Accessories included -
Antenna - Fixed external
Antenna - Antennas quantity - 2
Antenna > Antennas quantity - 2
Antenna > Antenna type - 2xExternal
Antenna gain - 5 dBi
ARTIKEL1 - WIRELESS N300 ACCESS POINT
ARTIKEL2 - IN
Brand - D-Link
BrandPartCode - DAP-2020/E
Breite - 0.21
Category - Root/Electronics/Networks and communication/Access points
Category - Wireless Access Points
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Certificates - Certification - Wi-Fi, CE
Code - DAP-2020/E
Color - White
Description - Access point N (DAP-2220) It is used to create a secure and manageable wireless corporate network. Multiple operating modes, network management tools and security functions give administrators a range of possibilities to use DAP-2220. The device can be placed in the selected location, fixed to the wall or placed on a desk.
Design - Internal - No
Design - Product colour - White
Design - Reset button - Yes
dimension depth - 70 mm
dimension height - 280 mm
Dimensions - 147.5 x 113 x 31.5 mm
dimension weight - 640 g
dimension width - 210 mm
EAN - 790069428739
ean - 790069428739
EANCode - 0790069428739
Eans - 0790069428739
EAN_code - 0790069428739
Features - 2.4 GHz - Yes
Features - 5 GHz - No
Features - Ethernet LAN data rates - 10,100 Mbit/s
Features - Frequency band - 2.4 - 2.4835 GHz
Features - Maximum data transfer rate - 300 Mbit/s
Features - Modulation - CCK, DBPSK, DQPSK, OFDM
Features - Networking standards - IEEE 802.3i, IEEE 802.3u
Features - Quality of Service (QoS) support - Yes
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - No
Gewicht - 0.61
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 0790069428739
GTIN - 790069428739
guarantee - 24
guarantee_type - external
HERSTELLER - D-LINK
Hoehe - 0.07
HSTNUMMER - DAP-2020/E
I/O ports - 1 x 10/100 Mbit/s
Laenge - 0.27
Link - https://eu.dlink.com/uk/en/products/dap-2020-wireless-n-access-point
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - The DAP-2020 Wireless N Access Point allows your business to create a secure and manageable wireless network. Multiple operational modes, network management tools and security features gives network administrators more flexible deployment options. The DAP-2020 can be wall mounted or placed on a desktop to meet any wireless demands. Secure Your Wireless Network The DAP-2020 provides 64/128-bit WEP encryption and WPA/WPA2 security to protect your network and wireless data. This device also supports Wi-Fi Protected Setup (WPS) to quickly and securely set up a wireless network. In addition, the device features MAC address filtering and the ability to disable SSID broadcasting, preventing unauthorised access to your home or office network.Multiple Operation ModesThe DAP-2020 offers seven different modes of operation. These modes allow you to flexibly configure the device to suit a variety of different wireless applications. Access point mode allows the device to act as a central hub for wireless users. Wireless client mode enables the DAP-2020 to connect to another access point. Bridge mode can join two wired networks together, while bridge with AP mode allows the device to act as a wireless hub and as a bridge at the same time. Repeater mode extends wireless coverage to cover all dead spots. WISP client router mode allows wireless Internet service subscribers to share an Internet connection with wired home/office computers without the need for an extra router. Finally, the device can act as a WISP repeater (range extender) to let WISP subscribers share their Internet connection with wired and wireless computers, without any additional routers.
LongProductName - 802.11b/g/n, 300Mbps, WPA2/WPA, 10/100BASE-TX Ethernet LAN port, 2.4 - 2.4835GHz
LongSummaryDescription - D-Link DAP-2020. 2.4 GHz, Maximum data transfer rate: 300 Mbit/s. Security algorithms: WPA, WPA2. Ethernet LAN data rates: 10,100 Mbit/s. Product colour: White. Power consumption (max): 2.25 W
Management, monitoring, configuration -
Management features - Web-based management - Yes
Manufacturer - D-Link
Manufacturer_code - DAP-2020/E
Name - D-Link DAP-2020/E
Name - D-Link | Wireless N Access Point | DAP-2020 | 802.11n | Single-band | Mesh Support No | 300 Mbit/s | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 1 | No mobile broadband | MU-MiMO No | Antenna type 2xExternal
Name - D-Link DAP-2020 - white
name - DAP-2020 AP N300
Network architecture - FastEthernet
Number of antennas - 2
Operating frequency - 2,4 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 65 °C
Other features - Certificates: Wi-Fi, CE
Other features > Ethernet LAN (RJ-45) ports - 1
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 274.00 mm
Package features > Gross height (mm) - 68.00 mm
Package features > Gross width (mm) - 208.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 446 pc(s)
Package features > Paper/Pasteboard - 650.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.66 kg
Package features > TI weight (kg) - 0 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging data - Package depth - 274 mm
Packaging data - Package height - 68 mm
Packaging data - Package weight - 600 g
Packaging data - Package width - 208 mm
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Performance > Frequency band - Single-band
Performance > Wi-Fi data rate (max) - 300 Mbit/s
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - AC input voltage - 12 V
Power - Input current - 0.5 A
Power - Power consumption (max) - 2.25 W
Power supply - External power supply: 12 V DC/0.5 A
producer - D-Link
Producer - D-link
ProducerCode - DAP-2020/E
Producer product family - Wireless N Access Point
Producer product name - DAP-2020
ProductName - DAP-2020
Security - - WPA2/WPA wireless encryption - Wi-Fi Protected Setup (WPS) - Easy to Use and Manage - Intuitive web user interface - Built-in setup wizard
Security - Security algorithms - WPA, WPA2
ShortDescription -
ShortSummaryDescription - D-Link DAP-2020, 2.4 GHz, 300 Mbit/s, WPA, WPA2, 10,100 Mbit/s
Software -
Special functions -
Standards - 802.3
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 10
Stck_Pal - 20
Storno - N
System Requirements -
Technical details - Master (outer) cases per pallet (air) - 30 pc(s)
Technical details - Master (outer) cases per pallet (sea) - 48 pc(s)
Technical details - Pallet gross length - 120 cm
Technical details - Pallet gross weight (air) - 223 kg
Technical details - Pallet gross weight (sea) - 343.6 kg
Technical details - Pallet gross width - 110 cm
Technical details - Pallet height (air) - 133.5 cm
Technical details - Pallet height (sea) - 2.06 m
Technical details - Products per pallet (air) - 300 pc(s)
Technical details - Products per pallet (sea) - 480 pc(s)
Technical details - Products per shipping (inner) case - 10 pc(s)
Technical details - Shipping (inner) case gross weight - 6.7 kg
Technical details - Shipping (inner) case height - 24 cm
Technical details - Shipping (inner) case length - 57.1 cm
Technical details - Shipping (inner) case net weight - 6 kg
Technical details - Shipping (inner) case width - 36 cm
Technical details > Gross weight - 1.09 kg
Technical details > Net weight - 0.43 kg
Technical details > Producer - D-Link
Title - D-Link DAP-2020 300 Mbit/s White
Unboxing -
URL - https://www.dlink.com/uk/en/products/dap-2020-wireless-n-access-point
vendpn - DAP-2020/E
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo -
Weight - 0,65
Weight - 224.7 g
Weight & dimensions - Depth - 113 mm
Weight & dimensions - Height - 31.5 mm
Weight & dimensions - Weight - 224.7 g
Weight & dimensions - Width - 147.5 mm
Wireless LAN features > Wi-Fi band - 802.11n
