezwykle wygodne dzięki dostępowi z chmury oraz łatwej w użytkowaniu aplikacji Omada. Płynny roaming: Transmisje wideo i trwające połączenia głosowe nie są przerywane, gdy użytkownicy zmieniają lokalizację. Obsługa zasilania PoE+: Dobór lokalizacji dla urządzenia oraz jego montaż nie przysparzają większych trudności dzięki obsłudze zasialnia PoE (w standardzie 802.3at). Bezpieczna sieć dla gości: Do dyspozycji jest wiele metod uwierzytelniania (SMS/Facebook Wi-Fi/ Voucher, itp.) oraz liczne technologie, które chronią dostępu do sieci bezprzewodowych.
Design - Certification - CE, FCC, RoHS
Design - LED indicators - Yes
Design - Placement - Ceiling, Wall
Design - Product colour - White
Design - Reset button - Yes
dimension depth - 80 mm
dimension height - 310 mm
Dimensions - 243 x 243 x 64 mm
Dimensions - 243 × 243 × 64 mm
dimension weight - 1313 g
dimension width - 303 mm
EAN - 4897098687765
ean - 4897098687765
EAN - 6935364030742
EANCode - 4897098687765
Eans - 4897098687765
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Airtime Fairness (ATF) - Yes
Features - Automatic channel scanning - Yes
Features - Automatic channel selection - Yes
Features - Band steering - Yes
Features - BeamForming - Yes
Features - Cabling technology - 10/100/1000Base-T(X)
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Fit AP mode features - Mesh networking
Features - Flow control support - Yes
Features - Frequency band - 2.4 - 5 GHz
Features - Maximum data transfer rate - 1201 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 574 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 1201 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
Features - Number of users - 1020 user(s)
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - Spread spectrum method - OFDMA
Features - Transmitting power (CE) - 20/23 dBm
Features - Transmitting power (FCC) - 23 dBm
Features - VLAN support - Yes
Features > MU-MiMO - Yes
Full Description Line - Omada|EAP620 HD|Type Range Extender|Data transmission speed 1800 Mbps|IEEE 802.11a|IEEE 802.11g|IEEE 802.11n|IEEE 802.11ac|IEEE 802.11ax|1x10/100/1000M|Antenna Type Built-in|Colour White|Dimensions 243 × 243 × 64 mm
Gross Weight Kg - 1
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 4897098687765
GTIN - 6935364030742
GTIN - 6935364030759
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
HSTNUMMER - EAP620 HD
I/O ports - 1 x 10/100/1000 Mbit/s PoE
IEEE 802.11ac Network standard - Yes
IEEE 802.11a Network standard - Yes
IEEE 802.11ax Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
Link - https://www.tp-link.com/us/business-networking/ceiling-mount-access-point/eap620-hd/
LongDesc - High-Density Connectivity with 4× Increased CapacityOFDMA* and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.Advanced Wi-Fi Speed with 4 Spatial StreamsThe Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 1775 Mbps (1201 Mbps on a 5 GHz band and 574 Mbps on a 2.4 GHz band). With 8 spatial streams, multi-user throughput is incredibly increased to drive more applications.Omada SDN—Smarter Cloud Solution for Business NetworkingOmada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.Seamless Roaming802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.Secure Guest Network with Facebook Wi-Fi and SMS LoginGuest Network provides elevated secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.
LongProductName - IEEE 802.11ax/ac/n/g/b/a, 1G LAN, 2.4/5 GHz, PoE, 243x243x64 mm
LongSummaryDescription - TP-Link Omada AX1800 Ceiling Mount WiFi 6 Access Point. Maximum data transfer rate: 1201 Mbit/s, Maximum data transfer rate (2.4 GHz): 574 Mbit/s, Maximum data transfer rate (5 GHz): 1201 Mbit/s. Security algorithms: SNMP, SNMPv2, SNMPv3, SSH, WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-PSK. Power over Ethernet (PoE) type supported: Active PoE, Passive PoE, DC voltage range: 12 V. Placement: Ceiling, Wall, Product colour: White, Certification: CE, FCC, RoHS. Antenna type: Internal, Antenna direction type: Omni-directional
Management, monitoring, configuration - Aplikacja Omada: Tak Zarządzanie centralne: Kontroler Omada oparty na Chmurze, Kontroler sprzętowy Omada (OC300), Kontroler sprzętowy Omada (OC200) Kontroler programowy Omada Dostęp do chmury: Tak (poprzez kontroler OC300, OC200, kontroler Omada oparty na chmurze lub kontroler programowy Omada) Powiadomienia e-mail Wyłącznik diod Kontrola dostępu po adresach MAC SNMP: v1, v2c, v3 Dziennik systemowy: Lokalny i zdalny Zarządzanie przez przeglądarkę: HTTP/HTTPS Zarządzanie L3 Zarządzanie multi-site Zarządzanie VLAN
Management features - Firmware upgradeable - Yes
Management features - Syslog - Yes
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - EAP620 HD
Manufacturer Name - TP-LINK
Model name - EAP620 HD
MPN - EAP620HD
name - Access Point EAP620 HD 1xGb PoE AX1800
Name - TP-Link EAP620 HD
Name - TP-LINK Omada EAP620 HD Wifi-6
Name - TP-LINK | AX1800 Wireless Dual Band Ceiling Mount Access Point | EAP620 HD | 802.11ax | 2.4GHz/5GHz | 1201+574 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | MU-MiMO Yes | PoE in | Antenna type Omni directional internal
Name - TP-LINK | TP-Link EAP620 AX1800 Ceiling Mount WiFi 6 Access Point | EAP620 | 802.11ax | 1201+574 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | MU-MiMO Yes | PoE in | Antenna type Internal
Network architecture - GigabitEthernet
Network Device Type - Range Extender
Networking > Wi-Fi - Yes
Networking > Wi-Fi standards - 802.11ax
Number of antennas - 4
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other features > Ethernet LAN (RJ-45) ports - 1
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 300 mm
Package features > Gross depth (mm) - 300.00 mm
Package features > Gross depth master carton - 325 mm
Package features > Gross depth master carton - 330 mm
Package features > Gross height (mm) - 305 mm
Package features > Gross height (mm) - 305.00 mm
Package features > Gross height master carton - 430 mm
Package features > Gross height master carton - 435 mm
Package features > Gross width (mm) - 80 mm
Package features > Gross width (mm) - 80.00 mm
Package features > Gross width master carton - 325 mm
Package features > Net weight master carton - 6.38 kg
Package features > Net weight master carton - 7.5 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Packing quantity - 5 pc(s)
Package features > Palette Qty - 185 pc(s)
Package features > Palette Qty - 236 pc(s)
Package features > Paper/Pasteboard - 336.00 g
Package features > Paper/Pasteboard - 390.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Plastic (No PET) - 84.00 g
Package features > Tare weight (kg) - 0.40 kg
Package features > Tare weight (kg) - 0.42 kg
Package features > Tare weight master carton - 0.772 kg
Package features > Tare weight master carton - 0.793 kg
Package features > Volume (m3) - 0.00732 m³
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Mounting kit - Yes
Packaging content - Number of products included - 1 pc(s)
Packaging content - Quick start guide - Yes
Packaging data - Package type - Box
Performance > 2.4 GHz - Yes
Performance > 5 GHz - Yes
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Performance > Frequency band - 2.4GHz/5GHz
Performance > Web-based management - Yes
Performance > Wi-Fi data rate (max) - 1201+574 Mbit/s
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > POE - PoE in
Power - DC voltage range - 12 V
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Active PoE, Passive PoE
Power supply - 802.3at PoE 12 V DC
producer - TP-LINK
Producer - TP-Link
ProducerCode - EAP620 HD
Producer product family - AX1800 Wireless Dual Band Ceiling Mount Access Point
Producer product family - TP-Link EAP620 AX1800 Ceiling Mount WiFi 6 Access Point
Producer product name - EAP620
Producer product name - EAP620 HD
ProductName - AX1800 Ceiling Mount WiFi 6 Access Point
Security - Uwierzytelnianie przy pomocy strony powitalnej Kontrola dostępu Filtrowanie adresów MAC Izolacja klientów połączonych z siecią bezprzewodową Mapowanie SSID do VLAN Wykrywanie nieautoryzowanych AP Obsługa 802.1X Szyfrowanie WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Security - Access Control List (ACL) - Yes
Security - MAC address filtering - Yes
Security - Remote Authentication Dial-In User Service (RADIUS) - Yes
Security - Security algorithms - SNMP, SNMPv2, SNMPv3, SSH, WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-PSK
Series - Omada
Shipping Box Depth Shipping/Package Box Dimensions - 52 cm
Shipping Box Height Shipping/Package Box Dimensions - 30 cm
Shipping box quantity - 16
Shipping Box Weight Shipping/Package Box Dimensions - 15.5 kg
Shipping Box Width Shipping/Package Box Dimensions - 49 cm
ShortDescription -
Short description - TP-LINK WLAN AX1800 Access Point Dualband EAP620 HD
ShortSummaryDescription - TP-Link Omada AX1800 Ceiling Mount WiFi 6 Access Point, 1201 Mbit/s, 574 Mbit/s, 1201 Mbit/s, 10,100,1000 Mbit/s, 2.4 - 5 GHz, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 16
Stck_Pal - 34
Storno - Y
System Requirements -
Technical details > Gross weight - 1.26 kg
Technical details > Gross weight - 1.276 kg
Technical details > Net weight - 0.86 kg
Technical details > Net weight - 0.856 kg
Technical details > Other features - Mounting kit included
Technical details > Producer - TP-LINK
Title - TP-Link Omada AX1800 Ceiling Mount WiFi 6 Access Point
Unit Box Height - 0.305
Unit Box Length - 0.305
Unit Box Width - 0.08
Unit Brutto Volume - 0.004777 cubm
Unit Gross Weight - 0.969 kg
Unit Net Weight - 0.9 kg
URL - https://www.tp-link.com/uk/business-networking/ceiling-mount-ap/eap620-hd/
Vendor Homepage - www.tp-link.com/baltic/business-networking/omada-sdn-access-point/eap620-hd/
vendpn - EAP620 HD
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo - Lifetime
Weight - 0.878
Weight & dimensions - Depth - 160 mm
Weight & dimensions - Height - 33 mm
Weight & dimensions - Width - 160 mm
Wireless LAN features > Wi-Fi band - 802.11ax
Wireless LAN features > Wi-Fi standards - 802.11ax/ac/n/g/b/a
