Accessories included - EAP230-Wall Instrukcja instalacji Wkręty do montażu
Antenna - Built-in
Antenna - Antenna features - Integrated antenna
Antenna - Antenna gain level (max) - 3.6 dBi
Antenna - Antennas quantity - 2
Antenna - Antenna type - Internal
Antenna > Antennas quantity - 2
Antenna gain - 4 dBi
ARTIKEL1 - OMADA AC1200 WIRELESS WALL AP
ARTIKEL2 - MU-MIMO GIGABIT
Brand - TP-Link
BrandPartCode - EAP230-WALL
Category - Root/Electronics/Networks and communication/Access points
Category - Wireless Access Points
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Code - EAP230-Wall
Color - White
Description - Bezprzewodowy, gigabitowy, naścienny punkt dostępowy Omada, MU-MIMO, AC1200 Niesamowicie cienka obudowa o grubości 11 mm. Technologia 802.11ac Wave 2 pozwala wielu użytkownikom na łączenie się z Internetem w tym samym czasie. EAP230-Wall to rozwiązanie sieciowe, które sprawdzi się w budynkach podzielonych na wiele pomieszczeń, takich jak hotele, biura oraz akademiki. Urządzenie ma rozmiar i kształt włącznika światła lub gniazdka, dlatego idealnie pasuje do każdego pomieszczenia. Centralne zarządzanie z chmury z dowolnego miejsca i o dowolnej porze. Łatwe zarządzanie z aplikacją Omada.
Design - LED indicators - Operation
Design - Placement - Wall
Design - Product colour - White
Design - Reset button - Yes
dimensionalWeight - 156
dimension depth - 50 mm
dimension height - 130 mm
Dimensions - 86,8 × 86,8 × 30,2 mm
dimension weight - 240 g
dimension width - 120 mm
EAN - 6935364089481
ean - 6935364089481
EANCode - 6935364089481
Eans - 6935364089481
EAN_code - 6935364089481
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Automatic channel scanning - Yes
Features - Automatic channel selection - Yes
Features - Band steering - Yes
Features - BeamForming - Yes
Features - Cabling technology - 10/100/1000Base-T(X)
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Ethernet LAN data rates - 100
Features - Ethernet LAN data rates - 1000 Mbit/s
Features - Frequency band - 2.4 - 5 GHz
Features - Maximum data transfer rate - 1167 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 300 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 867 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.3af
Features - Networking standards - IEEE 802.3at
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - Transmitting power (CE) - 20 - 23 dBm
Features - Virtual LAN features - Port-based VLAN
Features - Virtual LAN features - Port-based VLAN, VLAN mapping
Features - Virtual LAN features - VLAN mapping
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Features > MU-MiMO - Yes
Gross Weight Kg - 0,26
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 6935364089481
GTIN - 6935364089498
guarantee - 36
guarantee_type - normal
HERSTELLER - TP-LINK
HSTNUMMER - EAP230-WALL
I/O ports - 2 x 10/100/1000 Mbit/s
Link - https://www.tp-link.com/ae/business-networking/wall-plate-ap/eap230-wall/
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Unprecedented Thin Design with 11mmOmada EAP230-WallAC Access PointPrivate Connection for Every Room.EAP230-Wall is designed to meet every network need in environments with numerous separated rooms, like hotels, offices, and dormitories. A device in each room ensures an exclusive, high-speed Wi-Fi connection for every user. MU-MIMO + Dual-Band: Faster Connection for More Devices802.11ac wave 2 technology allows multiple users to access the internet at the same time. Speeds up to 1200 Mbps and 2.4 GHz and 5 GHz wireless bands deliver simultaneous high-speed internet access to various devices.Seamlessly Blends with any Décor The same size and shape as a light switch or power outlet faceplate to fit in perfectly in any room.High-Speed Gigabit PortEquipped with a Gigabit port to deliver the fastest possible wired transmission.Effortless Deployment with Power over Ethernet802.3af/802.3at PoE support means there’s no need for extra wiring. Plug in existing Ethernet cables to transmit both power and data to your APs.Quick, Simple Installation1.Detach and remove the faceplate of the junction box.2.Plug an Ethernet cable in to the port.3.Secure the Access Point to the wall using the provided screws.4.Press the faceplate back into position.Omada SDN—Smarter Cloud Solution for Business NetworkingOmada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.Easy Management with the Omada AppFollow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
LongProductName - 10/100/1000 Mbps, 2.4GHz/5GHz, CE, HTTP/HTTPS, white
LongSummaryDescription - TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1167 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, SNMP, SNMPv2, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 25.5 W
Management, monitoring, configuration - Dostęp do Omada Cloud Aplikacja Omada Kontroler Omada Cloud Zarządzanie centralne: Omada Cloud-Based Controller/ Omada Hardware Controller (OC300) / Omada Hardware Controller (OC200) / Omada Software Controller Oprogramowanie Omada Controller Dostęp do chmury: (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) Powiadomienia e-mail Wyłącznik diod Kontrola dostępu po adresach MAC SNMP v1, v2c Dziennik systemowy: Lokalny i zdalny SSH Zarządzanie przez przeglądarkę HTTP/HTTPS Zarządzanie L3 Zarządzanie multi-site Zarządzanie VLAN
Management features - Syslog - Yes
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - EAP230-WALL
Manufacturer Name - TP-LINK
Manufacturer_code - EAP230-WALL
Name - TP-Link EAP230-Wall
name - TP-Link EAP230-Wall 1GE PoE AC1200
Name - TP-Link Omada EAP230-WALL, Access Point
Name - TP-LINK | Omada AC1200 Wall-Plate Access Point | EAP230-Wall | 802.11ac | 300+867 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 2 | MU-MiMO Yes
Network architecture - GigabitEthernet
Networking > Wi-Fi - Yes
Number of antennas - 2
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - Montaż naścienny Hardware Watch Dog: Tak Dopuszczalna temperatura pracy: 0~40 (32~104); Dopuszczalna temperatura przechowywania: -40~70 (-40~158) Dopuszczalna wilgotność powietrza: 10%~90% niekondensująca; Dopuszczalna temperatura przechowywania: 5%~90% niekondensująca
Other features > Ethernet LAN (RJ-45) ports - 2
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 130.00 mm
Package features > Gross height (mm) - 47.00 mm
Package features > Gross weight - 0.51 kg
Package features > Gross width (mm) - 118.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Paper/Pasteboard - 240.00 g
Package features > Plastic (No PET) - 60.00 g
Package features > Tare weight (kg) - 0.30 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Mounting kit - Yes
Packaging content - Number of products included - 2 pc(s)
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 130 mm
Packaging data - Package height - 47 mm
Packaging data - Package weight - 210 g
Packaging data - Package width - 118 mm
Performance - Compatible operating systems - Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
Performance > 2.4 GHz - Yes
Performance > 5 GHz - Yes
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Performance > Web-based management - Yes
Performance > Wi-Fi data rate (max) - 300+867 Mbit/s
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - WAN connection - Ethernet (RJ-45)
Power - Power consumption (max) - 25.5 W
Power - Power consumption (typical) - 9 W
Power - Power over Ethernet (PoE) - Yes
Power supply - 802.3af/802.3at PoE Pobór mocy: 7 W
producer - TP-LINK
Producer - TP-Link
producerCode - EAP230-Wall
ProducerCode - EAP230-Wall
Producer product family - Omada AC1200 Wall-Plate Access Point
Producer product name - EAP230-Wall
ProductName - Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point
productName - TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point
productSize - Normal
Protocols - Secure File Transfer Protocol (SFTP) using SSH v2 - Yes
Security - Uwierzytelnianie przy pomocy strony powitalnej Kontrola dostępu Filtrowanie adresów MAC Izolacja klientów sieci bezprzewodowej Mapowanie SSID do VLAN Sieć VLAN oparta na portach lokalnych LAN Wykrywanie nieautoryzowanych AP Obsługa 802.1X Szyfrowanie 64/128/152-bit WEP, WPA/WPA2-PSK, WPA/WPA2-Enterprise
Security - Access Control List (ACL) - Yes
Security - MAC address filtering - Yes
Security - Number of SSID supported - 16
Security - Security algorithms - 64-bit WEP
Security - Security algorithms - 64-bit WEP, 128-bit WEP, 152-bit WEP, SNMP, SNMPv2, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Security - Security algorithms - 128-bit WEP
Security - Security algorithms - 152-bit WEP
Security - Security algorithms - SNMP
Security - Security algorithms - SNMPv2
Security - Security algorithms - WPA
Security - Security algorithms - WPA-PSK
Security - Security algorithms - WPA2-Enterprise
Security - Security algorithms - WPA2-PSK
Security - Service Set Identifier (SSID) features - Multiple SSIDs
ShortDescription -
Short description - TP-LINK WLAN AC1200 Access Point Dualband EAP230-Wall
ShortSummaryDescription - TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point, 2.4 GHz, 5 GHz, 1167 Mbit/s, 64-bit WEP, 128-bit WEP, 152-bit WEP, SNMP, SNMPv2, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK, 10,100,1000 Mbit/s
sizeX - 130
sizeY - 120
sizeZ - 50
Software -
Special functions - 16 SSIDdo 8 SSID na każdym paśmie Wyłączanie sieci bezprzewodowej Automatyczny wybór kanału Kontrola mocy transmisji QoS (WMM) Równoważenie obciążenia pasma Limit prędkości Harmonogram restartu Harmonogram sieci bezprzewodowej Statystyki sieci bezprzewodowej w oparciu o SSID/AP/klienta
Standards - 802.11ac
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 36
Stck_Pal - 0
Storno - Y
Sustainability - Sustainability compliance - Yes
System Requirements - Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
Technical details - Compliance certificates - CE
Technical details - Compliance certificates - CE, RoHS
Technical details - Compliance certificates - RoHS
Technical details > Net weight - 0.21 kg
Technical details > Producer - TP-LINK
Title - TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point
URL - https://www.tp-link.com/uk/business-networking/wall-plate-ap/eap230-wall/
vendpn - EAP230-Wall
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo - Lifetime
warrantyLength - 60
warrantyType - G
Weight - 0,24
weight - 245
Weight & dimensions - Depth - 86.8 mm
Weight & dimensions - Height - 30.2 mm
Weight & dimensions - Width - 86.8 mm
Wireless LAN features > Wi-Fi band - 802.11ac
Wireless LAN features > Wi-Fi standards - 802.11n/g/b/ac
